Linksys KVM2KIT User manual

Integrated KVM2-Port Switch
The Linksys ProConnect®Integrated KVM 2-Port
Switch lets you take instant command over two
PCs—all from a single keyboard, mouse, and
monitor! For your convenience, it even comes with
built-in cables to meet all your connection needs.
Switch between PCs with a quick, two-key action, or
use the automatic scan feature to easily monitor both
computers.
The KVM Switch eliminates those pesky, cable-
swapping duties while saving you desktop space and
hardware costs. Because it doesn’t use software, the
KVM Switch is compatible with all major desktop and
notebook computers. It’s the perfect choice for the
home, office, or anywhere else you work with two PCs
at the same time.
• Supports a Screen Resolution of up to 1920 x 1440
• Complete, Plug-and-Play Monitor Support
• Compatible with Virtually All PS/2 Keyboards and
Mice
• Caps Lock, Number Lock, and Scroll Lock Settings
Automatically Recalled for Each PC
• Hot-Pluggable—Swap out Your Keyboard, Mouse, or
Computers at Any Time
• No Software Required
•Easily Control Two PCs from a Single
Keyboard, Mouse, and Monitor
•Toggle between PCs with Quick, Hot Key
Combinations
•Convenient, Built-in Cables for a User-
Friendly, All-in-One Design
•Save Desktop Space, Energy, and
Hardware Costs
•Free Technical Support—24 Hours a Day,
7 Days a Week, Toll-Free US Calls
•1-Year Limited Warranty
ProConnect®Integrated KVM 2-Port Switch
Model Number: KVM2KIT
Save Desktop Space—Use a Single Monitor,
Keyboard, and Mouse for Two PCs
Features
Features
Benefits
Benefits
CCoonnttrroollTTwwooCCoommppuutteerrss
ffrroommaaSSiinngglleeCCoonnssoollee
ProConnect
®
Series

Package Contents
ProConnect®Integrated KVM 2-Port
Switch
• Integrated KVM 2-Port Switch
• One Quick Installation
• One Registration Card
DS-KVM2KIT-082702NC JL
Specifications
Model Number KVM2KIT
Standards PS/2
Protocol Microsoft PS/2 Protocol
Ports Keyboard: 1 PS/2 female - Console
2 PS/2 male - CPU
Mouse: 1 PS/2 female - Console
2 PS/2 male - CPU
Monitor: 1 HD15 female - Console
2 HD15 male - CPU
LEDs PC 1, PC 2
Resolution up to 1920 x 1440
Scan Interval 3, 5, 10, or 20 seconds (3 is default)
Environmental
Dimensions 3.125" x 3.0" x 0.875"
(79.4 mm x 76.2 mm x 22.2 mm)
Unit Weight 11.8 oz. (0.33 kg)
Certifications FCC Class B, CE Mark
Operating Temp. 32ºF to 122ºF (0ºC to 50ºC )
Storage Temp. -4ºF to 140ºF (-20ºC to 60ºC)
Operating Humidity 0% to 80%, Non-Condensing
Storage Humidity 0% to 80%, Non-Condensing
Console
• One VGA, SVGA, or Multisync Monitor
Capableofthe Highest ResolutionYouWillBe
Using on Either Computer
• One PS/2 Keyboard
• One PS/2 Mouse
Either Computer
• VGA, SVGA, or Multisync Video Card
• One PS/2 Port for the Keyboard
• One PS/2 Port for the Mouse
Minimum Requirements
Linksys
World Headquarters:
17401 Armstrong Ave.
Irvine, CA 92614 USA
E-mail: [email protected]
[email protected]
Web: http://www.linksys.com
Linksys products are available in more than 50
countries, supported by 12 Linksys Regional
Offices throughout the world. For a complete
list of local Linksys Sales and Technical
Support contacts,visit ourWorldwideWeb Site
at www.linksys.com .
