Linon MONACO 0217VESP-01-KD-U User manual

'
MODEL：0217VESP-01-KD-U
24” MONACO COUNTER STOOL
We are here to help!
We do our best to insure that your furniture arrives in excellent condition. In the event that a part is
damaged or missing, Linon Home Decor will be happy to provide you with replacement parts, at no
charge, within 30 days of purchase, providing the parts are available in our warehouse and the item
purchased are part of our current inventory. In order to receive spare parts, at no charge, you must
provide proof of purchase within 30 days.
If you need assistance with assembly or replacement parts, please call Linon Customer Service, prior
to returning the item to the store.
Our office is open Monday – Friday 9AM – 5PM, Eastern Standard Time.
Our Toll free customer service number is: 1-800-262-1852.
Or visit our web site www.Linon.com to order spare parts and for care instructions on you’re newly
purchased furniture.
PAGE 1

'
1A
1B
PARTS LIST
PARTS GRAPHICS DESCRIPTION QUANTITY
1A SEAT ASSEMBLY 1
1B BACK ASSEMBLY 1
3C FRONT LEG ASSEMBLY 1
2D RIGHT SIDE STRETCHER 1
2E LEFT SIDE STRETCHER 1
F SHORT BOLT 2
G BACK LEG BOLT 4
H FRONT LEG BOLT 4
I SPRING WASHER 10
J FLAT WASHER 10
K ALLEN HEXAGONAL WRENCH 1
L WOOD SCREW 4
M ADHESIVE PADS 4
If any parts are missing or damaged in this package Home Decor will be happy to provide you with
replacement parts, at no charge, within 30 days of purchase, providing the parts are available in our
warehouse and the item purchased is part of our current inventory. In order to receive spare parts, at
no charge, you must provide proof of purchase within 30 days.
Call us toll free at 1-800-262-1852. Or visit our web site www.Linon.com to order spare parts and for
care instructions on you’re newly purchased furniture.
PAGE 2

'
PREPARATION:
SELECT A WORK SURFACE. WE RECOMMEND A TABLE TOP. PLEASE PROTECT IT VERY WELL,
INCLUDING THE EDGES TO PREVENT ANY DAMAGES; YOU MAY USE A BLANKET AND THE
CARDBOARD FROM THE STOOL BOX．
YOU WILL NEED TO USE YOUR OWN PHILLIPS SCREWDRIVER WITH #2 SIZE HEAD．
STEP-1: CONNECT SEAT-1A TO BACK-1B AS SHOWN IN FIGURE-1
FIGURE-1
1.1 POSITION BACK-1B ON THE WORK SURFACE AS SHOWN IN FIGURE-1.
1.2 LOOK FOR TWO WOODEN DOWELS OUTSIDE SEAT-1A; INSERT THEM INTO THE
CORRESPONDING HOLES IN THE RAIL OF BACK-1B.
1.3 INSERT ONE SPRING WASHER-J, THEN ONE FLAT WASHER-I OVER ONE BACK LEG
BOLT-G; INSERT THE BOLT-G THROUGH ANY OF THE FOUR HOLES IN THE CORNER
BRACKETS ADJACENT TO THE BACK LEGS; IF NECESSARY, MOVE THE BOLT-G AROUND TO
FIND THE HOLE IN THE BACK LEG. TIGHTEN BY HAND.
1.4 REPEAT PROCEDURE 1.3 TO INSTALL THE REMAINING THREE SETS G+J+I.
1.5 REPEAT PROCEDURE 1.4 TO INSTALL TWO SHORT BOLTS WITH HARDWARE F+J+I TO
SECURE SEAT–1A TO BACK-1B.
PAGE 3

'
STEP-2 : CONNECT THE SIDE STRETCHER TO THE BACK-1B AS SHOWN IN FIGURE-2
FIGURE-2
2.1 FOLLOW THE LABELS ON STRETCHERS 2D AND 2E INSERT THEM IN THE BACK LEGS AS
SHOWN. SECURE CONNECTION WITH TWO WOOD SCREWS-L.
PAGE 4

'
STEP-3 : CONNECT THE FRONT LEG TO SEAT-1A AND SIDE STRETCHER AS SHOWN IN FIGURE-3
3C
FIGURE-3A FIGURE-3B
3.1 REMOVE THE SHIPPING CLEAT FROM END OF FRONT LEGASSEMBLY-3C.
3.2 TURN CHAIR AROUND WITH SEAT IN THE WORK SURFACE AS SHOWN IN FIGURE-3B.
3.3 CONNECT FRONT ASSEMBLY-3C TO STRETCHERS 2D AND 2E USING TWO WOOD
SCREWS-G,THEN CONNECT IT TO SEAT-1A USING FOUR FRONT LEG BOLTS-H WITH FOUR
SPRING WASHERS-I, AND FOUR FLAT WASHERS-J AS SHOWN IN FIGURE-3B.
3.4 PLACE FOUR FOOT PAD-M TO THE LEGS OF THE STOOLAS SHOWN.
PAGE 5

'
MAINTENANCE:
4.1 YOUR STOOL ASSEMBLY IS NOW COMPLETED. ENJOY USING IT !
4.2 DO NOT DISCARD THE ALLEN HEXAGONAL WRENCH-D; KEEP IT FOR FUTURE USE.
4.3 PERIODICALLY CHECK ALL CONNECTIONS AND RE-TIGHTEN BOLTS AND WOOD SCREWS IF
NECESSARY. DO NOT OVER-TIGHTEN TO AVOID STRIPPING WOOD OR METAL NUTS.
4.4 CLEAN THE LACQUER FINISH IF NECESSARY WITH CLEAN WATER DAMP CLOTH. IF YOU DO
NOT MIND A CHANGE OF LACQUER SHEEN THEN YOU MAY USE A NON-ABRASIVE FURNITURE
CLEANER. DO NOT USE HOUSEHOLD CLEANING CHEMICALS.
4.5 CLEAN THE UPHOLSTERY WITH A WATER DAMP CLOTH. DO NOT USE HOUSEHOLD
CHEMICALS.
