COVANA OASIS User manual

INSTALLATION MANUAL TABLE OF CONTENTS 1
Revision 0
2019/02/18
C.A. 232857

2 TABLE OF CONTENTS USER MANUAL
TABLE OF CONTENTS
TABLE OF CONTENTS.............................................................................................................................................2
CONGRATULATIONS ON THE PURCHASE OF YOUR NEW COVANA COVER..................................................3
SAFETY......................................................................................................................................................................4
Safety information...................................................................................................................................................4
Avoiding the risk of electrocution............................................................................................................................5
LABELING .................................................................................................................................................................6
GLOSSARY................................................................................................................................................................9
QUICK START-UP INSTRUCTIONS.......................................................................................................................11
LED LIGHT KIT (OPTIONAL)..................................................................................................................................12
MANUAL LIFTING PROCEDURE.......................................................................................................................13
WIRE GUARD REASSEMBLY (OPTIONAL)..........................................................................................................14
WINTERIZING THE OASIS COVER........................................................................................................................16
PERIODIC MAINTENANCE TABLE........................................................................................................................17
TECHNICAL SPECIFICATIONS..............................................................................................................................18
Side elevation .......................................................................................................................................................18
Frame and foot print .............................................................................................................................................19
Electrical specifications.........................................................................................................................................21
Operating limitations.............................................................................................................................................21
General specifications ..........................................................................................................................................21
TROUBLESHOOTING.............................................................................................................................................22
WARRANTY.............................................................................................................................................................24
APPENDIX ...............................................................................................................................................................27
Washing the OASIS cover....................................................................................................................................27
Post greasing procedure.......................................................................................................................................28
Chain lubrification procedure................................................................................................................................30

USER MANUAL CONGRATULATIONS 3
CONGRATULATIONS ON THE PURCHASE
OF YOUR NEW COVANA COVER
Thank you for choosing our product. The COVANA cover you have chosen is the result of excellent engineering,
attention to detail and a great deal of pride. With proper care and attention, your COVANA cover will last many
years and offer great performance.
Although our products are built to last, we strongly recommend that you register your COVANA cover at the time of
purchase to ensure an adequate follow-up process.
In fact, registering your COVANA cover allows us to quickly reach you in the unlikely event a safety notice was to
be issued. Your product and safety are a top priority for us at COVANA.
You will need your original sales receipt as proof of purchase to obtain warranty service and the work must be
performed by an authorized technician. If your COVANA cover were ever to malfunction, your product registration
will allow us to access necessary information in a timely manner.
Experience the benefits of registering your COVANA cover at www.covana.com/warranty.html.
Please take a few minutes to read all the instructions before you use your new COVANA cover. This user manual
will explain how your cover works, so you will get the most from your COVANA cover for many years.
For service and advice, do not hesitate to call your local authorized COVANA dealer.

4 SAFETY USER MANUAL
SAFETY
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE SAFETY INSTRUCTIONS AND
REVIEW THEM REGULARLY.
READ AND FOLLOW ALL INSTRUCTIONS
Safety information
The COVANA cover was designed, tested and
certified to be installed over a residential hot tub (spa)
and under important installation instructions issued by
COVANA. Any other type of usage will void the
warranty and product certification.
The extra load maximum weight provided in the
specification section of this manual is a provision for
environmental outcomes, such as some snow or
damp leaves that could accumulate on the cover, that
are evenly distributed on the surface of the cover.
The power safety cover meets ASTM F1346-91
requirements.
DANGER
To reduce the risk of injury, do not allow children
to use this product unless they are supervised at
all times.
Failure to follow all instructions may result in
injury or even death.
Do not allow people to climb on the cover at any
time.
Do not allow children to have access to the
COVANA cover without supervision.
Never operate the COVANA cover until all people
and objects are out of the spa.
Lower the COVANA cover in extreme wind
conditions such as gusts of 30 mph (50 km/h) in
the raised position and upwards of 45 mph
(70km/h) when completely lowered on the hot tub.
WARNING
Be sure to keep the key switch and the key out of
the reach of children.
Do not put any type of fabric or plastic sheet, such
as a tarpaulin, on the COVANA cover. This could
overheat the cover and result in deformation or
melting of the cover.
Inspect the cover periodically. It should raise
smoothly and evenly. Contact your COVANA
dealer if any unusual sound is heard during use.
Never use any type of pressure washer or buffer
to clean any surface of the COVANA cover. This
could result in premature wear or damage.
The key switch must be permanently mounted
and located 5 ft. (1.5 m) away from the spa and 5
ft. (1.5 m) above the deck or ground level. Ensure
the user has a clear view of the COVANA cover
when operating it. Furthermore, the key switch
terminal should be located in a place where no
water downpour or debris could fall on it. (Figure
1)
DO
Remove the control key after operating the
COVANA cover. Store the key in a secure
location when not in use. Users must bring the
control key in the hot tub with them to prevent
unauthorized operation of the cover.
Never leave the key in the key switch.
Check the cover frequently for signs of
deterioration.
Have any repairs, adjustments or mechanical
work performed by your authorized COVANA
dealer as soon as possible should you notice a
malfunction.
Close cover when not in use or if the hot tub is not
being monitored.
A COVANA cover should only be operated by an
adult.
This appliance can be used by children aged 8
years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge ONLY if they are
supervised or have received instructions
regarding safe use of the cover. Children must not
play with the appliance. Cleaning and user
maintenance must not be performed by children
without supervision.
Figure 1

USER MANUAL SAFETY 5
DO NOT
Operate the unit before all mechanical and
electrical connections are completed.
Step on or stack anything on the COVANA
operator cover.
Operate the COVANA cover while somebody is in
the hot tub.
Climb, walk or stand on the COVANA cover at
any time.
Leave the COVANA cover open for more than 12
hours. This could cause the cover to warp over
time.
Converge or directly reflect sunlight on the cover.
This could cause permanent damage.
Wash the cover with harsh chemicals or cleaners.
Use a pressure washer to clean any component
of the COVANA cover. This could result in
premature wear or damage.
Use an extension cord to connect the COVANA
cover to its power source. The cord may not be
properly grounded, and the connection is a shock
hazard. An extension cord may cause a voltage
drop, which would cause the motor to overheat.
CAUTION
Be sure to follow all instructions in this manual
and use only COVANA-approved accessories
and tools.
Do not roll the COVANA cover onto its side or
slide it on its side. This will damage the siding.
After removing any part, always place it in a safe
place on a clean and level surface to ensure
proper functionality.
All four posts of the COVANA cover must be
properly anchored to the foundation using the
anchoring holes located at the foot of each post.
The optional non-permanent mounting plates can
be used when anchoring is not possible, but
under strict condition. See Non-permanent
mounting plates installation section on Installation
Manual for further details.
This product mainly contains steel, plastic,
copper (Cu) and die-cast aluminum (Al). The
gearbox contains oil and other materials. Please
recycle them properly.
Avoiding the risk of electrocution
ELECTRICAL DANGER
Failure to comply with these instructions may
result in death by electrocution or serious injury.
Disconnect or turn off and secure all power
supplies before starting any intervention on the
COVANA cover.
Always have a licensed electrical contractor
perform any electrical maintenance or repairs on
the COVANA cover. The wiring must comply with
all applicable local electrical codes and
regulations.
The COVANA operator must be connected to a
circuit that is protected by a dedicated ground
fault circuit interrupter (GFCI) that complies with
all applicable local electrical codes and
regulations.
Install the COVANA cover in such a way that
drainage directs water away from the electrical
and base mechanical components.
Do not connect any auxiliary components to the
electrical system of the COVANA cover unless
they have been approved by COVANA.
Replace electrical components with original
components provided or approved by COVANA.
Ask your dealer for replacement parts.
To reduce the risk of electrical shock, replace all
damaged electrical cables immediately. Failure to
do so may result in death or serious personal
injury due to electrocution.
Do not bury any electrical cables. A buried cable
may result in death, or serious personal injury due
to electrocution if direct burial-type cable is not
used, or if improper digging occurs.
WARNING REGARDING DRUG OR
ALCOHOL USE
The use of drugs or alcohol while operating the
COVANA cover is strictly prohibited. The
impairment of judgement, vision or hearing might
affect the safety of other people or result in death.
WARNING REGARDING
MODIFICATIONS TO THE COVANA
COVER
Any modifications to the COVANA cover, such as
mechanical, electrical or aesthetic ones, may
cause the cover to operate in an unwanted or
dangerous way. Furthermore, these
modifications might void the warranty and
certification.
The COVANA cover was designed, tested and
certified for the sole purpose of covering and
securing a spa. Any installation that differs in
whole or in part from this purpose will void the
warranty and certifications.
SAVE THESE INSTRUCTIONS

6 LABELING USER MANUAL
LABELING
WARNING
Removing any labels from the COVANA cover will void product certification. All labels should always remain visible.
It is the owner’s responsibility to ensure that these labels are always visible and should never be removed.
Risk of electrocution warning, located on the
operator unit.
Specification label, located on the operator.
(European model)
Note: This label provides the serial number.
Key operating diagram, located on the key switch.
Specification label, located on the operator unit.
(North American model)
Note: This label provides the serial number.

USER MANUAL LABELING 7
Key switch warning, located on the key switch
Electrical information, located on the key switch cable.
Do not step symbol, located on top of the operator unit.

8 LABELING USER MANUAL
The COVANA cover is labeled on four exterior
and interior wall faces. If the labels are damaged
or no longer meet legibility requirements, please
obtain replacement labels by contacting
COVANA or your local COVANA dealer.
Drowning risk warning, found on the inside of the COVANA cover.

USER MANUAL GLOSSARY 9
GLOSSARY
Part
Figure
Function
All-weather seal
The all-weather seal will help protect sleeves from damage due to
weather.
Corner bracket
The corner bracket links the cover to the sleeves.
Operator
The operator powers and controls the lifting mechanism of the
COVANA cover.
Contour seal
The contour seal ensures uniform contact between the inner shell
and the hot tub. It prevents excessive water and other contaminants
from entering the spa. It also reduces heat loss.
Front frame cut-
out
The front frame cut-out gets installed under the front step of your
hot tub. It links the two non-motor-side posts.
Key switch
The key switch is used to operate the COVANA cover.
Figure2
Figure3
Figure4
Figure5
Figure7
Figure6

10 GLOSSARY USER MANUAL
Wire guard
(optional)
The wire guard is an assembly that will house a wire that comes
from the roof to light up the LED light kit on your OASIS cover. It
protects the wire from becoming overly taut and will release extra
wire if this happens.
CTS-70
(Continuous
tension system)
(optional)
The CTS-70 is in the roof of the Oasis cover. It keeps the wire
perfectly taut throughout the cover’s up and down cycle.
Sleeve
The sleeve is an aluminum case for the lifting mechanism.
Figure 8
Figure 9
Figure 10

USER MANUAL QUICK START-UP INSTRUCTIONS 11
QUICK START-UP
INSTRUCTIONS
Ensure that your COVANA cover was properly
installed by an authorized COVANA installer; this
includes the location of the cover (see the Location
considerations section of installation manual), the
foundation of the cover (see the Foundation
preparation section of installation manual) as well as
the electrical installation of the cover (see the
Electrical hook-up section of installation manual).
Please read carefully the Safety section of this
manual before operating the COVANA cover.
1) Ensure all debris and snow are removed from the
top of the COVANA cover before operating.
2) Ensure there is nobody in the spa or near the spa,
when raising or lowering the cover.
3) Ensure there is no obstruction over or around the
COVANA cover.
4) The key must be held in the proper position until
fully opened or closed.
5) The COVANA cover will automatically stop in
both fully open and fully closed position.
6) Turn the key clockwise to raise the cover.
7) Turn the key counterclockwise to lower the cover.
8) The key will automatically return to center/off
position when released.
9) Remove the key when finished operating the
COVANA cover. Store the key in a secure place.
WARNING
Users must bring the control key in the hot tub
with them to prevent any unauthorized
operation of the cover
10) Place the rubber cap back on the key switch after
each use.
Important: Keep the cover fully closed when not in
use.

LED LIGHT KIT (OPTIONAL)
USER MANUAL
12
LED LIGHT KIT (OPTIONAL)
To operate the COVANA light system, press on the light switch located under the cover in one of its corners. The
COVANA lights can operate in two different modes. You can select the mode by switching the lights off and
immediately back on.
The COVANA light system has two sequenced modes:
Color locked
Color wheel
Always turn the lights off when not in use.

USER MANUAL MANUAL LIFTING PROCEDURE 13
MANUAL LIFTING
PROCEDURE
ELECTRICAL WARNING
Disconnect or turn off and secure all power
supplies before starting any intervention on the
COVANA cover.
1) Disconnect or turn off and secure the power
supply.
2) Remove the four screws at the bottom of the
operator cover and take the cover off. (Figure
11)
3) Use ½”(13 mm) hexagonal socket wrench to
raise or lower the COVANA cover by turning the
operator’s input shaft. (Figure 12)
4) Slowly turn the shaft. Stop immediately if higher
tension is felt.
WARNING
Never use a power tool, as this will damage the
unit.
5) Turn the input shaft clockwise to lower the roof
and counter clockwise to raise the roof.
WARNING
Do not exceed the limits of the mechanism.
Failure to respect this guideline could cause
mechanical failure.
6) Reinstall the operator cover with the four
screws. (Figure 11)
7) Reconnect and turn on the power supply.
Figure 12
Figure 11
Cover
Operator
Screws

WIRE GUARD REASSEMBLY
USER MANUAL
14
WIRE GUARD
REASSEMBLY
(OPTIONAL)
You might need to reassemble your wire guard
harness if the magnetic plate (Figure 16) came off to
let the wire out. The wire guard is located on the inside
of the posts. It is on the opposite side of the light
switch at the bottom of the post.
The function of the wire guard is to protect the
wire from excessive strain. The main causes for
the magnetic plate to come off are the wire getting
caught, ice buildup around the roof or someone
catching or pulling on the wire.
We recommend following the steps below for
properly reassembling the wire guard assembly.
WARNING
Failure to follow these guidelines could impede
designed performance or could cause
mechanical failure.
1) Locate the wire guard. Check if the wire has not
been damaged (cuts in wire, disconnected etc.)
(Figure 13)
2) Fold wire in two by making a loop with your
hands. The length of the loop must be
approximately 20 in. (50 cm) long (Figure 14).
3) While still holding the loop, thread the wire in the
wire guard. All of the wire loop must be threaded
into the wire guard (Figure 15).
WARNING
Do not attempt to tape or fix the wire together by
any means. The wire guard is designed to
function as shown.
Ensure the wire is not caught in the post or
twisted around any other object before
proceeding.
Make a 20 in.
(50 cm) loop
Figure 14
Figure 15
Figure 13

USER MANUAL WIRE GUARD ASSEMBLY 15
4) Put the plate back on top of the wire guard. There
are two magnets that will hold the plate in place
(Figure 16). The wire should have sufficient
tension and stand straight. Please ensure the
wire is not caught or twisted around the post.
5) Once the plate is installed, the assembly should
look as shown in Figure 16. The wire should have
sufficient tension and look straight. Please ensure
the wire is not caught or twisted around the post.
6) Operate the OASIS cover by cycling it up and
down. If the plate still comes off due to excessive
tension, consult the Troubleshooting section or
call your local COVANA dealer
Figure 16
Magnetic plate
Wire guard

16 WINTERIZING USER MANUAL
WINTERIZING THE OASIS COVER
If you plan on winterizing your hot tub during the cold season, COVANA recommends winterizing the
COVANA cover as well. This process prevents any potential aesthetic damage done to your COVANA cover
and minimizes the risk of freezing water damage to the tub. Please follow these instructions:
WARNING
These instructions are relevant for anyone who plans to stop using the hot tub for a long period of time,
particularly if the temperature goes below 32° F (0° C).
1) Clean the COVANA cover completely to remove any dust, greasy residue or any other foreign
contaminants.
2) Prepare the hot tub for closure by following the spa manufacturer's winterization instructions.
3) Completely close the COVANA cover on the hot tub. Ensure the seal touches the whole perimeter of
the tub.
4) Remove the power from the COVANA cover.
oThis can be done by shutting off and securing the circuit breaker powering the COVANA cover;
5) For areas with a large seasonal snowfall, remove excessive snow accumulation regularly or after a
heavy snowfall to avoid damage to the structure of the COVANA cover. Do not let the snow accumulate
more than 12’’ (30 cm) on the COVANA cover.

USER MANUAL PERIODIC MAINTENANCE TABLE 17
PERIODIC MAINTENANCE TABLE
Your COVANA Cover was designed to provide years of trouble-free enjoyment. As with any appliance, problems
may occasionally occur that require the expertise of an authorized COVANA service technician. Before calling for
service, please refer to the Troubleshooting section. Always retain your original sales receipt for future reference.
Tasks
Frequency
Each Use
Weekly
3 months
Yearly
As needed
Perform a visual inspection
(debris, snow, ice, etc.)
x
Check that the sleeves are
correctly positioned. (Middle
sleeves are not out of place)
x
Check that all-weather seals
are correctly positioned (in
contact with the outer sleeves
when the cover is closed).
x
Listen for unusual sounds
during operation.
x
Check the seal around the
COVANA cover. (no vapor
leakage)
x
Check the lifting mechanism
by raising and lowering the
COVANA cover.
x
Check the anchoring of the
COVANA cover.
x
Test the GFCI.
x
Check the tension of the
chains on all posts and in the
u-frame. *
x
Lubricate chains on all posts
and in the u-frame. *
x
Grease the jack assemblies. *
x
Wash the cover with a mild
detergent (i.e. dishwashing
detergent) and water. Rinse
well using only water.
x
*Contact your local dealer
Please call your COVANA dealer for any mechanical, electrical or aesthetic maintenance.

18 TECHNICAL SPECIFICATIONS USER MANUAL
TECHNICAL
SPECIFICATIONS
Side elevation
Figure 17
22 7/8” (57 cm)
The hot tub must fit within these
height specifications:
Min: 34” (86 cm)
Max 48” (122 cm)
Maximum
overall height:
115”(292 cm)

USER MANUAL TECHNICAL SPECIFICATIONS 19
Frame and foot print
Figure 18
**NOT TO SCALE**
Standard model

20 TECHNICAL SPECIFICATIONS USER MANUAL
Figure 19
**NOT TO SCALE**
Long side (LS) model
