LINSY HOME LH027X3 User manual

LH027X3
ASSEMBLY INSTRUCTIONS - please keep for future reference.
IMPORTANT - please read these instructions before assembly.

General care and maintenance.
Important – Please read these instructions fully before starting assembly.
Please clean with a damp cloth or mild detergent, do not use bleach or abrasive cleaners.
Do not allow the spill to stay on the surface for a long time.
Do not clean with products containing the following: acetone (e.g., nail varnish remover), ammonia
(e.g.bleach), or sodium hydroxide(e.g., caustic soda, drain, and oven cleaners).
If the product is accidentally exposed to the irritating liquid, rinse thoroughly with clean water.
Mats can be used to protect surfaces from moisture and heat.
Please check whether there are missing screws in the product regularly.
The product should not be discarded with household waste, and please take it to your local authority
waste disposal center.
Please check if all the components and tools listed
on pages 3 - 4 are received.
Please remove all fittings from the plastic bags and
separate them into homologous groups.
Please keep children and animals away from the
working areas; swallow small parts may cause
suffocation.
Please make sure you have enough space to lay
out the parts before starting.
Do not stand on the product, which could cause
damage.
Please assemble the product as close toits
final position as possible.
Do not place furniture directly in front of
radiators, fires, or any other source of heat.
The assembly will be easier with 2 people.
Please dispose of all packaging carefully and
responsibly.
Safety And Care Advice
2

Components
Please check if all the pieces listed below are received.
3
(A)*46 (B)*46 (C)*2 (D)*12
(E)*30 (F)*1 (G)*16 (H)*16
Two-in-one Screws Two-in-one Cam
(Diameter 15mm) White furniture anchors L-shaped shelf support
Wood Tenon
(diameter 8*30mm) Dual-function Screwdriver Back Plate Buckle Self-tapping screws
(M3*17mm)
(I)*2
Self-tapping screws
(M3*12mm)

Components
Please check if all the pieces listed below are received.
4
Parts list
Number Description Specifications
（MM）
Quantity Material
Top Panel 400*300*15 Melamine Faced Boards1
1
Upper-Left Panel 920*299*15 Melamine Faced Boards1
2
Upper-Right Panel 920*299*15 Melamine Faced Boards1
3
Top Backplane 879*378*3 Melamine Faced Boards1
4
Top/Middle
Decoration Stripe 368*40*15 Melamine Faced Boards2
5
Back Brace 368*50*15 Melamine Faced Boards1
6
Adjustable Shelves 362*268*15 Melamine Faced Boards3
7
Adjustable Shelf
Decoration Stripes 363*40*15 Melamine Faced Boards3
8
Panel 400*300*15 Melamine Faced Boards1
9
Lower-Left Panel 800*299*15 Melamine Faced Boards1
10
Lower-Right Panel 800*299*15 Melamine Faced Boards1
11
Lower Backplane 730*378*3 Melamine Faced Boards1
12
Lower
Decoration Stripe 368*80*15 Melamine Faced Boards1
14
Bottom Panel 368*283*15 Melamine Faced Boards1
13
Back Bottom Brace 368*50*15 Melamine Faced Boards1
15
Upper Back Brace 368*64*15 Melamine Faced Boards1
16

6
4
2
3
1
7
8
X3
9
10
11
12
13
15
14
16
Product explosion diagram
Please check if all the pieces listed below are received.
5

Step 2
Step 1
Assembly Instructions
(A)*22 (E)*15 (F)*1
6
Assembly Instructions
Please use the screws correctly, otherwise the product will be seriously damaged!
(E)*3 (F)*1 (B)*6
7
8
B
X3
14
15
8
13
1
6
9
x2
x3

Step 4
Step 3
Assembly Instructions
7
(F)*1 (B)*2
(F)*1 (B)*2
B
14
13
15
13
B

(A)*10 (E)*4 (F)*1
Step 6
Step 5
Assembly Instructions
8
(F)*1 (B)*5
10 11
10
13

Step 8
Step 7
Assembly Instructions
9
(F)*1 (B)*5
11
13
10
12

Step 10
Step 9
Assembly Instructions
10
(A)*6
(F)*1
(F)*1 (B)*6
9

(A)*8 (E)*8 (F)*1
Step 12
Step 11
Assembly Instructions
(F)*1 (B)*4
11
23
2
16

(F)*1 (B)*4
Step 14
Step 13
Assembly Instructions
12
3
4

Step 16
Step 15
Assembly Instructions
(B)*6 (F)*1
13
(B)*6 (F)*1

Step 18
Step 17
Assembly Instructions
14
(G)*16 (H)*16 (F)*1 (I)*2
(D)*12
1 2 3
GH
GH
GH
GH
GH
GH
GH
GH
GH
GH
GH
GH
GH
GH
GH
GH
W
I

Step 19
Assembly Instructions
15
7

Step 20
Assembly Instructions
16

(C)*2 (F)*1
Step 21
Assembly Instructions
17
V
V
The Wall
Large View at V
The installation is complete.

Step 22
Assembly Instructions
18
