Lionel 87-1811020 User manual

8071811010250
8/18
Lionel HO Scale
Berkshire Passenger Set
Owner’s Manual
Lionel HO Scale
Berkshire Passenger Set
Owner’s Manual
CAUTION—ELECTRIC TOY
NOT RECOMMENDED FOR CHILDREN UNDER FOURTEEN YEARS OF AGE. AS WITH ALL ELECTRIC
PRODUCTS, PRECAUTIONS SHOULD BE OBSERVED DURING HANDLING AND USE TO PREVENT
ELECTRIC SHOCK.
TRANSFORMER RATINGS—INPUT: 100-240 V , 50/60 Hz.
OUTPUT: 12 VDC

2
This device complies with Part 15 of the FCC Rules and with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2)
This device must accept any interference received, including interference that may cause undesired operation.
Contains
FCC ID: 2AH7AKW2541A
IC: 21416-KW2541A”
LionChief™ Remote control
The LionChief remote control is used to operate the locomotive. Easy to use, and with
many enhanced features including a wider range of realistic sounds, such as chuff sounds
and three buttons on the control to activate user-controllable announcements and engine
sounds. Long-distance control and multi-engine operation on one layout are in your grasp
with the LionChief remote control system.
LionChief®Bluetooth®
Incorporating Bluetooth technology into Lionel model trains opens a new world, inte-
grating the tradition of model railroading with the latest smart-device technology.
With Lionel’s new LionChief app, you can control full operation and sounds directly
from your Bluetooth-enabled smart phone or tablet and operate multiple locomo-
tives from the same device. LionChief is available to smartphone users and is
compatible with all new 2017 LionChief, LionChief Plus, S-Gauge, and HO Trains.
Thank You!
Thank you for your purchase of the Lionel HO Berkshire Passenger Set! This set is designed to oper- ate on any HO track system with a minimum curve radius of 20 inches. You can power your train
with the included wall-pack power supply, a conventional DC transformer, or a DCC system up to 14
Volts. The LionChief remote control included will work with or without a DCC signal on the rails.
FCC Statement
The following Lionel marks are used throughout this Owner’s Manual and are protected under law. All
rights reserved.
Lionel®, LionChief™, MagneLock™
The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth
SIG, Inc. and any use of such marks by Lionel is under license. Other trademarks and
trade names are those of their respective owners.
Apple and the Apple logo are trademarks of Apple Inc., registered in the U.S. and other
countries. Mac App Store is a service mark of Apple Inc.
Google Play and the Google Play logo are trademarks of Google Inc.

3
Operating your wall-pack power supply safely 4
Joining the MagneLock track sections 5
Connecting your wall-pack power supply 5
Locomotive control switches 6
Using the LionChief remote control 7-8
Coupling 8
Remote control features 9
Resetting the locomotive to factory settings 10
Using another Bluetooth®device 10
Connecting to your LionChief, LionChief Plus, or FlyerChief locomotive on Apple devices 11
What if my Bluetooth enabled engine didn’t automatically connect? 12
Connecting to your LionChief, LionChief Plus, or FlyerChief locomotive on Android devices 13
Running Your Locomotive 14
Settings 15
Volume Control 15
Switching Connection Between Multiple Bluetooth®Locomotives 16
Troubleshooting 16
The LionChief Universal Remote (6-83071) 17-18
Adjusting the locomotive volume using the Universal Remote 19
Pairing locomotives to the Universal Remote 20
Operating locomotives with the Universal Remote 21-22
Using a conventional transformer 23
Controlling your locomotive with DCC 24
Changing decoders 25
Advanced DCC programming 26-27
Compatibility & limitations 28-29
Lubricating your locomotive 30-31
Cleaning 32
Servicing your locomotive’s LEDs 32
Servicing your passenger car LEDs 32
Storing your locomotive 33
Wall-pack power supply 34
FCC Statement 35
Lionel Limited Warranty Policy & Service 36
Table of Contents

4
Operating your wall-pack power supply safely
Your Lionel wall-pack power supply is listed by Underwriter’s Laboratory Inc. and has been carefully designed to ensure peak performance. When using electrical products, basic safety
precautions should be maintained.
Be sure to observe the following guidelines:
• Read the manual thoroughly before using this device.
• This device is not recommended for children under fourteen years of age.
• Parents should periodically inspect this product for potential hazards and, if necessary, have them
repaired by a Factory Trained Authorized Lionel Service Station. In the event that such a condition
exists, the transformer should not be used until it has been properly repaired.
• The wall-pack power supply is intended to be used indoors. Do not use this device if water is
present. Serious or fatal injuries may result.
• Use the wall-pack power supply only for its intended purpose.
• The wall-pack power supply was designed to operate on 100-240 volt AC, 50/60-Hertz power. Do
not connect this product to any other power supply.
• Do not operate the wall-pack power supply with a damaged cord, plug, or case.
• To avoid the risk of electrical shock, do not disassemble the unit. There are no user serviceable
parts inside. If damaged, take this product to a Factory Trained Authorized Lionel Service Station.
Visit www.lionel.com for a list of authorized Service Centers.
• Do not operate the wall-pack power supply on your layout unattended. Obstructed accessories or
stalled trains may overheat, resulting in damage to your layout.
• Always unplug the wall-pack power supply from the power source when not in use.
• Never insert objects into the ventilation slots on this product. Damage to sensitive
electronic components can result.

5
Joining the MagneLock track sections
Lionel's MagneLock Track allows you to assemble your track in seconds! Just hold the pieces near each other and magnets will align and hold the sections together. Metal rail joiners are not neces-
sary between the sections as the connectors in the roadbed will transfer power. If you would like to add
these connectors for extra alignment and conductivity, or if you would like to join MagneLock Track
to other HO tracks, simply break away the alignment tabs on the ends of the rails and insert the rail
joiners. Lionel HO MagneLock Track is compatible with HO code 83 rail track from other manufac-
turers.
While not necessary, if you would like to fasten your track permanently to a platform, small holes
are provided in the roadbed for nails. Metal tabs on the underside of the roadbed can be used to solder
additional feeder wires if desired.
Figure 1. Joining the track sections
Figure 2. Wall-pack power supply connection
Connecting your wall-pack power supply
Your trains are powered by a DC wall-pack power supply. To power the track, simply plug the wall-pack into an outlet and plug the jack into the terminal section as shown in Figure 2.
Jack on wall-pack
power supply
Terminal track section
