Lippert On-the-Go 12.5 Installation instructions
1
lippert.com 432-LIPPERT (432-547-7378) Rev: 04.05.22
On-the-Go™12.5 and
14.5 Foot Ladder
(Designed for use with the
On-the-Go™Prepped Receiver)
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006260
Table of Contents
Introduction ............................................ 2
Safety ................................................... 2
Parts List ................................................ 2
Operation ............................................... 3
Overview ............................................... 3
Extending and Retracting the Ladder .................. 4
Installing Ladder on Receiver .......................... 5
Essential Ladder Operation Safety ..................... 5
Storage and Maintenance .............................. 6
Notes .................................................... 6
On-the-Go™12.5
and 14.5 Foot
Ladder
(Designed for use
with On-the-Go
™
Prepped Receiver)
Installation and
Owner’s Manual
(For Aftermarket Applications)
On-the-GoOn-the-Go™™Ladder Aftermarket KitsLadder Aftermarket Kits
Kit #Kit # DescriptionDescription
2021097938 On-the-Go Ladder - 12.5
2021126697 On-the-Go Ladder - 14.5
NOTE: Aftermarket kits contain ladder with attached
mounting hanger and warning labels.
2
lippert.com 432-LIPPERT (432-547-7378) Rev: 04.05.22
On-the-Go™12.5 and
14.5 Foot Ladder
(Designed for use with the
On-the-Go™Prepped Receiver)
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006260
On-the-GoOn-the-Go™™Ladder Prepped Kit —2021097938Ladder Prepped Kit —2021097938
LetterLetter PNPN DescriptionDescription QtyQty
A 2021097937 12.5 ft Ladder assembly with
attached attached mounting
hanger and warning labels
1
Introduction
The On-the-Go Ladder is a fully-adjustable and collapsible
ladder with safety locks at each rung for extra security. The
Ladder is designed to be used only with the OEM-installed
On-the-Go Receiver.
Additional information about this product can be obtained
from lci1.com/support or by using the LippertNOW app.
Replacement kits can be ordered from https://store.lci1.
com/ or by using the LippertNOW app.
The LippertNOW app is available for free on the Apple App
Store®for iPhone®and iPad®and also on Google Play™for
Android™users.
Apple App Store®, iPhone®, and iPad®are registered
trademarks of Apple Inc.
Google Play™and Android™are trademarks of Google Inc.
Safety
Read and fully understand all instructions before installing
or operating this product.
Adhere to all safety labels.
Parts List
NOTE: Part numbers are shown for identification purposes
only. Not all parts are available for individual sale. All parts
with a link to the Lippert Store can be purchased.
THE “WARNING” SYMBOL ABOVE IS A SIGN THAT
AN INSTALLATION PROCEDURE HAS A SAFETY
RISK INVOLVED AND MAY CAUSE DEATH, SERIOUS
PERSONAL INJURY, SEVERE PRODUCT AND/OR
PROPERTY DAMAGE IF NOT PERFORMED SAFELY
AND WITHIN THE PARAMETERS SET FORTH IN THIS
MANUAL.
THE “CAUTION” SYMBOL ABOVE IS A SIGN THAT A
PROCEDURE HAS A SAFETY RISK INVOLVED AND
MAY CAUSE PERSONAL INJURY, PRODUCT AND/OR
PROPERTY DAMAGE IF NOT PERFORMED SAFELY
AND WITHIN THE PARAMETERS SET FORTH IN THIS
MANUAL.
THE “DANGER” SYMBOL ABOVE IS A SIGN THAT
IMPROPER OPERATION HAS A SAFETY RISK
INVOLVED AND MAY CAUSE DEATH, SERIOUS
PERSONAL INJURY, SEVERE PRODUCT AND/OR
PROPERTY DAMAGE IF NOT PERFORMED SAFELY
AND WITHIN THE PARAMETERS SET FORTH IN THIS
MANUAL.
A
On-the-GoOn-the-Go™™Ladder Prepped Kit —2021126697Ladder Prepped Kit —2021126697
LetterLetter PNPN DescriptionDescription QtyQty
A N/A 14.5 ft. Ladder assembly with
attached mounting hanger and
warning labels
1
3
lippert.com 432-LIPPERT (432-547-7378) Rev: 04.05.22
On-the-Go™12.5 and
14.5 Foot Ladder
(Designed for use with the
On-the-Go™Prepped Receiver)
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006260
Operation
locked
lock button
unlocked
full retraction full extension
Fig.1
Fig.2
Fig.3
Overview
Each ladder rung is extended and retracted via telescoping
rails held in place by locks and operated by sliding the lock
buttons (Fig.1).
Sliding the button away from the rail disengages the lock.
Sliding the button towards the rail engages the lock (Fig.2).
The ladder can be fully retracted when the ladder is being
stored, or fully extended during use if the full height of the
ladder is required (Fig.3).
NOTE: The ladder can be used under a partial extension
in the event that the full ladder height is not needed. Care
should be taken to ensure that rung spacing is even to
avoid potential for tripping, or else group unused rungs at
either the top or the bottom of the ladder.
lock buttons
REMOVE AND STOW THE LADDER PRIOR TO
TRAVEL. FAILURE TO PROPERLY REMOVE AND
STOW THE LADDER COULD RESULT IN PERSONAL
INJURY OR PROPERTY DAMAGE.
4
lippert.com 432-LIPPERT (432-547-7378) Rev: 04.05.22
On-the-Go™12.5 and
14.5 Foot Ladder
(Designed for use with the
On-the-Go™Prepped Receiver)
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006260
Fig.4
Fig.5 Fig.6
Extending and Retracting the Ladder
1. Disengage both lock buttons on the rung (Fig.4).
2. Fully extend or retract the rung (Fig.5).
3. Engage the lock buttons (Fig.6).
NOTE: Lock buttons cannot be engaged if the rung is not
fully extended or retracted.
MOVING PARTS CAN PINCH, CUT, AND CRUSH.
KEEP HANDS OFF MOVING PARTS AT ALL TIMES
AND EXERCISE CAUTION WHEN EXTENDING OR
RETRACTING THE LADDER.
MAKE SURE ALL LOCK BUTTONS ARE IN THE
“LOCK” POSITION PRIOR TO ASCENT OR
DESCENT. UNLOCKED LOCK BUTTONS MAY CAUSE
INSTABILITY AND COULD LEAD TO A FALL.
5
lippert.com 432-LIPPERT (432-547-7378) Rev: 04.05.22
On-the-Go™12.5 and
14.5 Foot Ladder
(Designed for use with the
On-the-Go™Prepped Receiver)
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006260
Essential Ladder Operation Safety
FALLS FROM A LADDER FROM ANY HEIGHT CAN
LEAD TO DEATH OR SERIOUS PHYSICAL INJURY.
OBEY SAFETY MEASURES AND DO NOT USE
THE LADDER FOR ANYTHING OTHER THAN ITS
INTENDED USE.
• Do not exceed the 330 lb. (150 kg) maximum weight
capacity of the ladder.
• Only 1 person at any given time should be on the ladder.
• Ensure all lock buttons are in the “lock” position prior to
using ladder (Fig.6).
• Position the ladder only on level, stable ground that will
not shift or sink under use.
• Do not overreach. Keep torso between the side rails at all
times.
• Always face the ladder when ascending or descending.
• Equipment carried up and down the ladder should be
manageable and easy to handle.
75°
Fig.7
Fig.8
1. Extend the ladder to full height.
2. Insert the attached mounting hanger of the ladder into
the slots on the receiver (Fig.7).
MAKE SURE LADDER IS FULLY SEATED IN THE
RECEIVER BEFORE USE. IF ALL THE LADDER
TREADS ARE NOT FULLY EXTENDED, USE CAUTION
ASCENDING AND DESCENDING AS LADDER RUNG
SPACING WILL NOT BE AS UNIFORM AS EXPECTED.
Installing Ladder on Receiver
3. Pull down on ladder to make sure the mounting hanger
is fully inserted into the receiver.
4. Put feet of the ladder on the ground. Ladder should
be at an angle. The optimal angle for use of the ladder is
approximately 75 degrees (Fig.8). Retract rungs starting
from the bottom if angle needs adjustment.
6
lippert.com 432-LIPPERT (432-547-7378) Rev: 04.05.22
On-the-Go™12.5 and
14.5 Foot Ladder
(Designed for use with the
On-the-Go™Prepped Receiver)
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006260
Storage and Maintenance
The ladder comes with a Velcro strap (Fig.9) for storage
when the ladder is not in use.
Fig.9
velcro strap
Notes
Regularly inspect the receiver and ladder for any signs of
wear over time that may affect the safety or the stability of
either component.
8
lippert.com 432-LIPPERT (432-547-7378) Rev: 04.05.22
On-the-Go™12.5 and
14.5 Foot Ladder
(Designed for use with the
On-the-Go™Prepped Receiver)
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006260
Manual information may be distributed as a complete
document only, unless Lippert Components provides
explicit consent to distribute individual parts.
All manual information is subject to change without
notice. Revised editions will be available for free
download at lippert.com. Manual information is
considered factual until made obsolete by a revised
version.
Please recycle all obsolete materials and contact
Lippert Components with concerns or questions.
