Liquid LEDs String Lights User manual
SAFETY INFORMATION
When using electrical products, basic precautions should always be followed,
including the following:
• Do not mount or place near gas or electric heaters, fireplace, candles, or other similar
heat sources.
• Do not secure the product's wiring with staples or nails or place it on sharp hooks or
nails.
•Do not let lamps rest on the supply cord or on any wires.
•Do not hang objects from the cord, wire, or light string.
•Do not use this product for other than its intended use.
•Do not close doors or windows on the product or extension cords as this may damage
the wire insulation.
•Do not cover the product with cloth, paper or any material not part of the product when
in use.
•Read and follow all instructions on the product or provided with the product.
•Ensure the power cord is unplugged before installing, connecting, or when replacing the
light bulbs.
• Do not replace the light bulbs during rain or when the string light is wet.
Ensure to read all instructions and warnings in this user guide before first use. Retain
this user guide for future reference.
www.liquidleds.com.au 02 8880 9033
IMPORTANT SAFETY INSTRUCTIONS
!
2
СAUTION: RISK OF ELECTRIC SHOCK
Do not use extension cord near water or where water may accumulate.
Keep lamps at least 16 feet (4.88m) from pools and spas.
Keep plugs and receptacles dry.
Do not submerse.
!
!WARNING: RISK OF ELECTRIC SHOCK
Disconnect power at the source prior to wiring,
re-lamping or servicing in any way. The light string kits
are supplied with an two prong plug that will
only fit into a Australian outlet. Do not alter the plug.
3
www.liquidleds.com.au 02 8880 9033 3
Connecting String Lights
String Light Additional String Light
Connect to String Light
(if connecting two or more)
Tightly cap female end if not
connecting multiple string lights,
or last set of connected string lights.
65
IP 65
240V
IP
65
IP
Connecting Multiple Sets:
Add the wattage of each light bulb together for a total of 2000 Watts or less.
When multiple connecting sets protect connection(s) from direct exposure to rain and
water. Do not allow connection(s) to become wet.
3
www.liquidleds.com.au 02 8880 9033 4
Installation
Maintenance
Periodically clean the string light, check connections and ensure no additional weight has been
added.
Troubleshooting
The lights will not turn on.
The fuse blows, or the
circuit breaker trips, when
the light is turned on.
PROBLEM POSSIBLE CAUSES SOLUTION
The bulb is burned out.
The power is off.
There is a faulty switch.
There is a faulty wire connection.
The bulb is not making contact with
the terminal.
There are crossed wires, or the
power wire is grounding out.
The receptacle circuit is overloaded.
Replace the light bulb.
Ensure the power supply is turned on.
Test or replace the switch.
Check the wiring.
Check position of terminal inside socket.
Discontinue use of the light string.
Contact a qualified electrician
Connect to a different receptacle circuit.
Installation Methods
Attach guide wire
to structural support
Attach guide wire
to structural support
Guide Wire
(Not included)
S-Hooks or
cable ties ( included )
Using a guide wire with S-hooks or cable ties
1
Attached to a structure
2
Structural
Support
Structural
Support
Structural
Support
Attach to structural
support
Minimum every 6meters
Screw
Hook
Screw
Hook
Screw
Hook
Attach to structural
support
Minimum every 6meters
NOTE: If certain bulbs will not light, unplug the string light from the outlet and check the contact inside the socket
(brass contact at the center of the socket). It may be necessary to raise the contact point somewhat to ensure
eliable contact with the base of the bulb. Ensuring power is off, bend the contact upwards with a
small flat-head screwdriver (no more than 25-30 degrees).
