Saxby Lighting Axial Rectangular User manual

www.saxbylighting.com
Instruction manual
78542
Axial Rectangular
We recommend cleaning with a soft dry cloth. Do not use solvents or abrasive cleaners as these could damage the finish.
For your safety, always switch off the power supply before cleaning.
Care and Safety
Technical data
220-240 V~, 50 Hz
Supply
Voltage:
Bulb
Type:
35W LED module (COB), 4000K
Conformity with all relevant EC Directive requirements.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or local store for recycling advice.
This product is not suitable for dimming.
Wiring
• You have correctly identified the wires.
• The connections are tight.
• No loose strands have been left out of the
connection block.
Check that...
This LED's are protected by a shade. The shade part must be replaced immediately should
it become cracked or damaged. This fitting must not be used without the shade in place.
Replace Cracked Shade
Conformity with all relevant UKCA Directive requirements.
This product contains a light source of energy efficiency class F.
Non-replaceable light source Replaceable control gear by a
professional
For further information, please visit https://www.lighting-info.co.uk/78542
V2 10/06/2022
EU Manufacturer: Brilliant AG,
Brilliantstrasse 1, D-27442 Gnarrenburg
UK Manufacturer: BH17 7BY
NEUTRAL
SWITCHED LIVE
BLUE (N)
BROWN (L)
SUPPLY LIGHT FITTING
Having correctly identified the wiring from your existing light fitting, pull the mains wire through the hole and connect
to the connection block inside the LED driver in the following way:
This unit is double insulated and must not be earthed. If there are any incoming earth cables, they must be joined together
and well insulated with good quality insulation tape. This is to ensure earth continuity throughout your property.
The power supply is Double Insulated and does not require connection to an Earth circuit.

Plan the desired layout of this fitting carefully, ensuring the cables will reach the distance between the junction box
and the light fitting.
Avoid locating any cables in positions that would cause a hazard. Position cables and outdoor rated junction
boxes (not supplied) away from areas where they may be at risk from being cut, trapped or damaged.
The mains supply cable must have a minimum cross section area of 1.0mm2.
Cables must be protected using suitable conduit or plastic trunking.
This power supply is double insulated and does
not require connection to an Earth circuit.
Warning
Please read these instructions carefully before commencing any work.
This unit must be fitted by a competent and qualified electrician.
Install in accordance with the IEE Wiring regulations and current Building Regulations.
Check the pack and make sure you have all the parts listed.
To prevent electrocution switch off at the mains supply before installing or maintaining this fitting. Ensure other persons cannot
restore the electrical supply without your knowledge. If you are in any doubt, please consult a qualified electrician.
If replacing an existing fitting, make a careful note of the connections.
Take care not to drill into any pipes or mains cables beneath the surface during mounting holes preparation.
This light fitting must be connected to a fused circuit.
This system contains non-replaceable parts and cannot be serviced. If damage occurs the part should be scrapped.
The external flexible cable or cord of this luminaire cannot be replaced. If the cord is damaged the luminaire must be destroyed.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with
your local authority or retailer for recycling advice.
Thank you for purchasing this light fitting. Please read the instruction carefully before use to ensure safe and satisfactory
operation of this product. Please retain these instruction for future reference.
Installation
Existing fittings must be completely removed before installation of a new product. Before removing the existing fitting, carefully
note the position of each set of wires.
Note that the power needs to be isolated/switched off at the fuse board.
Layout
• The ceiling surface must be flat and smooth to ensure a good fit.
• The minimum ceiling void depth is 110mm. when more than one downlight is installed, the minimum distance between
units is 500mm. the unit must be located a minimum distance of 50mm from a joist.
• Plan the desired layout of these fittings carefully, ensuring the cables will reach the distances between the LED Driver and
each light fitting. Ensure that there is adequate ventilation for the LED Driver.
• Cut a mounting hole 130 x 220mm in the ceiling taking care not to foul any pipes, mains cables or joists beneath the surface.
• It is always recommended to cut the hole slightly smaller than the size specified, and then file the hole until the recessed
unit fits snugly.
• Push the spring clips upwards and fit into the ceiling hole, then push the unit up until firmly in position, ensuring that no
cables are trapped.
• Ensure that the product is sitting properly in the hole.
• It can also be used as a wall light, using the supplied screws to mount the light on the wall. See Fig 2.
• Replace fuse or circuit breaker and switch on. Your light is now ready for use.
Fig 1. (Recessed) Fig 2. (Wall)
See wiring
2
3
4
5
130 X 220mm
As a wall light, it is recommended
to stick the drive on the back
of the product.
1
