Litex E-PD52WW5C User manual

PRINTED IN CHINA
Table of Contents:
Safety Tips. pg. 1
Unpacking Your Fan. pg. 2
Parts Inventory. pg. 2
Installation Preparation. pg. 3
Hanging Bracket Installation. pg. 3
Fan Assembly. pgs. 4 - 5
Wiring. pg. 6
Canopy Assembly. pg. 6
Blade Assembly. pg. 7
Light Kit Assembly (Optional). pgs. 7- 8
Testing Your Fan. pg. 8
Troubleshooting. pg. 9
Warranty. pg. 9
Parts Replacement. pg. 9
Installation Guide
For Model:
E-PD52WW5C
net weight of fan: 18.52 lb. (8.4 kg)
E124404
READ THESE INSTRUCTIONS AND
SAVE THEM FOR FUTURE USE
Federal regulations require all ceiling
fans with light kits manufactured or
imported after January 1, 2009, to limit
total wattage consumed by the light kit
to 190W. Therefore, this fan is equipped
with a wattage limiting device.

SAFETY TIPS.
page 1
WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit
panel before you begin the fan installation or before servicing the fan or installing accessories.
1. Read all instructions and safety information carefully before installing your fan and save these instructions.
CAUTION: To avoid personal injury, the use of gloves may be necessary while handling fan parts with sharp
edges.
2. Make sure all electrical connections comply with Local Codes or Ordinances and the National Electrical
Code. If you are unfamiliar with electrical wiring or if the house/building wires are different colors than
those referred to in the instructions, please use a qualified electrician.
3. Make sure you have a location selected for your fan that allows clear space for the blades to rotate, and at
least seven (7) feet (2.13 meters) of clearance between the floor and the fan blade tips. The fan should
be mounted at least thirty (30) inches (76 centimeters) from walls or other upright structures.
4. The outlet box and ceiling support joist used must be securely mounted, and capable of supporting at
least 35 pounds (16 kilograms). The box must be supported directly by the building structure. Use only
UL listed outlet boxes marked "FOR FAN SUPPORT."
WARNING: To reduce the risk of fire, electrical shock, or personal injury, mount to the outlet box marked
"Acceptable for Fan Support," and use the mounting screws provided with the outlet box. Most outlet boxes
commonly used for the support of lighting fixtures are not acceptable for fan support and may need to be
replaced. Consult a qualified electrician if in doubt.
WARNING: To reduce the risk of fire, electrical shock, or personal injury, wire connectors provided with this fan
are designed to accept only one 12 gauge house wire and two lead wires from the fan. If your house wire is
larger than 12 gauge or there is more than one house wire to connect to the two fan lead wires, consult an
electrician for the proper size wire connectors to use.
5. Electrical diagrams are for reference only. Light kits that are not packed with the fan must be UL listed and
marked suitable for use with the model fan you are installing. Switches must be UL general use
switches. Refer to the instructions packaged with the light kits and switches for proper assembly.
6. After installation is complete, check that all connections are absolutely secure.
7. After making electrical connections, spliced conductors should be turned upward and pushed carefully up
into the outlet box. The wires should be spread apart with the grounded conductor and the
equipment-grounding conductor on opposite sides of the outlet box.
WARNING: To reduce the risk of electrical shock and fire, do not use this fan with any variable (rheostat) wall
control. (Note:This fan is suitable for use with remote control.)
8. Do not operate the fan in reverse until fan has come to a complete stop.
9. Do not insert anything between the fan blades while they are rotating.
WARNING: To reduce the risk of personal injury, do not bend the blade arms during assembly or after
installation. Do not insert objects into the path of the blades.
WARNING: To avoid personal injury or damage to the fan and other items, be cautious when working around or
cleaning the fan.
10. Do not use water or detergents when cleaning the fan or fan blades.A dry dust cloth or lightly dampened
cloth will be suitable for most cleaning.
WARNING: To reduce the risk of personal injury, use only parts provided with this fan. The use of parts OTHER
than those provided with this fan will void the warranty.
NOTE: The important safety precautions and instructions appearing in the manual are not meant to cover all
possible conditions and situations that may occur. It must be understood that common sense and caution are
necessary factors in the installation and operation of this fan.

page 2
1. Unpacking Your Fan.
Carefully open the packaging. Remove items
from Styrofoam inserts. Remove motor housing
and place on carpet or Styrofoam to avoid
damage to finish. Do not discard fan carton or
Styrofoam inserts should this fan need to be
returned for repairs.
Check against parts inventory that all parts have
been included.
2. Parts Inventory.
a. canopy. 1 piece
b. hanging bracket (pre-attached to canopy).
1 piece
c. 4in. downrod and hanging ball (with pin and
clip). 1 piece
d. motor housing. 1 piece
e. blade arm. 5 pieces
f. switch housing cap. 1 piece
g. blade. 5 pieces
h. light kit fitter. 1 piece
i. glass shade. 4 pieces
j. hardware packs
required bulbs:
4 x 40 watt candelabra base bulbs
(included)
ab
cd
e
g
hi
j
f

3. Installation Preparation.
4. Hanging Bracket Installation.
page 3
Vaulted ceiling
angle is not to
exceed 25 degrees.
downrod
installation
ON
OFF
ON
OFF
blade edge
7 feet
(2.13m)
(76cm)
30
inches
hanging bracket
spring washers
outlet box screws
flat washers
*Note: It is very important that you use the proper hardware when installing the hanging bracket as this will
support the fan.
flushmount
installation
12ft. - 20ft.
12ft. - 20ft.
(3.66m - 6.1m)
(3.66m - 6.1m)
Turn off circuit breakers to current fixture from breaker
panel and be sure operating light switch is turned to the
OFF position.
WARNING: Failure to disconnect power supply prior to
installation may result in serious injury.
Remove existing fixture.
WARNING: When using an existing outlet box, be sure the
outlet box is securely attached to the building structure and
can support the full weight of the fan. Ensure it is clearly
marked "Suitable for Fan Support." If not, it must be replaced
with an approved outlet box. Failure to do so can result in
serious injury.
CAUTION: Be sure oulet box is grounded properly and that a
ground wire (green or bare) is present.
Locate screws in slotted holes of canopy and partially
loosen these screws. Remove the other 2 screws--save
screws for later use. Twist canopy to remove hanging
bracket.
Install hanging bracket to outlet box using original screws,
spring washers and flat washers provided with new or
original outlet box.*If installing on a vaulted ceiling, face
opening of hanging bracket towards high point of ceiling.
Arrange electrical wiring around the back of the hanging
bracket and away from the hanging bracket opening.
To prevent personal injury and damage, ensure that
the hanging location allows the blades a clearance
of 7ft. (2.13m) from the floor and 30in. (76cm) from
any wall or obstruction.
This fan is suitable for room sizes up to 225 square
feet (20.9 square meters).
This fan can be mounted with a downrod
on a normal or vaulted ceiling.The hanging length
can be extended by purchasing a longer downrod
(0.5in./1.27cm diameter). After installing hanging
bracket, continue to Section 5 on page 4 for those
instructions. This fan can also be mounted using
flushmount installation only on a normal ceiling.
After installing hanging bracket, continue to Section 6
on page 5 for those instructions.
Installation requires these tools:
Phillips screwdriver, flat-head screwdriver,
adjustable pliers or wrench, stepladder, wire cutters,
and rated electrical tape.

page 4
NOTE: The important safety precautions and
instructions appearing in the manual are not
meant to cover all possible conditions and
situations that may occur. It must be understood
that common sense and caution are necessary
factors in the installation and operation of this fan.
5. Fan Assembly (with downrod).
yoke set screw
downrod
electrical wiring
pin
clip
canopy
motor
housing
set screw hole
set screw
hanging ball
stop pin
pin clip
A
B
If you wish to extend the hanging length of your
fan, you must remove the hanging ball from the
4in. downrod provided to use with an extended
downrod (sold separately). [If you wish to use the
4in. downrod, please proceed to instructions
following the dotted line below.]
To remove hanging ball, loosen set screw on
hanging ball and remove the pin and clip. Lower
hanging ball and remove stop pin. Slide hanging
ball off the original downrod, A, and slide it
down the longer downrod, B (the top of the
downrod should be noted as having a set screw
hole; use this hole when setting the set screw).
Insert stop pin into top of extended downrod
and raise hanging ball. Be sure stop pin aligns
with slots on the inside of the hanging ball.
Tighten set screw securely.
Remove pin and clip (if you have not already
done so). Slide downrod through canopy and
yoke cover.
Tip: To prepare for threading electrical wires
through downrod, apply a small piece of
electrical tape to the ends of the electrical
wires-this will keep the wires together when
threading them through the downrod.
Loosen yoke set screws and nuts at top of motor
housing. Remove pin and clip from downrod (if
you have not already done so). Slide downrod
through canopy and yoke cover.
Thread electrical wires through downrod and
pull extra wire slack from the upper end of the
downrod.
Place downrod into the motor housing yoke and
re-insert pin and clip that were previously
removed. Tighten yoke set screws and nuts
securely. Lower yoke cover and canopy to motor
housing.
["Fan Assembly" continued on next page.]

page 5
5. Fan Assembly (with downrod). (cont. )
With the hanging bracket secured to the outlet
box and able to support the fan, you are now
ready to hang your fan. Grab the fan firmly with
two hands. Slide downrod through opening in
hanging bracket and let hanging ball rest on the
hanging bracket. Turn the hanging ball slot until it
lines up with the hanging bracket tab.
Tip: Seek the help of another person to hold the
stepladder in place and to lift the fan up to you
once you are set on the ladder.
Continue to "Wiring" section for wiring diagram.
yoke
6. Fan Assembly (flushmount).
canopy
canopy cover
motor housing
hanging ball slot
hanging bracket tab
canopy
motor housing
hanging
bracket
hook
Remove and set aside canopy cover to reveal 6
holes. Notice that 3 of these holes are larger.
If there are only 3screws in top of motor
housing, please proceed to next paragraph. If
there are 6screws in top of motor housing,
remove every other screw and lock washer.
Thread wiring through canopy. Place canopy
over yoke, aligning larger holes in canopy with
the 3 existing screws in top of motor housing.
Insert the 3 screws and 3 lock washers that had
been removed (if there were only 3 screws
located in top of motor housing, these
screws/lock washers will be located in one of
the hardware packs) into the remaining holes.
Securely tighten these screws.
To prepare the fan for wiring, hang fan onto
hanging bracket by sliding the canopy over the
hanging bracket hook. (Use one of the
non-slotted holes on the rim of the canopy to
do so.)
Continue to the "Wiring" section for wiring
diagram.
canopy

7.Wiring.
page 6
8. Canopy Assembly.
canopy
hanging bracket
black
black
white
white
blue
black supply wire
white supply wire
*
from ceiling
from fan
ground (green
or bare)
ground
(green or bare)
Raise canopy to hanging bracket, aligning
loosened screws in hanging bracket with slotted
holes in canopy. Twist canopy to lock. Insert
screws (with washers) that were previously
removed (on page 3, Section 4) and secure all
screws with Phillips screwdriver.
slotted
hole
Important: Be sure outlet box is properly grounded
or that a ground wire (GREEN or Bare) is present.
Make sure all electrical connections comply with
Local Codes or Ordinances and the National
Electrical Code. If you are unfamiliar with electrical
wiring or if the house/building wires are different
colors than those referred to below, please use a
qualified electrician.
When downrod is secured in place on the
hanging bracket, electrical wiring can be
made as follows:
Connect BLACK and BLUE wire from fan to
BLACK wire from ceiling with wire connector
provided.
Connect WHITE wire from fan to WHITE wire
from ceiling with wire connector provided.
Connect all GROUND (GREEN) wires together
from fan to BARE/GREEN wire from ceiling with
wire connector provided.
If you intend to control the fan light with a
separate light switch connect BLUE wire from fan
to the BLACK supply from the independent
switch.
* Wrap each wire connector separately with
electrical tape as an extra safety measure.
This fan is remote control adaptable (remote control
sold separately).

page 7
9. Blade Assembly.
10. Light Kit Assembly (Optional).
motor housing
blade arm
blade
light kit fitter
If you wish to use your fan WITHOUT a light
kit, remove 3 screws from switch housing cap.
Align holes in switch housing cap with holes
in switch housing. Use screws that were
removed to attach switch housing cap to
switch housing. Please proceed to Section 11
on the following page to complete installation
without light kit.
If you wish to use your fan WITH a light kit,
remove 3 screws from light kit fitter. Locate
BLUE and WHITE wires in the switch housing
labeled FOR LIGHT. Remove and discard
cardboard label and plastic that hold these 2
wires together.
Next, locate WHITE and BLACK wires in light
kit fitter labeled FOR LIGHT KIT CONNECTION.
["Light Kit Assembly" continued on next
page.]
blade attachment
screws and washers
blade arm screws
lock washer
blade screw and washer
motor housing
switch housing cap
switch
housing
blue wire
white wire
black wire
white wire
Time Saver:Washers for blade screws can be
set on each blade screw prior to installing
blades.
Locate 15 blade attachment screws and
washers in one of the hardware packs. Hold
blade arm up to blade and align holes. Insert 3
blade attachment screws (along with washers)
with fingers first and then tighten screws
securely with a Phillips screwdriver. Repeat for
the remaining blades.
Remove blade arm screws and lock washers
from fan motor and set aside.Then, if applicable,
remove plastic motor blocks from underside of
motor and discard plastic motor blocks (save
blade arm screws and lock washers to secure
blade arms). Align blade arm holes with motor
screw holes and attach blade arm with lock
washers and blade arm screws. Before securing
screws permanently, repeat with remaining
blade arms. Securely tighten all screws.
Note: Tighten blade arm screws twice a year.
plastic
motor
block

switch housing
black wire
blue wire
white wire
white wire
page 8
10. Light Kit Assembly (Optional). (cont.)
Connect WHITE wire from switch housing
to WHITE wire from light kit fitter. Connect
BLUE wire from switch housing to BLACK
wire from light kit fitter. Be sure molex
connections snap together completely.
Attach light kit fitter to switch housing with
3 screws that were removed on previous
page. Securely tighten all screws with
Phillips screwdriver.
Secure 4 glass shades using thumb screws
provided in one of the hardware packs. Do
not overtighten thumb screws as glass may
crack or break.
Install 4 candelabra base 40 watt bulbs
(included).
Important: When replacing bulbs, please
allow bulb(s) and glass shade(s) to cool
down before touching them.
motor
housing
glass
shade
bulb
light kit
fitter
It is recommended that you test fan before
finalizing installation. Restore power from circuit
box and light switch (if applicable).Test fan
speeds with the pull chain opposite the reverse
switch. Start at the OFF position (no blade
movement). First pull will set the fan to HI.
Second pull will set the fan to MEDIUM.Third pull
will set the fan to LOW. Fourth pull will again set
the fan to the OFF setting.Test lights with the
pull chain in the middle. If fan and/or lights do
(does) not function, please refer to
"Troubleshooting" section to solve any issues
before contacting Customer Service.
Turn fan completely off before moving the
reverse switch. Set reverse switch to recirculate
air depending on the season:
- DOWN position in summer (diagram 1)
- UP position in winter (diagram 2)
A ceiling fan will allow you to raise your
thermostat setting in summer and lower your
thermostat setting in winter without feeling a
difference in your comfort.
Important: Reverse switch must be set either
completely UP or completely DOWN for fan to
function. If the reverse switch is set in the middle
position (diagram 3), fan will not operate.
pull chain
extension
thumb
screws
11.Testing Your Fan.
pull chain
extension
thumb
screw
reverse
switch
molex connections
diagram 1 diagram 2 diagram 3

Warranty.
Parts Replacement.
For parts and information, please refer to
"Parts Inventory" on page 2.
Litex Customer Support:
1-800-527-1292
www.litexfans.com
page 9
Troubleshooting.
LITEX 30-YEAR LIMITED WARRANTY:
LITEX INDUSTRIES, LTD. warrants this fan to the original
household purchaser for indoor use under the following
provisions:
1-YEAR WARRANTY: LITEX INDUSTRIES, LTD. will replace or
repair any fan which has faulty performance due to a
defect in material or workmanship.Contact Litex Customer
Service at 1-800-527-1292 to arrange for return of fan.
Return fan, shipping prepaid, to Litex Industries, Ltd.We will
repair or ship you a replacement fan, and we will pay the
return shipping cost.
5-YEAR WARRANTY: LITEX INDUSTRIES, LTD. will repair or
replace, at no charge to the original purchaser, any fan
motor that fails to operate satisfactorily when failure
results from normal use.
RETURN FAN MOTOR ONLY, shipping prepaid, to Litex
Industries.We will repair or ship purchaser a replacement
motor and Litex will pay the return shipping cost.
6 to 30-YEAR WARRANTY: LITEX INDUSTRIES, LTD. will repair
the fan, at no charge to the original purchaser for labor
only, if the fan motor fails to operate satisfactorily when
failure results from normal use. Parts used in the repair will
be billed to the purchaser at prevailing prices at time of
repair.
The purchaser shall be responsible for all costs incurred
in the removal, reinstallation and shipping of the product
for repairs.
This warranty does not apply when damage from
mechanical, physical, electrical or water abuse results in
causing the malfunction. Deterioration of finishes or other
parts due to time or exposure to salt air is specifically
exempted under this warranty.
Neither Litex Industries nor the manufacturer will
assume any liability resulting from improper installation or
use of this product. In no case shall the company be liable
for any consequential damages for breach of this, or any
other warranty expressed or implied whatsoever.This
limitation as to consequential damages shall not apply in
states where prohibited.
Problem: Fan fails to operate.
Solutions:
1. Check wall switch to fan.
2.Verify that reverse switch is set completely in
either direction.
3. Check to be sure fan is wired properly.
Problem: Light kit (optional) not lighting.
Solutions:
1. Check wall switch to fan.
2. Check that bulbs are installed correctly.
3. Check to be sure wires in canopy are wired
properly.
4. Check to be sure that bulbs total no more than
190W. [Note: Lamping light kit with bulbs that total more
than 190W will cause the wattage limiting device to
interrupt the flow of electricity to the light kit.]
Problem: Fan operates but lights fail (if
applicable).
Solutions:
1. Check that bulbs are installed correctly.
2. Check to be sure wires in canopy are wired
properly.
3.Verify that molex connections are connected
properly in switch housing.
4. Replace defective bulbs with same type of
bulb.
5. Check to be sure that bulbs total no more than
190W. [Note: Lamping light kit with bulbs that total more
than 190W will cause the wattage limiting device to
interrupt the flow of electricity to the light kit.]
Problem: Fan wobbles.
Solutions:
1. Check to be sure set screw(s) on motor
housing yoke is (are) tightened securely.
2. Check to be sure set screw on hanging ball is
tightened securely.
