1. Introduction
Congratulations on the purchase of your new device. You have thus opted
for a high-quality product. The operating instructions are an integral part of
this product. They contain important information relating to safety, use and
disposal. Read all of the operating and safety instructions thoroughly
before using the product. Use the product only as described and for the
specified range of applications. Include all documents when passing on
the product to someone else.
2. Intended use
This outdoor halogen spotlight is not designed for commercial application.
It is suitable for indoor and outdoor use. The 120 watt halogen light bulb
(9) provides good illumination. The motion sensor detects movements and
the outdoor halogen spotlight automatically switches itself on and off as a
result. This device meets all relevant norms and standards in conjunction
with CE conformity. In the event of any modification to the outdoor
halogen spotlight that was not approved by the manufacturer, compliance
with these standards is no longer guaranteed.

LIVARNO LUX LSHB 150 B1
4 - English
3. Supplied items
Outdoor halogen spotlight LSHB 150 B1
120 watt halogen light bulb
Installation materials (2 screws and 2 plugs)
Operating instructions and safety instructions
These operating instructions have a fold-out cover. The outdoor halogen
spotlight is illustrated with numbers on the inside cover. The numbers
indicate the following:
1 Screw (front pane)
2 Screw (wall bracket)
3 Cable junction box
4 Cable bushing
5 Screw connection (cable bushing)
6 Locking screw
7 Wall bracket
8 Motion sensor
9 Halogen light bulb
10 Front pane
11 Power cable (not supplied / home connection)
12 Screw terminal
13 LUX control
14 SENS control
15 TIME control

LIVARNO LUX LSHB 150 B1
English - 5
4. Technical data
Spotlight:
Brand: LIVARNO LUX
Model designation: LSHB 150 B1
Operating voltage: 220 – 240V~, 50/60Hz
Protection class: I (with earth conductor)
Protection rating: IP44 (splashing water protection
category)
Operating position: vertical - spotlight at top, motion sensor
at bottom
Maximum projected light
coverage:
approx. 50m² when installed at a
height of approx. 2m
Dimensions (W x H x D): approx. 139 x 112 x 86mm
Weight: approx. 587g
Halogen light bulb:
Light bulb: halogen light bulb R7s J78
Energy efficiency class: C
Service life: approx. 2000 hours / approx. 8000
switching cycles
Luminous flux: 2200lm +/-5%
Power: 120 watts
Colour temperature: approx. 3000K +/-10%
Motion sensor:
Sensor detection angle: 180° max.
Detection range: max. 12m (detection sensitivity can be
set via control dial)
Light sensitivity: can be set via control dial
Mechanical swivelling: approx. 150° horizontal / approx.
180° vertical
Light time: approx. 10 seconds +/- 5 seconds to
12 minutes +/- 1.5 minutes
The technical data and design may be changed without notification.

LIVARNO LUX LSHB 150 B1
6 - English
5. Safety instructions
Before using this device for the first time, please
read the following instructions carefully and
take note of the safety warnings, even if you
are familiar with the use of electronic devices.
Store these operating instructions in a safe
place for future reference. If you sell or pass on
the device to someone else, be sure to always
include these operating instructions as they are
an integral part of the device.
WARNING! This symbol
indicates important information
for safe operation of the outdoor
halogen spotlight and the safety
of the user. Disregarding this
information can lead to material
damage and/or health hazards
and even death.
Fire hazard: Attach the
outdoor halogen spotlight at a
distance of at least 1m from
illuminated materials. Excessive
heat generation can cause a fire.

LIVARNO LUX LSHB 150 B1
English - 7
Any cracked protective cover
must be replaced.
The outdoor halogen spotlight
has an earth conductor. The earth
conductor (yellow/green) must
be connected to the indicated
terminal.
Electrical devices do not belong in the
hands of children. Never allow children to
use electrical devices unsupervised
Children may not recognise potential risks.
Always keep plastic packaging away
from children. It poses a suffocation risk.
If you notice any smoke, unusual noises or
strange odours, switch off the device
immediately. In such cases, the device
should not be used until it has been
inspected by authorised service personnel.
Never inhale smoke from a potential
device fire. If you have inhaled smoke,

LIVARNO LUX LSHB 150 B1
8 - English
however, consult a doctor. The inhalation
of smoke can be harmful.
The housing of the outdoor halogen
spotlight must not be damaged. There is a
risk of an electric shock if the housing is
damaged.
Do not use the outdoor halogen spotlight
in potentially explosive environments
which contain flammable gases, vapours
or dust. It poses a risk of explosion.
Never open the housing of the outdoor
halogen spotlight except to change the
halogen light bulb. The circuit must be
disconnected during all work on the
outdoor halogen spotlight, even when
changing the light bulb! There is a risk of
an electric shock if the housing is open.
You must not hang any objects on the
outdoor halogen spotlight. The housing is
not designed to carry loads. Otherwise,
the outdoor halogen spotlight could be
damaged.
