Living Spaces 17C258A-W-S User manual

OUTDOOR KORO CORNER CHAIR
17C258A-W-S
217203
A
1
SEAT
DESCRIPTION
QTY
Parts List:
B
LEG
Assembly Steps:
Tip- Remove protective wrapping and lay all parts on floor. Indentify all parts packed in Carton against
attached parts list to make sure all parts are presented.
Step 1:Place a protective soft material on floor.Lay seat (A) upside down on floor, the bottom is facing up.
Then attach Leg (B) to the bottom as shown in Diagram.
Step 2:With a second person's assistance carefully turn the chair over onto its legs. Make sure legs rest on
a flat surface.Put the seat cushion and back cushion on the sofa.
NOTE: IT IS USER'S RESPONSIBILITY TO MAKE SURE ALL PARTS ARE ASSEMBLED AND TIGHTENED
PROPERLY AND SECURELY.
Step 1 Step 2
REF
4
Assembly Instruction
DESCRIPTION
QTY IMAGE
REF
Hardware List :
Diagram:
C
CUSHION
1
D
BACK PAD
1
C
D
E
ARMREST PAD
1
A
B
A
E

Assembly Steps:
2
Assembly Instruction
DESCRIPTION
QTY IMAGE
REF
Hardware List :
047
Diagram:
U-CLIP
047
Step 1: Remove protective wraping and lay all parts on floor.
Step 2:Place a protective soft Material on the floor,it's better to lift the each collcetion which need to be
connected with another person's help.
Step 3:Connect the each collection with u-clips .
