Living Spaces 120391 User manual

ASSEMBLY INSTRUCTIONS
Fine Furniture for every stage of life
PAGE 1 OF 4
BARSTOOL
120391
REIVSION:03/17/2022

PAGE 2 OF 4
ITEM:120391
ASSEMBLY INSTRUCTIONS
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
WARNING!
1.Don’t attempt to repair or modify parts that are broken or defective.Please contact the store
immediately.
2.This product is for home use only and not intended for commercial establishments.
ASSEMBLY TIME 15 MINUTES
PARTS IDENTIFICATION
HARDWARE IDENTIFICATION
NOTE:
Quantities shown are for one stool.
Phillips head screw diver is required in the assembly process; however,manufacturer does not provide thin item.
SEAT
FOOT REST
BASE
BOLTS
M6x14MM
ALLEN WRENCH
(M6-RBW)
GAS CYLINDER
COVER RING
1PC
1PC
1PC
4PCS
1PC1PC
1PC
1PC
1
2
A
B
C
D
E

PAGE 3 OF 4
ITEM:
ASSEMBLY INSTRUCTIONS
120391
STEP 1 STEP 2
STEP 3 STEP 4
COMPLETE
C
D
E
×Please pull out the
sheath before using
1
2
A
B

PAGE 4 OF 4
ITEM:
ASSEMBLY INSTRUCTIONS
120391
Note:Dimension tolerance±5%
15"
14.96"
28-33"
24.5-29.5"
16"
13"
3"
15.5"
