Living Spaces LUCA Y2103W-308 User manual

ASSEMBLY INSTRUCTIONS
SKU:
LUCA DESK
ITEM NO :
1
Y2103W-308
Y2103B-308
314652
314563
314608
15 min
Outlet USB Port
Y2103G-308

1
A
SKU#
PART IMAGE DESCRIPTION QTY
6887-A-W (White)
2
Allen key 60*22*4mm
1
2
Bolts M6*20mm 4
8
PART IMAGE DESCRIPTION QTY
31
Bolts M6*40mm
Hardware List of Luca Desk
THE HARDWARE IS LOCATED IN THE PACKING ITEM
NOTE: MUST TIGHTEN SCREWS PERIODIACLLY. WITH USE SCREW
MAY ENCOME LOOSE CHECK TIGHTNESS OF ALL SCREWS EVERY 6-8
WEEKS.
CLEANING INSTRUCTIONS:
After assembly, clean and polish the completed parts if necessary with
soft cloth and industrial recognized furniture polish.
SKU#
B
D1
C1
1
Desk Top
Right Leg
Left Leg
6887-A-B (Blue)
6887-A-G (Grey)
6887-B-W (White)
6887-B-B (Blue)
6887-B-G (Grey)
Support Bar
6887-C-W (White)
6887-C-B (Blue)
6887-C-G (Grey)
6887-D-W (White)
6887-D-B (Blue)
6887-D-G (Grey)
6887-1(4)
6887-2(8)
6887-3(1)
Note: Screwdriver will be prepared by yourshelf.

3
A
B
C
D
DETAIL VIEW
SAFETY RELEASE TAB SAFETY RELEASE TAB
Outlet USB Port
STEP 1:
Moving the drawer glides out the desk.

4
2
3
1
3
D
B
C
STEP 2: Assembly of the leg frames.
* Assemble the Right Leg (B), Left Leg (C)
to Desk top (A) by bolt (2).
STEP 3:
Cross Bar (D) is assembled to
two leg frames by Bolt (1).
2= 8Pcs
1= 4Pcs
Notice: Put the desk top (A)on
soft carpet to protect product.

5
1.Pull out slide. Slide bearings forward
2.Push slide back insde.
Repeat for every slide
3.Insert into slide
slot correctly push
the drawer into the
table body with force
STEP 4:
STEP 5: Revert the knobs as instruction
Assemble the drawers
as the right instruction.

That's it ! You've finished
assembling your item. Thank you!
