Living Spaces revive User manual

REV1.0 Wired Adjustable Base
OWNER’S MANUAL
Installation & Operation
Patent Pending
Warranty - 2-Year Parts and Labor on entire base
by LIVING SPACES

Safety & Warranty Warnings 1-5
Parts List 6
REV1.0 Electronics Quick Reference Guide 7-8
Installation Guide 9-10
REV1.0 Remote Control Instructions 11
Synchronizing Two Bases 12
Headboard Bracket Installation Guide 13
Troubleshooting 14-16
CONTENTS

Attention: READ THE FOLLOWING INFORMATION CAREFULLY BEFORE USING THIS PRODUCT
If unable to understand warnings, cautions, and/or instructions, contact the dealer or technical personnel if applicable, before attempting to
use the equipment. Otherwise, injury or damage may result.
SAFETY WARNINGS:
• Do not use bed outdoors.
• Do not use bed near explosives.
• Using bed with oxygen administering equipment other than the
nasal masked type creates a possible fire hazard.
• When using nasal or masked type administering equipment, route and secure oxygen or air tubing properly to ensure that tubing does not
become entangled or damaged during normal operation of the bed.
• Use caution when having liquids in or around the bed to ensure no spilling occurs. In case of spillage, stand in a dry,clean area of the floor
and unplug the bed immediately. Clean up spill and allow the area around bed to dry thoroughly before using the electric controls again. Do
not eat or drink hot liquids while operating the bed.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or instructions concerning use of the appliance by a person responsible
for their safety.
• Do not allow children or individuals with disabilities to operate the bed without adult supervision.
• Do not allow any person or pet under the bed at any time.
• During bed operation, make sure body is positioned within the confines of the bed. Do not place extremities over the sides of the bed when
operating bed functions.
Safety & Warranty Warnings
WARRANTY WARNING!
Do not open or tamper with control box, motors, or remote (with the exception of battery compartments). The warranty will be void if the internal
workings of these components are tampered with.
Product Rating:
The motors are not designed to operate continuously for more than [2] minutes in an [18] minute time period or approximately 10% duty cycle.
Attempting to circumvent or exceed this rating will shorten the life expectancy of the foundation and may void the warranty. Operating Information:
• After power foundation assembly is completed, operate remote control to ensure proper functions.
• Keep moving parts free of obstruction during bed operation (including sheets, clothing, tubing, wiring, and products using electric power cords).
• Distribute body weight evenly over bed surface. Do not place entire weight on head or foot sections of the bed, during repositioning and entering or
exiting bed.
Hospital Use Disclaimer:
This power foundation is designed for residential use only. It is not approved for hospital use and does not comply with hospital standards.
Weight Limits:
This product is not rated to support weights in excess of 850 pounds inclusive of the mattress and bedding. The bed will structurally support this
weight, provided it is evenly distributed across the foundation. The power foundation is not designed to support or lift this amount in the head or foot
sections alone. Exceeding this weight restriction could damage the bed and/or cause injury and will void the warranty.
1-16 2-16

RADIO FREQUENCY:2.4 GHz
FCC COMPLIANCE:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
To comply with the FCC RF exposure requirements, no change to the antenna or the device is permitted. Any change to the antenna or the
device could result in the device exceeding the RF exposure requirement and void user’s right to operate the device.
3-16
Parts List
All electronics and components that need to be installed are located in boxes under the foundation or
attached to the frame. Before discarding the packing materials, ensure that all the parts are accounted for.
6-16
WIRED REMOTE RETAINER BAR POWER CORD
POWER SUPPLY BOX12" LEGS
SPLITTER CABLE (included
with TXL or CKS size only
OPTIONAL EQUIPMENT (OPTIONAL)

REV1.0 Electronics Quick Reference Guide
Head Motor
7-16 8-16
Remote
Power Cord
Power Supply
Head Motor

Installation Guide
Two people are required to set up the foundation.
1. Open the shipping box, cut the ribbon securing accessory
boxes & mattress retainer bar, and put them aside.
Lift the folded bed frame unit out of the shipping carton
carefully, and then put it on a flat floor.
2. To install all six legs (seven for king/CK size,see image A
on page 12) , thread the bolt of the leg to the nut on the
foundation frame, and tighten by hand. DO NOT OVERTIGHTEN.
3.Uncoil the input power cord (connected to the control box on the
underside of the base) and plug it into the power supply box.
NOTE: To avoid damage to the foundation, always open the
carton while the bed is in the flat position.
4.Connect the remote cord into the receptacle cord on the underside
of the base.
9-16
5. Carefully flip the foundation over onto its legs.
Important: Two people are required to move the
foundation. Do not drag across the floor. Do not rest frame
on its side; excessive pressure may damage the legs.
6. Locate the mattress retainer bar brackets.
Slide the left side of the mattress retainer bar into the
bracket. Pull the retainer bar to the opposite bracket and
secure the right side.
Head
Leg Positions
Foot
Middle Leg on King/CK Size Only
A
10-16

REV1.0 Remote Control Instructions
11-16
HEAD CONTROL
(Raise)
HEAD CONTROL
(Lower)
Synchronizing Two Bases
OVERVIEW
Two TXL or CKS bases may be placed next to each other to form a King or Cal King. Both sides can be operated independently with their own
remotes or, if desired, a single remote can be used with both bases. Using a single remote for both bases will result in the bases moving
jointly.
TO SYNC REMOTE TO TWO BASES:
STEP 2
Using the splitter cable (included with TXL or CKS bases only) plug both
cables into each base (A & B). Finish by attaching the last cord to one
remote. The bases should now be controlled by one remote.
STEP 1
Ensure both bases (A & B) are plugged into a power source and both in the
flat position.
FOR TXL OR CKS BASES ONLY
12-16

Headboard Bracket Installation Guide
Headboard brackets are an optional accessory and are not included.
A 1/2'' (13 mm) socket and 1/2'' (13 mm) crescent wrench are necessary to complete installation.
HEADBOARD BRACKET COMPONENTS
(12) Short Bolts (12) Nuts
(2) T-Brackets
STEP 1
The headboard bracket will have 2 long slots to accomodate
any frame type. Align the appropriate slots on the bracket with
the holes on the bed. Use bolts and nuts to secure the bracket.
Make sure the bolts are tight.
STEP 2
To put the T-Bracket and Headboard Bracket together, you will
need (2) bolts and (2) nuts. Slip the bolts through the holes
from T-Bracket to Headboard Bracket with the head of bolt
facing outward. Use 1/2'' (13mm) socket and 1/2'' (13mm)
wrench to tighten the bolts.
STEP 3
You may now connect your headboard to the attachment plates using the remaining bolts and nuts to secure it to the brackets. The heads of
the bolts will face outward. Use a 1/2" (13 mm) socket and 1/2" (13 mm) wrench to tighten the bolts.
(2) Headboard Brackets
13-16 14-16
Troubleshooting
In the event that the power foundation fails to operate, assess the symptoms and possible solutions
provided in the chart below.
PROBLEM POSSIBLE SOLUTION
No features of the base will activate.
Head section will elevate, but will not return
to the flat position.
Ensure that all wired connections are secured below the bed base.
Unplug the power cord, wait 30 seconds and plug back in to reset electric components.
The surge protection or the electrical outlet may be defective. Test the outlet by plugging
in another working appliance.
Bed mechanism may be obstructed. Elevate bed and check for obstruction. Remove
obstruction.
Head section may be too close to the wall.
The remote will not operate the base. Check to ensure that the remote control is secured completely and that the power cord is
plugged into the wall outlet.

NOTES:

by LIVING SPACES
Customer Service: 1-855-430-8943
Serial No.
