Living Spaces ALENA 322637 User manual

Headboard hardware located in velcro pouch
in back of headboard.
Footboard hardware located in one end of
the footboard/siderails.
ASSEMBLY INSTRUCTIONS
Item No: 322637, 322638, 322643, 322644
Description: ALENA QUEEN/KING BED
Thank you for purchasing this quality product. Besure to check all packing material carefully for small parts that
may have come loose inside the carton during shipment.
PARTS LIST:
TOOLS REQUIRED(NOT PROVIDED)
Philips Screwdriver
Step1: AssemblyHB post(B)(C)&FB with Leg(J).Assembly Bolts(M) with FB(D)&HB post(B)&(C).
D M M M
K B
U J C
J L S When tightening
please stop here.
When tightening
please stop here. M
PAGE 1 OF 4 MADE IN VIETNAM
NO.
Description
Sketch
Quantity
A
Headboard
1PC
B
HB post Left
1PC
C
HB post Right
1PC
D
Footboard
1PC
E
Side Rail
2PCS
F
Center Rail
Support Leg
3PCS
G
Slat
Support Leg
8PCS
H
Center Rail
1PC
I
Slats
4PCS
J
Leg
2PCS
HB HARDWARE LIST:
NO. Description
Sketch
Size
Quantity
K
Flat Washer
Ø5/16"
12PCS
L
Spring Washer
Ø5/16"
12PCS
M
Bolt
Ø5/16"x4"
12PCS
N
Nut
M12
12PCS
O
Spanner
M12
1PC
FB HARDWARE LIST:
NO. Description
Sketch
Size
Quantity
K
Flat Washer
Ø5/16"
17PCS
L
Spring Washer
Ø5/16"
17PCS
M
Bolt
Ø5/16"x4"
4PCS
N
Nut
M12
4PCS
O
Spanner
M12
1PC
P
Bolt
Ø5/16"x1-1/2"
11PCS
Q
Screw
Ø8x1-1/2''
8PCS
R
Screw
Ø8x3/4''
4PCS
S
Allen Key
M5x4''
1PC
T
Metal bracket
50x32x30
2PCS
U
Bolt
5/16"x4"
2PCS
K
Flat Washer
Ø5/16"
2PCS
L
Spring Washer
Ø5/16"
2PCS
M
Bolt
Ø5/16"x4"
16PCS
S
Allen Key
M5x4''
1PC
U
Bolt
Ø5/16"x4"
2PCS

ASSEMBLY INSTRUCTIONS
Item No: 322637, 322638, 322643, 322644
Description: ALENA QUEEN/KING BED
Thank you for purchasing this quality product. Besure to check all packing material carefully for small parts that
may have come loose inside the carton during shipment.
Step2: Assembly HB(A) with post(B)&(C).
A
B
C
K
Step3: Assembly Side Rail(E) with HB(A)&FB(D).
A
K
M
D
PAGE 2 OF 4
MADE IN VIETNAM
K
Flat Washer
Ø5/16"
8PCS
L
Spring Washer
Ø5/16"
8PCS
N
Nut
M12
8PCS
O
Spanner
M12
1PC
K
Flat Washer
Ø5/16"
8PCS
L
Spring Washer
Ø5/16"
8PCS
N
Nut
M12
8PCS
O
Spanner
M12
1PC

ASSEMBLY INSTRUCTIONS
Item No: 322637, 322638, 322643, 322644
Description: ALENA QUEEN/KING BED
Thank you for purchasing this quality product. Besure to check all packing material carefully for small parts that
may have come loose inside the carton during shipment.
Step4: Assembly Center Rail(H) with HB(A)&FB(D).
R
A
R
H
F H
D
S
P
H
L
K
F
PAGE 3 OF 4
MADE IN VIETNAM
K
Flat Washer
Ø5/16"
3PCS
L
Spring Washer
Ø5/16"
3PCS
P
Bolt
Ø5/16"x1-1/2"
3PCS
R
Screw
Ø8x3/4''
4PCS
S
Allen Key
M5x4''
1PC
T
Metal bracket
50x32x30
2PCS

ASSEMBLY INSTRUCTIONS
Item No: 322637, 322638, 322643, 322644
Description: ALENA QUEEN/KING BED
Thank you for purchasing this quality product. Besure to check all packing material carefully for small parts that
may have come loose inside the carton during shipment.
Step4: Assembly slat(I) with side Rail(E).
Q
I
I G
G
Step5: Completed assembly for a regular bed.
Adjustable
PAGE 4 OF 4 MADE IN VIETNAM
K
Flat Washer
Ø5/16"
8PCS
L
Spring Washer
Ø5/16"
8PCS
P
Bolt
Ø5/16"x1-1/2"
8PCS
Q
Screw
Ø8x1-1/2''
8PCS
S
Allen Key
M5x4''
1PC
