LIXIL DXV Equility D12045-004 User manual

- 1 -
INSTALLATION INSTRUCTIONS
EQUILITY®5-1/2'x 30"MODEL D12045-004
(1676 x 768mm)
5-1/2'x 33"MODEL D12045-014
(1676 x 838mm)
ATTENTION INSTALLER:
Please deliver this manual to homeowner.
Thank you for selecting DXV. To ensure this product is installed properly, please read these instructions
carefully before you begin. (Certain installations may require professional help.) Also be sure your
installation conforms to local codes.
CAUTION: PRODUCT IS FRAGILE. TO AVOID BREAKAGE AND POSSIBLE INJURY HANDLE WITH CARE!
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2022 756205-100 (1/22)
!

- 2 - 756205-100 (1/22)
TABLE OF CONTENTS:
Cover. ...................................................................................................Page 1
Table of Contents .................................................................................Page 2
Safety Instructions Notice ....................................................................Page 3
General Installation Information ...........................................................Page 4
Tub Specications ................................................................................Page 5
Roughing-in Reference.........................................................................Page 6
Freestanding Tubs ................................................................................Page 7
Post Installation Instructions ................................................................Page 8

- 3 -
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS!
SAVE THESE INSTRUCTIONS
756205-100 (1/22)
!WARNING: Risk of personal injury. Do not permit children to use this bathtub without adult supervision. Never drop or
insert any object into any opening.
!WARNING: Risk of electric shock. Do not permit electrical appliances near any bathtub when bathtub contains water.
!WARNING: Risk of hyperthermia and possible drowning. People using medications and/or having adverse medical
history should consult a physician before using this product.
!WARNING: Risk of personal injury. Do not overll bathtub before entering. Entering tub when lled more than 2/3 can
cause overow and slippery conditions. Exercise caution when entering and exiting.
!WARNING: No Food or Alcoholic Beverages. Use of your bathtub immediately after meals is not recommended. Avoid
alcohol consumption before or during bathing. Alcoholic beverages can cause drowsiness or hyperthermia resulting in loss of
consciousness or even drowning.
!WARNING: Pregnancy. If you are or think you may be pregnant, consult your physician before using the bathtub.
Use this unit only for its intended use as described in this manual.
Do not use any attachments not recommended by DXV.

- 4 - 756205-100 (1/22)
GENERAL INSTALLATION INFORMATION
Carefully uncrate and inspect your new bath for any shipping damage. If such damage is found, report it to your
vendor immediately. After inspection and during installation, protect the bath from construction damage. Before
installation, and before enclosing with wallboard, tile, etc., the bath must be lled with water to check for leaks that
may have resulted from shipping damage or mishandling! Fittings (bath ller, shower arm, etc.) are not provided with
the bath and must be ordered separately. Framing and enclosing materials are provided by others. Follow test
procedures carefully.
ATTENTION INSTALLER!
THIS TUB MUST BE TESTED FOR OPERATION AND LEAKS PRIOR TO ENCLOSURE OF SURROUNDING
AREAS. FAILURE TO DO SO WILL VOID WARRANTY. THIS TUB WAS WATER TESTED AT THE FACTORY AND
FOUND TO BE FULLY OPERATIONAL AND LEAK FREE PRIOR TO SHIPPING. FREIGHT HANDLING AND JOB
SITE EXPOSURE MAY HAVE DETERIORATED THE TUB’S CONDITION. IT IS THE RESPONSIBILITY OF THE
INSTALLER TO THOROUGHLY TEST THE UNIT PRIOR TO INSTALLATION. TUBS ARE INTENDED FOR INDOOR USE
ONLY.
TEST PROCEDURES:
1. Place the tub on a at surface such as a driveway.
2. Seal the drain with tape.
3. Fill tub and allow tub to stand for ve minutes. Examine all ttings carefully for leaks.
NOTE: The overow is a plumbing device designed to prevent water from reaching a certain level in your tub.
DO NOT, under any circumstances, tape off or block the overow in any way.
4. If any leaks or operating problems are discovered, do not complete installation until problems are resolved.
DXV will not be responsible for any costs involved with removing or reinstalling the tub, or for the costs
of any surrounding materials or labor.
If you have installation or warranty questions please do not return the unit to the place of purchase. Call 800-227-2734
Always protect tub from construction damage by using a protective cover. Damage, including chips and scratches
incurred at the jobsite is excluded from warranty but may be repaired by qualied technician at the owner’s expense.
Do not stand in the tub or store materials in the tub during construction. Do not store tub in temperatures below
32 degrees Fahrenheit. Proper waste and overow installation is the responsibility of the installer. DXV does not warrant
leaks associated with improper waste and overow installation.
Check for availability of optional DXV wall tiling bead (required for recess installation).
Protect all nished surfaces of the bathtub during construction and installation using a drop cloth.

- 5 - 756205-100 (1/22)
RECOMMENDED TOOLS AND MATERIALS
Most of the procedures require the use of common tools and materials, which are available from hardware and
plumbing, supply stores. It is essential that the tools and materials be on hand before work is begun.
Tools Materials
• Level
• Square
• Tape Measure
• Pipe Wrench
• Slip Joint Pliers
• Standard Woodworking Tools
• Personal Safety Equipment
• Caulking Gun
• Silicone Caulking
• Tub & Tile Caulk
GENERAL SPECIFICATIONS FOR EQUILITY FREESTANDING BATH — TABLE 1
Description Water Depth
to Overow
Bathing Well
at Sump
Bathing Well
at Rim
Weight with
Water / Floor
Loading
Product
Weight
Gallon to
Overow
Equility
5-1/2'x 30"
(1676 x 768 mm)
D12045-004
14-1/2"
(370 mm)
42-1/8" x 16-1/2"
(1070 x 419 mm)
60-1/8" x 24-1/2"
(1527 x 622 mm)
590 lbs.
(268 kg.)
56 lbs./ft²
(273 kgs/m²)
93 lbs.
(42 kg.)
60 gal.
(226 l.)
Equility
5-1/2' x 33"
(1676 x 838 mm)
D12045-014
15-3/8"
(390 mm)
42-1/8" x 19-1/2"
(1070 x 495 mm)
60-1/8" x 27-1/4"
(1527 x 692 mm)
672 lbs.
(305 kg.)
57 lbs./ft²
(279 kgs/m²)
122 lbs.
(55 kg.)
66 gal.
(250 l.)
For more details, see specication page per model at www.dxv.com
The drain outlet is directly under the drain hole in the tub.
ROUGHING-IN REFERENCES FREESTANDING MODELS
-see appropriate sections for details
Equility Model D12045-014
5-1/2' x 33" (1676 x 838 mm)
Equility®Model D12045-004
5-1/2' x 30" (1676 x 768 mm)
Freestanding tubs use wall-mounted or freestanding faucets. The waste and overow assembly
is concealed between the walls of the tub, eliminating the need for a decorative exposed drain kit.
Dotted Line Represents Bathing Well
24-5/8"
(625 mm)
2-3/4"
(70 mm)
3-1/8"
(80 mm)
59-1/2" (1510 mm)
2 x 17-1/8"
(435 mm) 17-5/16"
(440 mm)
5/16"
(8 mm)
12-1/4"
(311 mm) 42-1/8"
(1070 mm)
16-1/2"
(419 mm)
30-5/16"
(770 mm)
66-3/4"
(1695 mm)
33-3/8"
(848 mm)
Ø 2-11/64"
(55 mm)
2 x 14-5/8"
(371 mm)
24-5/8"
(625 mm)
3"
(76 mm)
5-3/4"
(145 mm)
2-3/4"
(70 mm)
3-1/8"
(80 mm)
59-1/2" (1510 mm)
2 x 17-1/2"
(445 mm) 18-1/8"
(460 mm)
5/16"
(8 mm)
12-1/4"
(311 mm) 42-1/8"
(1070 mm)
19-1/2"
(496 mm)
33-5/16"
(846 mm)
66-3/4"
(1695 mm)
33-3/8"
(848 mm)
Ø 2-11/64"
(55 mm)
2 x 17-5/8"
(446 mm)
13º 13º

- 6 - 756205-100 (1/22)
1
2
3
4
• Place the tub on a nished, level oor in the
desired location.
ª Using an erasable pencil or marker, trace the outline of
the base of the tub on the oor. (See Fig. 1)
• Using the adjustable feet on the underside of the tub,
ensure that the tub is level.
• Ensure that there is a gap between the tub base and the oor.
Gap shall not exceed 1/8" [3 mm]. (See Fig. 2 )
• Using the traced outline for reference, conrm that the
drain/waste outlet in the oor will align with the tub drain outlet.
(Tub drain outlet will be located in the center of the traced
outline. See Fig. 3)
Note: The drain/waste outlet must be installed in
accordance with all local building codes.
All drain connections must be made using an
access created beneath the tub.
• The tail piece assembly, consisting of a anged tail piece, drain
tail piece gasket and slip-joint nut used to connect the the tub
drain to the drain/waste outlet, is included with this product.
• The 1-1/2" diameter tail piece is compatible with drain provided.
(See Fig. 4)
• Slide the slip-joint nut over tail piece towards the anged end as shown.
• Slide the P-trap slip-joint nut and seal over the tail piece as shown.
• Insert the tail piece into the P-trap.
• The ange of the tail piece should be approximately 5-3/4" [145 mm] or
3" [76 mm] depending on model, above the nished oor when fully inserted
into the P-trap.
• The tail piece can be cut if necessary.
INSTALLATION INSTRUCTIONS:
REMOVE THE TUB
INSTALLING THE 1-1/2" DIAMETER TAIL PIECE ASSEMBLY
INTO P-TRAP
FIG. 1
1/8" MAX
(3 mm)
FIG. 2
FINISHED FLOOR
FIG. 3
DRAIN
FLOOR CUTOUT
TRACED
OUTLINE
DRAIN TAIL PIECE GASKET
SLIP-JOINT NUT
TAIL PIECE
P-TRAP
FIG. 4
(INCLUDED) THREADED PORTION
OF DRAIN BODY
TAIL PIECE
ASSEMBLY
For MODEL#
D12045-004
5-3/4" [145 mm]
For MODEL#
D12045-014
3" [76 mm]
FINISHED
FLOOR
SLIP-JOINT NUT
P-TRAP
& SEAL
(PROVIDED BY
INSTALLER)
(PROVIDED BY
INSTALLER)

- 7 - 756205-100 (1/22)
5
6
7
8
• Apply a generous bead of silicone caulking to the base of the tub.
(See Fig. 5)
• Carefully set the tub into position. Ensure that drain tail piece gasket is fully
seated against the tail piece ange.
• Connect the tail piece to the tub drain. Tighten all of the drain connections.
Remove any excess caulking where the tub meets the oor.
Note: Connecting the tail piece assembly to the drain will require access
from beneath the tub.
• Fill the tub with water and drain. Check for leaks and re-tighten connections
as necessary.
• Apply a bead of Tub & Tile caulk around the bottom edge of the tub where
it meets the oor. Remove any excess caulking.
FIG. 5
No xtures can be mounted on the tub deck of freestanding tubs. Floor or wall-mounted xtures are required.
Wall-Mounted - The position of the tub and the reach of the spout are critical. Pay special attention to the spout reach when
choosing your xtures. Be careful to ensure the spout will extend out far enough to clear the tub ange and the falling water will
not hit too high up on the side wall of the tub and splash.
Floor-Mounted - Some freestanding xtures must be anchored to the tub drain for stabilization. The waste and overow
on freestanding tubs are concealed so anchoring to the overow pipe (or tub structure) is not possible. Many kits
(with minor modication) can be mounted to the wall (rather than the drain pipe) for stabilization.
FIXTURES

- 8 -
In the United States:
DXV
30 Knightsbridge Road
Piscataway, New Jersey 08854
Attention: Director of Customer Care
For residents of the United States, warranty
information may also be obtained by calling
the following toll free number: [phone]
www.DXV.com
In Canada:
DXV
5900 Avebury Road
Mississauga, Ontario
L5R 3M3
Canada
Toll Free: 1-800-387-0369
Local: 905-306-1093
Fax: [phone]
www.DXV.ca
In Mexico:
DXV
Via Morelos 330
Col. Santa Clara Coatitla
Ecatepec, Estado de México 55540
Toll Free: 01-800-8391200
www.DXV.mx
756205-100 (1/22)
POST INSTALLATION CLEAN-UP
Remove all construction debris from bath. Tile grout can be removed with a wooden Popsicle stick or tongue depressor.
Do not use wire brushes or any other metal implement on bath surface.
Post installation clean-up generally can be completed using warm water and liquid dishwashing detergent.
Stubborn dirt or stains may be removed using granular Spic and Span®mixed with water.
