LOCKEY GCTB175 User manual

T.+44 (0)1763 245245 E. [email protected] W.www.lockeydigital.co.uk
Black powder coated steel housing
Gate width up to 1.0 m (max.)
Gate height up to 1.8 m (max.)
Key features:
Adjustable closing speed
Simple to install
Suitable for timber or metal gates & doors
Adjustable nal latch speed
90 degree opening angle
Gate weight up to 50 kg (max.)
*CAUTION - The Garden Gate Closers are only suitable for
installation where the gate post or door frame are ush with the
gate or door and the hinge point is on the corner of the post or
door (see installation instructions on next page).
Garden Gate Closer - black
GCTB175
*To retain product warranty & restrict
gate opening angle further than the 90
degree limit, a gate stop must be installed
GCTB175
Garden Gate Closer
The GCTB175 Garden Gate Closer
is an inexpensive gate closer for lightweight
gates or doors which provides hydraulically
controlled closing speed and nal latching
speed adjustments. This closer was designed
for installation to garden gates and
lightweight doors (non fire doors) where the
*gate post or door frame is ush with the
gate or door and where the hinge point is at
the corner of the gate post or door frame
(like a typical internal house door with butt
hinges).
If you are a fencing contractor looking to
provide your customer with a compact gate
closer solution for their new gate, the
GCTB175 Garden Gate Closer would be a
natural choice. Other common OEM
applications are with machine guarding
(cage doors), kennels, shed doors, shutters
and y screens and the like.
The Garden Gate Closer's popularity is driven
by two things, quick and simple installation
and value for money. It's one of the simplest
gate closer installations you will nd.
Installs on top, middle or bottom of
either right or left hand of gate
Mounts on opening side of gate,
pushing it closed

Suitable For ‘T’ and Butt Hinges Where Gate and Post Are Flush
This gate closer is specically
designed for installing to gates that
have two types of hinges, ‘T’ hinges
and butt hinges. Examples of these
hinges are show in the drawings
below.
Do NOT t this gate closer to any
gate that does not have suitable types
of hinges or if the size, weight and
dimensions are outside the range
shown in the instructions. Distance from face of
post to centre of hinge
must be NO greater
than 6 mm
‘T’ hinge
Butt hinge




 











° 







