Loctite 98022 User manual

EQUIPMENT
OperationManual
Loctite® 300ml Cartridge Pusher
Part Number 98022

Table Of Contents
1 PLEASE OBSERVE THE FOLLOWING.................................................................................... 3
1.1 EMPHASIZED SECTIONS ...............................................................................................................................3
1.2 FOR YOUR SAFETY......................................................................................................................................3
1.3 ITEMS SUPPLIED ..........................................................................................................................................3
2 DESCRIPTION......................................................................................................................... 4
2.1 DESCRIPTION OF UNIT .................................................................................................................................4
2.2 THEORY OF OPERATION..................................................................................................... 4
3 TECHNICAL DATA ................................................................................................................. 5
4 INSTALLATION....................................................................................................................... 6
5 DISPENSING ........................................................................................................................... 6
5.1 SETTING UP LOW LEVEL INDICATOR...........................................................................................................7
5.2 INSTALLING A 300 ML CARTRIDGE ..............................................................................................................7
5.3 SHUT DOWN ................................................................................................................................................7
6 CARE,CLEANING AND MAINTENANCE................................................................................. 7
7 TROUBLESHOOTING .............................................................................................................. 8
8 DOCUMENTATION.................................................................................................................. 8
8.1 SPARE PARTS...............................................................................................................................................8
8.2 ACCESSORIES ..............................................................................................................................................8
8.3 WIRING DIAGRAM .......................................................................................................................................9
9 WARRANTY............................................................................................................................ 9
2

1 Please Observe The Following
1.1 Emphasized Sections
Warning!
Refers to safety regulations and requires safety measures that protect the operator or
other persons from injury.
Notice
Gives recommendations for better handling of the unit during operation or adjustment
as well as for service activities.
1.2 For Your Safety
For safe and successful operation of the unit, read these instructions completely. If
the instructions are not observed, the manufacturer can assume no responsibility.
Always wear goggles when operating with pressurized air.
Observe general safety regulations for the handling of chemicals such as Loctite®
adhesives and sealants. Observe the manufacturer’s instructions as stated in the
Material Safety Data Sheet (MSDS).
While under warranty, the unit may be repaired only by an authorized Loctite®
service representative.
1.3 Items Supplied
Carefully remove the unit from its shipping carton and inspect it for any signs of
damage. Any damage should be reported immediately to the carrier. Refer to the list of
supplied parts below and compare to the contents. Report any missing parts promptly
to the Loctite® customer service department at 1-800-LOCTITE or 1-800-562-8483.
1 300 ml Cartridge Pusher
1Instruction Manual
1 Fitting Kit
3

2 Description
2.1 Description of Unit
Refer to drawing in section 4 for numbered items below.
1 Cartridge Sleeve Cap
2 Plastic Washer
3 Cartridge Sleeve
4 Pneumatic Cylinder – 2” Bore x 8 ½ “ Stroke
5 Reed Switch Assembly for low level indicator.
6 Hand Lever – 3-way pneumatic valve for controlling movement of cylinder.
7 Spacer block for mounting 3-way valve
8 Cartridge Plunger Ram
9 Cylinder Mount/ Grease Reservoir
10 Grease Fitting
11 Base Plate
12 Advance Air Port
13 Retract Air Port
14 Regulator 0-60 PSI
15 Pressure Gage 0-61 PSI
16 Advance Air Port
17 Retract Air Port
18 Air Supply Port
2.2 Theory of Operation
The 300 ml Cartridge Pusher 98022 is used to dispense Loctite® medium viscosity
adhesive from 300 ml cartridges. The cartridge pusher is a front loaded, freestanding
device that can be coupled with a Loctite® Single Function Controller 98023, Three
Function Controller 98024 or integrated into an existing work cell.
Pressurized air is supplied to the air regulator. The air regulator controls the air
pressure that flows into the ram cylinder. A hand lever, pneumatic, three-way valve
channels the pressurized air into the pneumatic cylinder. The hand lever controls the
direction of travel of the piston within the air cylinder. Moving the hand lever down*,
toward the cartridge sleeve, causes the piston to move forward pressing product out of
the 300 ml cartridge through a product feed line. Moving the hand lever up*, toward
the air cylinder, causes the piston to retract. ( * Refers to unit mounted in vertical
orientation.)
The amount of product dispensed is controlled by three main factors:
•Amount of pressure pushing on the piston.
•Length of time a shut off valve remains open
•Dispense needle size – length and orifice diameter
4

2 Description (Continued)
A reed switch assembly is located on the air cylinder. The use of this switch is optional.
This switch is equipped with an LED indictor and a connector has been installed to
interface with Loctite® Single Function Controller 98023 or Three Function Controller
98024. The reed switch is activated by a permanent magnet located on the piston within
the air cylinder. As product is dispensed out of the 300 ml package, the piston will
move forward and activate the reed switch. Once activated the LED indicator will light
up and the switch will communicate a low level condition to the controller.
The 300 ml Cartridge Pusher is outfitted with a grease fitting located on the main
housing. This fitting allows access to a grease reservoir, which surrounds the piston
shaft applying a generous coating of grease during use. This grease protects the surface
of the shaft and the cylinder seals from adhesives or other contaminants.
3 Technical Data
Pneumatic Supply Min 50 PSI Max 100 PSI
Air Quality Filtered 10 um, oil-free, non-condensing
Pneumatic Hose Size Minimum 4mm I.D.
Dimensions W x H x D, 5 ½” x 8 3/8” x 26 ¾”
Operating Temperature 10°C to 40°C (50°F to 104°F)
Weight 10.6 Lbs. ( 4.8 kg)
5

4 Installation
1. The 300ml cartridge pusher is designed to be mounted vertical or horizontal
position. The vertical position is preferred. See drawing for hole locations.
2. Install airline to regulator using a 1/8” NPT fitting.
PSI
30
20
Model No.
No.
Serial
Rocky Hill, Connecticut 06067
10
0
40
50
60
6

5 Dispensing
The low level indicator must be set up before a cartridge of product is loaded into the
dispenser. The unit has been factory pre-set but minor adjustment may be needed.
5.1 Setting Up Low Level Indicator
1. Set hand lever (item 6) down to advance position.
2. Extend ram (item 8) until ram contacts sleeve cap (item 1).
3. Connect reed switch (item 5) to Loctite® Single Function Controller 98023.
4. Loosen barrel clamp on reed switch (item 5) and slide switch down cylinder (item
4), toward dispense end, until LED indicator lights.
5. Move reed switch (item 5) back up cylinder (item 4) approximately ½” and tighten
barrel clamp.
6. Fine adjustment of reed switch (item 5) can be accomplished after first cartridge is
emptied.
5.2 Installing a 300 ml Cartridge
1. Set hand lever (item 6) up to retract position.
2. Remove sleeve cap (item 1) and plastic washer (item 2).
3. Prepare cartridge by installing feed tube fitting.
4. Slide cartridge into cartridge sleeve (item 3).
5. Install cartridge sleeve cap (item 1) and plastic washer (item 2).
6. Install appropriate cartridge adapter onto cartridge.
7. Install feed tube or needle fitting and into the adapter.
8. Use pressure regulator (item 14) to set cylinder pressure.
Typical regulator settings range from 10 psi to 50 psi. Regulator pressure settings
greater than 50 psi is not recommended. If regulator is set at 50 psi and product flow
is insufficient then a larger product feed line should be used.
9. Move hand lever (item 6) down to cause the ram (item 8) to advance.
5.3 Shut Down
Move the hand lever (item 6) up toward the air cylinder (item 4) to retract piston.
6 Care, Cleaning and Maintenance
If dispensing is to be stopped for a prolonged period of time shut total system
down and remove 300 ml cartridge from sleeve.
Every 3 – 6 weeks, Loctite® ViperLube™ Grease should be pumped into grease
fitting located on cylinder mount/grease reservoir (item 9).
7

7 Troubleshooting
Problem Possible Cause Correction
No adhesive is dispensed. •Cylinder is in retract mode.
•Product reservoir is empty.
•Air pressure is set to low.
•Flow controls on 3-way
valve is shut down.
•Blockage downstream of
cartridge pusher.
•Move hand lever down to
advance ram.
•Insert new product package
into cartridge sleeve.
•Check incoming air
pressure (min 60 PSI).
•Open flow controls on 3-
way valve.
•Check valve, hose, and
needle.
LED indicator does not light. •Connection is loose.
•Reed switch is not properly
located.
•Indicator is faulty.
•Tighten plug connector.
•See low level set-up
instructions.
•Replace sensor.
8 Documentation
8.1 Spare Parts
Cartridge Sleeve Kit 984826
Kit includes – Cartridge Sleeve
Cartridge Sleeve Cap
Plastic Washer
Reed Switch Assembly 984756
Air Cylinder 984732
Plunger Ram 984755
8.2 Optional Accessories
Loctite® ViperLube™ Grease 14 oz. Cartridge 36782
Cartridge Fitting Kits:
Poly Fitting 1/4” Tube x 1/4 Male NPT, Qty 10 984832
Poly Fitting 3/8” Tube x 1/4 Male NPT, Qty 10 984833
Fischbach cartridge to 1/4 Female NPT, S.S., Qty. 1 982644
Adapter, Semco Cartridge to 1/4 Female NPT, Qty 3 98181
Adapter, Fitting, Male Luer Lok x 1/4 Male NPT, Qty. 5 98371
Nozzle, 2.5” Long x 1/4 Male NPT, Qty. 10 98128
Feedtube Kits:
Black Teflon® Lined Feedtube, 3/8” x 33 feet 97970
Black Teflon® Lined Feedtube, 1/4” x 33 feet 97972
8

8 Documentation (Continued)
8.3 Wiring Diagram
9 Warranty
Henkel expressly warrants that all products referred to in this Instruction Manual for The 300 ml Cartridge Pusher
98022 (hereafter called “Products”) shall be free from defects in materials and workmanship. Liability for Henkel
shall be limited, as its option, to replacing those Products which are shown to be defective in either materials or
workmanship or to credit the purchaser the amount of the purchase price thereof (plus freight and insurance
charges paid therefor by the user). The purchaser’s sole and exclusive remedy for breach of warranty shall be such
replacement or credit.
A claim of defect in materials or workmanship in any Products shall be allowed only when it is submitted in
writing within one month after discovery of the defect or after the time the defect should reasonably have been
discovered and in any event, within 12 months after the delivery of the Products to the purchaser. No such claim
shall be allowed in respect of products which have been neglected or improperly stored, transported, handled,
installed, connected, operated, used or maintained. In the event of unauthorized modification of the Products
including, where products, parts or attachments for use in connection with the Products are available from Henkel,
the use of products, parts or attachments which are not manufactured by Henke, no claim shall be allowed.
No Products shall be returned to Henkel for any reason without prior written approval from Henkel. Products
shall be returned freight prepaid, in accordance with instructions from Henke.
NO WARRANTY IS EXTENDED TO ANY EQUIPMENT WHICH HAS BEEN ALTERED, MISUSED,
NEGLECTED, OR DAMAGED BY ACCIDENT, OR IF THE SYSTEM USED TO DISPENSE ANY LIQUID
MATERIAL OTHER THAN HENKEL PRODUCTS.
EXCEPT FOR THE EXPRESS WARRANTY CONTAINED IN THIS SECTION, HENKEL MAKES NO
WARRANTY OF ANY KIND WHATSOEVER, EXPRESS OR IMPLIED, WITH RESPECT TO THE
PRODUCTS.
ALL WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, AND OTHER
WARRANTIES OF WHATEVER KIND (INCLUDING AGAINST PATENT OR TRADEMARK
INFRINGEMENT) ARE HEREBY DISCLAIMED BY HENKEL AND WAIVED BY THE PURCHASER.
THIS SECTION SETS FORTH EXCLUSIVELY ALL OF LIABILITY FOR HENKEL TO THE PURCHASER
IN CONTRACT, IN TORT OR OTHERWISE IN THE EVENT OF DEFECTIVE PRODUCTS.
WITHOUT LIMITATION OF THE FOREGOING, TO THE FULLEST EXTENT POSSIBLE UNDER
APPLICABLE LAWS, HENKEL EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER FOR ANY
DAMAGES INCURRED DIRECTLY OR INDIRECTLY IN CONNECTION WITH THE SALE OR USE OF,
OR OTHERWISE IN CONNECTION WITH, THE PRODUCTS, INCLUDING, WITHOUT LIMITATION,
LOSS OF PROFITS AND SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES, WHETHER CAUSED
BY NEGLIGENCE FROM HENKEL OR OTHERWISE.
9

Henkel Corporation
1001 Trout Brook Crossing
Rocky Hill, CT 06067-3910
Henkel Canada Corporation
2225 Meadowpine Boulevard
Mississauga, Ontario L5N 7P2
Henkel Capital, S.A. de C.V.
Calzada de la Viga, s/n, Fracc. Los Laureles
Loc. Tulpetlac, C.P. 55090
Ecatepac de Morelos, Edo de Mexico,
Henkel Corporation
Automotive / Metals HQ
32100 Stephenson Hwy.
Madison Heights, MI 48071
Henkel Ltda.
Rua Karl Huller, 136 – Jd.
Canhema 09941-410
Diadema/SP, Brazil
www.loctite.com
Loctite is a registered trademark of Henkel Corporation, U.S.A
© Copyright 2003. Henkel Corporation. All rights reserved. Data in this operation manual is subject to change without notice.
Manual P/N: 984744, Rev B, 08/2008
10
