Logic LC-404-N19 User manual

MODEL SERIES
LC-404-N19 CABLE CUBBY SERIES
www.logicav.in
2. Installation
INSTALLATION MANUAL
CABLE MANAGER
www.logicav.in
Cable Manager Locking Details
4. After positioning the cable manager into
the table cut-out, insert the mounting clamp
to the enclosure for securing the unit to the
table surface (on both sides)
5. Softly tighten the screw to
secure the enclosure towards
the bottom side of the table
(on both sides)
After installing the cable manager on the table
Ensure the mounting clamps has been assembled as per above instruction (on both sides)
Bottom side
of the table
Table Surface

Cable Manager x 1 A: Cut-out template x1
Checklist 2. Installation
1. Product Dimension
www.logicav.in www.logicav.in
mm
Lorem ipsum
B: Mounting
clamp x 2
IMPORTANT: Prior tom installation, ensure that you have received all the
parts as per the checklist.
236.00 141.00
130.00 130.00
R6.50
130.00
214.60
106.50
Instruction to provision the cut-out on the table:
ATTENTION: The cut-out on the table for the cable cubby should be
executed only by an experienced craftsperson to prevent
any damage/scarring
CAUTION: Wear safety glasses while operating power equipment.
Failure to comply may result in eye injury
1. Place the cut-out
template on the table
2. Follow template dimensions,
to carry out the cut-out on the table
3. Then position the cable manager
in the table cut-out
View after positioning the
cable manager into the table
Table Top Cut out
Table Top
Table Top
Dimension in mm
mm
mm
