INSTALLATION MANUAL
RETRACTABLE MODULES FOR
CABLE MANAGER
www.logicav.in
MODEL SERIES
LG-HDMIRC
LG-MDPRC
LG-TCRC RETRACTABLE SERIES
LG-USBRC MODULES
LG-RJ45RC
LG-DPRC
LG-VGARC

www.logicav.in
1. Use L-clamp and screws
2 nos from LG-805RC
2. Position the L-clamp as shown in the
image and then, screw them softly
(Refer screw B in the module checklist)
Checklist
1. Installation
L - clamp
L - clamp
B: Screw x 4
(Extra Screw x 1)
A: Cable Retractable
Module x 1

www.logicav.in
View after positioning
the L-clamp with modules

www.logicav.in
3. Insert the modules into the enclosure
from the bottom side of the table

www.logicav.in
4. Mount the L-clamp (along with modules) to the enclosure with screws
(Refer screw D in the LG-805RC checklist on both slots and module)
Section View for Reference

www.logicav.in
5. Pull the cable from the retractor and place it in the C-shape cut out
(Refer C-shape plate H in the LG-805RC checklist) Further, position it on the
enclosure Reference image for 3 x Modules and 1 x Blank plate
(Refer blank plate G in the LG-805RC checklist)

www.logicav.in
6. Position and softly tighten the screw (8 no’s) as per the previous point
(Refer screw E in the LG-805RC checklist)
Section View for Reference

Final view reference image
www.logicav.in
Top view of the cable manager with
three modules and one blank plate
Isometric view
Table
