LOGICDATA DMIclassic Series User manual

DOCUMENT VERSION 1.0 | SEPTEMBER 2023
DMIclassic Family
Operating Manual

DMICLASSIC FAMILY - OPERATING MANUAL // PAGE 2
DMIclassic Family - Operating Manual
Document Version 1.0 / September 2023
This document was originally published in English.
LOGICDATA Electronic & Software Entwicklungs GmbH
Wirtschaftspark 18
8530 Deutschlandsberg
Austria
Phone: [phone]
Fax: [phone]
Internet: www.logicdata.net
Email: o[email protected]

DMICLASSIC FAMILY - OPERATING MANUAL // PAGE 3
CONTENTS
1 General Information 5
1.1 Other Applicable Documents 5
1.2 Copyright 5
1.3 Royalty-Free Use of Images and Text 5
1.4 Trademarks 5
2 Safety 6
2.1 Target Audience 6
2.2 General Safety Regulations 6
2.3 Intended Use 6
2.4 Reasonably Foreseeable Misuse 6
2.5 Explanation of Symbols and Signal Words 7
2.6 Liability 7
2.7 Residual Risks 8
2.8 Skilled Persons 9
2.9 Notes for Resellers 9
3 Scope Of Delivery 10
4 Unpackaging 10
5 Product 11
5.1 Key Product Features 11
5.1.1 DMIclassic B 11
5.1.2 DMIclassic C 12
5.1.2.1 About the Sliding Mechanism 12
5.2 Dimensions 13
5.2.1 DMIclassic B 13
5.2.2 DMIclassic C 14
5.3 Drilling Template 15
5.3.1 DMIclassic B 15
5.3.2 DMIclassic C 16
6 Assembly 17
6.1 Safety During Assembly 17
6.2 Required Components 18

DMICLASSIC FAMILY - OPERATING MANUAL // PAGE 4
6.3 Process 18
6.4 Completing Assembly 18
7 System Information 19
7.1 DMIclassic B 19
7.2 DMIclassic C 20
8 Operation 22
8.1 Adjusting the Table Top Height 23
8.2 Saving a Memory Position (DMIclassic C Only) 23
8.3 Adjusting the Table to a Memory Position 24
(DMIclassic C Only)
8.4 Changing the Height Display (cm/inch, 25
Dmiclassic C Only)
9 Additional Information 25
9.1 Disassembly 25
9.2 Maintenance 26
9.2.1 Cleaning 26
9.3 Troubleshooting 26
9.4 Disposal 26

DMICLASSIC FAMILY - OPERATING MANUAL // PAGE 5
1 GENERAL INFORMATION
Documentation for the DMIclassic Family Handset consists of this Operating Manual and several other do-
cuments (Other applicable documents, page 5). Assembly personnel must read all documentation before
starting assembly. Keep all documentation for as long as the product is in your possession. Ensure that all
documentation is provided to subsequent owners. Go to www.logicdata.net for more information and sup-
port. This Manual may change without notice. The most recent version is available on our website.
1.1 OTHER APPLICABLE DOCUMENTS
This Operating Manual contains assembly and operation instructions for the DMIclassic Family Handset.
Other applicable documents include:
• Datasheet for DMIclassic Handset
• DYNAMIC MOTION System Manual
• Datasheet and Operating Manual for the installed DYNAMIC MOTION Actuator
• Datasheet for the installed Power Unit
1.2 COPYRIGHT
© September 2023 by LOGICDATA Electronic und Software Entwicklungs GmbH. All rights reserved, except
for those listed in Chapter 1.3 Royalty-free use of images and text on page 5.
1.3 ROYALTY-FREE USE OF IMAGES AND TEXT
After purchase and full payment of the product, all text and images in Chapter 2 “Safety”, may be used free
of charge by the customer for 10 years after delivery. They should be used to prepare end user documen-
tation for Height-Adjustable Table Systems. The license does not include logos, designs, and page layout
elements belonging to LOGICDATA. The Reseller may make any necessary changes to the text and images
to adapt them for the purpose of end user documentation. Texts and images may not be sold in their current
state and may not be published or sublicensed digitally. The transfer of this license to third parties without
permission from LOGICDATA is excluded. Full ownership and copyright of the text and graphics remain
with LOGICDATA. Texts and graphics are oered in their current state without warranty or promise of any
kind. Contact LOGICDATA to obtain text or images in an editable format ([email protected]).
1.4 TRADEMARKS
Documentation may include the representation of registered trademarks of goods or services, as well as
information about copyright or other proprietary expertise of LOGICDATA or third parties. In all cases, all
rights remain exclusively with the respective copyright holder. LOGICDATA® is a registered trademark of
LOGICDATA Electronic & Software GmbH in the USA, the European Union, and other countries.

DMICLASSIC FAMILY - OPERATING MANUAL // PAGE 6
2 SAFETY
2.1 TARGET AUDIENCE
This Operating Manual is intended for Skilled Persons only. Refer to Chapter 2.8 Skilled Persons on page 9 to
ensure that personnel meet all requirements.
2.2 GENERAL SAFETY REGULATIONS
In general, the following safety regulations and obligations apply when handling the product:
• Do not operate the product unless it is in a clean and perfect condition
• Do not remove, change, bridge, or bypass any protection, safety, or monitoring equipment
• Do not convert or modify any components without written approval from LOGICDATA
• In the event of malfunction or damage, faulty components must be replaced immediately
• Unauthorized repairs are prohibited
• Do not attempt to replace hardware unless the product is in a de-energized state
• Only Skilled Persons are allowed to work with DMIclassic Family handsets
• Ensure that national worker protection conditions and national safety and accident preven-
tion regulations are observed during operation of the system
2.3 INTENDED USE
The products in the DMIclassic Family Handset are for electrically Height-Adjustable Tables. They are in-
stalled by Resellers into Height-Adjustable Table systems. They are used to control Height-Adjustable Table
systems via an integrated Control Unit in the connected DYNAMIC MOTION Actuator. They are intended
for indoor use only. They may only be installed in compatible Height-Adjustable Table Systems and with
LOGICDATA-approved accessories. Contact LOGICDATA for further details. Use beyond or outside the in-
tended use will void the product’s warranty.
2.4 REASONABLY FORESEEABLE MISUSE
Usage outside of the intended use may lead to minor injury, serious injury, or even death. Reasonably fore-
seeable misuse of the Handset includes, but does not extend to:
• Connecting unauthorized parts to the product. If you are unsure as to whether a part can be
used with a Handset, contact LOGICDATA for further information

DMICLASSIC FAMILY - OPERATING MANUAL // PAGE 7
2.5 EXPLANATION OF SYMBOLS AND SIGNAL WORDS
Safety Notices contain both symbols and signal words. The signal word indicates the severity of the hazard.
DANGER Indicates a hazardous situation which, if not avoided, will result in death or serious
injury.
WARNING Indicates a hazardous situation which, if not avoided, could result in death or serious
injury.
CAUTION Indicates a hazardous situation which, if not avoided, could result in minor or mo-
derate injury.
NOTICE Indicates a situation which, if not avoided, could result in damage to the product
through electrostatic discharge (ESD).
NOTICE Indicates a situation that will not lead to personal injury, but could lead to damage to
the device or the environment.
INFO Indicates the protection class of the device: Protection Class III.
Protection Class III devices may only be connected to SELV or PELV power sources.
INFO Indicates important tips for handling the product.
2.6 LIABILITY
LOGICDATA products comply with all currently applicable health and safety regulations. However, risk can
result from incorrect operation or misuse. LOGICDATA is not liable for damage or injury caused by:
• Improper product use
• Disregard of the documentation
• Unauthorized product alterations
• Improper work on and with the product
• Operation of damaged products
• Wear parts
• Improperly performed repairs
• Unauthorized changes to the operating parameters
• Disasters, external inuence, and force majeure
The information in this Operating Manual describes the characteristics of the product without assurances.
Resellers assume responsibility for the LOGICDATA products installed in their applications. They must en-
sure their product complies with all relevant directives, standards, and laws. LOGICDATA shall not be held
liable for any damage that is directly or indirectly caused by the delivery or use of this document. Resellers
must observe the relevant safety standards and guidelines for each product in the Table System.

DMICLASSIC FAMILY - OPERATING MANUAL // PAGE 8
2.7 RESIDUAL RISKS
Residual risks are the risks that remain after all relevant safety standards have been complied with. These
have been evaluated in the form of a risk assessment. Residual risks associated with the installation of the
DMIclassic Family handsets are listed here and throughout this Operating Manual. The risks associated with
the system as a whole are listed in the System Manual. See also Chapter 1.1 Other Applicable Documents on
page 5. The symbols and signal words used in this Operating Manual are listed in Chapter 2.5 Explanation of
Symbols and Signal Words on page 7.
WARNING Risk of death or serious injury through electric shocks
DMIclassic Family handsets are electrical devices. Although you will not have to con-
nect any products to the Power Unit during assembly, basic safety precautions must be
taken at all times. Failure to observe electrical safety precautions may lead to death or
serious injury through electric shocks.
• Never open the Handset
• Do not convert or modify the Handset in any way
• Do not immerse the Handset or its components in liquid. Clean only with a dry or
slightly damp cloth
• Do not place the Cable of the Handset on heated surfaces
• Check the housing and cables of the Handset for visible damage. Do not install or
operate damaged products
WARNING Risk of death or serious injury through electric shocks
The DMIclassic Family handsets are Protection Class III devices. They may only be
supplied with safety extra-low voltage (SELV). Supplying the DMIclassic Family handsets
with the incorrect voltage could result in death or serious injury through electric shocks.
• Only supply the DMIclassic Family handset with safety extra-low voltage (SELV)
• Refer to the data sheet for information on the permissible supply voltage
WARNING Risk of death or serious injury in explosive atmospheres
Operating the Handset in potentially explosive atmospheres may lead to death or
serious injury through explosions.
• Do not operate the Handset in potentially explosive atmospheres
CAUTION Risk of minor or moderate injury through tripping
During the assembly process, you may have to step over Cables. Tripping over Cables
may lead to minor or moderate injury.
• Ensure that the assembly area is kept clear of unnecessary obstructions
• Be careful not to trip over Cables

DMICLASSIC FAMILY - OPERATING MANUAL // PAGE 9
CAUTION Risk of minor or moderate injury through crushing
If any Handset Key becomes stuck while the system is in motion, the system may not
stop properly. This may lead to minor or moderate injury through crushing.
• Disconnect the system immediately if any Handset Key becomes stuck
2.8 SKILLED PERSONS
DMIclassic Family handsets may only be installed by Skilled Persons. A Skilled Person is dened as someone
who:
• Has read and understood all documentation relevant to the Handset
2.9 NOTES FOR RESELLERS
Resellers are companies that purchase LOGICDATA products for installation in their own products.
INFO For reasons of EU conformity and product safety, Resellers should provide end users
with an Operating Manual in their native EU ocial language
INFO The Charter of the French Language (La charte de la langue française) or Bill 101 (Loi
101) guarantees the right of the population of Quebec to conduct business and com-
mercial activities in French. The bill applies to all products sold and used in Quebec.
For table systems that will be sold or used in Quebec, Resellers must provide all pro-
ductrelevant texts in French. These include, but are not limited to
• Operating Manuals
• All other product documentation, including datasheets
• Inscriptions on the product (such as labels), including those on product packaging
• Warranty certicates
The French inscription may be accompanied with a translation or translations, but no
inscription in another language may be given greater prominence than that in French.
INFO Operating Manuals must include all the safety instructions that end users require to
handle the product safely. They must also include an instruction to always keep the
Operating Manual in the immediate vicinity of the product.
INFO No unauthorized persons (young children, persons under the inuence of medications,
etc.) should be allowed to handle the product.
INFO Resellers must perform a risk assessment on their product that covers residual hazards.
It must include measures to mitigate risk, or reference the product‘s Operating Manual.

DMICLASSIC FAMILY - OPERATING MANUAL // PAGE 10
3 SCOPE OF DELIVERY
The standard scope of delivery for Handsets in the DMIclassic Family consists of the Handset, its preattached
cable (and 3 mounting screws only in case DMIclassic C). All other components necessary for installing the
Handset must be supplied separately by the reseller.
4 UNPACKAGING
To unpackage the product:
1. Remove all components from the packaging
2. Check the contents of the package for completeness and damage
3. Provide the Operating Manual to the operating personnel
4. Dispose of the packaging material
NOTICE Dispose of the packaging material in an environmentally friendly manner. Remember
to separate plastic parts from the cardboard packaging.
NOTICE Ensure proper ESD handling during unpackaging. Damage that can be attributed to
electrostatic discharge will void warranty claims.

DMICLASSIC FAMILY - OPERATING MANUAL // PAGE 11
5 PRODUCT
The DMIclassic Family of Handsets consists of two products: DMIclassic B and DMIclassic C. In general,
operation and assembly of both handsets are similar with some dierences that will be pointed out within
this manual further on.
5.1 KEY PRODUCT FEATURES
5.1.1 DMICLASSIC B
1 Mounting Points
2 UP / DOWN Keys
3 LED Signal Light
1
3
2
Fig. 1: Product features, DMIclassic B

DMICLASSIC FAMILY - OPERATING MANUAL // PAGE 12
5.1.2 DMICLASSIC C
1 Memory Position Keys
2 Mounting Points
3 UP / DOWN Keys
4 SAVE Key
5 Display
6 Mounting Plate (for sliding mechanism)
1
3
54
2
6
Fig. 2: Product features, DMIclassic C
5.1.2.1 ABOUT THE SLIDING MECHANISM
The Sliding Mechanism is a feature of DMIclassic C that allows the handset to be stowed under the table,
during transportation or when it is not being used.
To move to the retracted position: Push the handset inwards toward the table top until it clicks into place.
To move to the extended position: Pull the handset outwards until it clicks into place.

DMICLASSIC FAMILY - OPERATING MANUAL // PAGE 13
5.2 DIMENSIONS
5.2.1 DMICLASSIC B
Length 50.0 mm | 1.967”
Width 59.9 mm | 2.358”
Height (to underside of Table Top) 17.3 mm | 0.681”
17.3 mm
0.681”
50.0 mm
1.967”
59.9 mm
2.358”
Fig. 3: Product dimensions, DMIclassic B

DMICLASSIC FAMILY - OPERATING MANUAL // PAGE 14
5.2.2 DMICLASSIC C
Length 69.5 mm | 2.736”
Width 137.2 mm | 5.404”
Height (to underside of Table Top) 24.7 mm | 0.974”
69.5 mm
24.7 mm
137.2 mm
Fig. 4: Product dimensions, DMIclassic C

DMICLASSIC FAMILY - OPERATING MANUAL // PAGE 15
5.3 DRILLING TEMPLATE
5.3.1 DMICLASSIC B
There are two variants for mounting. In the Standard Position the drilled holes should be 8 mm from the
front edge of the Table Top and 43.8 mm apart.
Alternatively, the drilled holes can be set to the Transportation Position, 24 mm from the front edge of the
Table Top and 43.8 mm apart. The Transportation Position allows the DMIclassic B to be slid backwards under-
neath the Table Top, so that the Handset does not protrude from the front edge of the table when in transport.
The Side Edge of the DMIclassic B does not have to be ush with the Table‘s Side Edge. Leave a minimum of
20 mm between the outer hole and the Side Edge to ensure the DMIclassic B does not protrude from the side
24 mm
0.945”
43.8 mm
1.724”
8 mm
0.315”
Table Edge
Table Edge
Transportation Position
Standard Position
Fig. 5: Drilling template, DMIclassic B

DMICLASSIC FAMILY - OPERATING MANUAL // PAGE 16
5.3.2 DMICLASSIC C
When placing the drilling holes, it must be ensured that the Handset does not protrude from the front edge
of the Table Top while in the retracted position. To ensure the correct position:
• The two drilling holes at the front of the plate must be 31.5 mm from the front edge of the table.
• The two drilling holes must be placed in a line parallel to the front edge of the table and 46 mm apart.
• The single drilling hole at the back of the plate must be 45.5 mm from the front edge of the table.
• The center of the single drilling hole must be 23 mm from the width of each of the two front holes.
The Side Edge of the DMIclassic C handset does not have to be ush with the Table‘s Side Edge. To avoid pro-
trusion over the side edge, leave a gap of at least 70 mm from the central hole to the side edge of the table.
31.5 mm
23 mm
45.5 mm
DESK EDGE
46 mm
Fig. 6: Drilling template, DMIclassic C

DMICLASSIC FAMILY - OPERATING MANUAL // PAGE 17
6 ASSEMBLY
This chapter describes the process of installing the DMIclassic Family handset into the DYNAMIC MOTION
System.
6.1 SAFETY DURING ASSEMBLY
WARNING Risk of death or serious injury through electric shocks
DMIclassic Family handsets are electrical devices. Basic safety precautions must be
taken at all times. Failure to observe electrical safety precautions may lead to death or
serious injury through electric shocks.
• Never open the Handset
• Ensure that the Handset is not connected to the Power Unit during assembly
• Do not convert or modify the Handset in any way
• Check the housing and cables of the Handset for visible damage. Do not install or
operate damaged products.
CAUTION Risk of minor or moderate injury through improper handling
Improper handling of the product during assembly may lead to minor or moderate
injury through cutting, pinching, and crushing.
• Avoid contact with sharp edges
• Be careful while handling tools that may cause personal injury
• Ensure assembly complies with the generally accepted standards and guidelines of
electrical engineering and furniture manufacturing
• Read all instructions and safety advice carefully
CAUTION Risk of minor or moderate injury through tripping
During assembly and operation, poorly routed Cables may become a trip hazard.
Tripping over Cables may lead to minor or moderate injury.
• Ensure that Cables are routed properly to avoid trip hazards
• Be careful not to trip over Cables when installing the Handset
NOTICE Ensure proper ESD handling during assembly. Damage that can be attributed to elec-
trostatic discharge will void warranty claims.
NOTICE To avoid damage to the product, measure the dimensions of the Handset before assembly.
NOTICE Before assembly, all parts must be acclimatised to the ambient conditions.
NOTICE Do not lift the Handset by its cable. This will cause irreparable damage to the product.
INFO Perform a product risk assessment so that you can respond to potential residual ha-
zards. Assembly instructions must be included in your end user Operating Manual.

DMICLASSIC FAMILY - OPERATING MANUAL // PAGE 18
6.2 REQUIRED COMPONENTS
1x DMIclassic Family handset
2x (DMIclassic B) or
3x (DMIclassic C)
Mounting Screws
(for DMIclassic B supplied by Reseller)
Tool Drill or Drilling Machine
Tool Screwdriver
INFO Screw specications for DMIclassic B
The mounting points have a width of 4.3 mm. The Mounting Screws should hold
the Handset safely and securely in place. Exact specications can be provided by
LOGICDATA on request.
INFO Screw Specications for DMIclassic C
The Mounting Screws are provided by LOGICDATA with the Handset. These are 16
mm in length, with a 3 mm thread and 8 mm head diameter.
6.3 PROCESS
NOTICE DMIclassic C handset is equipped with a sliding mechanism and should always be
mounted in the retracted position.
1. Place the Handset into the rails of the sliding plate (applicable only for DMIclassic C).
2. Position the Handset in the desired position under the table top and mark the position of the
Mounting Points. For DMIclassic C ensure that the Handset is in the retracted position and
does not protrude from the edge of the Table Top.
3. Drill the holes for the Mounting Screws into the Table Top at the marked points.
4. Use the screwdriver and Mounting Screws to attach the Handset to the Table Top at the drilled holes.
NOTICE The required tightening torque depends on the material of the Table Top. Do not
exceed 2 Nm.
6.4 COMPLETING ASSEMBLY
After the DMIclassic Family handset is attached to the Table Top, you must connect the Cable to the Power
Hub. Refer to the manual for your chosen Power Hub for instructions.

DMICLASSIC FAMILY - OPERATING MANUAL // PAGE 19
7 SYSTEM INFORMATION
7.1 DMICLASSIC B
When a DMIclassic B Handset is installed alongside the DYNAMIC MOTION system, system information is
communicated via ashes of the LED Signal Light. Possible signals are as follows:
SIGNAL MESSAGE REQUIRED ACTIONS
No Light System operating normally Operate the DM System as normal
System not connected properly See Chapter 4 for connection instructions
Red Light Blinking System Error Warning Release all keys and wait for 5 seconds.
Then try to repeat the action again.
Disconnect all components from the
Power Hub.
Disconnect the Power Hub from the
Mains. Check the Power Hub for overhea-
ting. Let cool if necessary.
Check all cable connections and recon-
nect the system.
If problem persists: Perform a Position
Reset Procedure (Chapter 4.7).
Contact LOGICDATA.
Green Light Blinking System Start-up Wait until the LED has stopped blinking
to continue. Do no press any buttons.
Reset in Progress
Duty Cycle Exceeded
Collision Detected (ISP) Remove the obstruction from the Table
System. Remove unnecessary loads from
the Table Top. Operate the DM System as
normal.
Green Light Flashing
Rapidly
Position Reset Required. Perform a Position Reset Procedure
(System Manual, Chapter 4.7).
NOTICE Do not operate the DYNAMIC MOTION system if problems persist. Contact
LOGICDATA for further information.

DMICLASSIC FAMILY - OPERATING MANUAL // PAGE 20
7.2 DMICLASSIC C
When a DMIclassic C Handset is installed alongside the DYNAMIC MOTION system, error messages are
displayed on the digital display panel. These are as follows:
SIGNAL MESSAGE REQUIRED ACTIONS
The display shows
“Hot”.
Overheating protection has been
activated.
Wait for the overheated components to
cool.
The display shows
“ISP”.
The system has recognized a collision. Release all Keys and wait for the Drive
Back function to be completed.
The display shows
“Con”.
The system has recognized a connection
error.
Release all Keys and wait for 5 seconds.
Then, try again.
Disconnect the Power Unit from the
Mains. Then, disconnect System from the
Power Unit. Reconnect the system again,
then operate the DM System as normal.
Handset displays error
code “CXX” (e.g. C17).
An internal error has occurred. Read the table below to nd the correct
response to the error code shown.
Hot
ISP
Con
C1 7
