Logik I-L90 User manual

I-L90
Recharger Stand
Instruction Manual
Features
•You can listen to your iPOD whilst charging
•Compatible with iPOD/mini iPOD consoles
•You can use USB or Firewire Cables to download data from your computer
•The power adapter allows you to charge your iPOD while away from your PC
Supplied with:
•AC/DC Adapter for charging the iPOD/mini iPOD battery
•3.5mm jack cable to connect to your speaker system
•Different sized plates for fitting your own iPOD/mini iPOD
Precautions
•Only for use with iPOD/mini iPOD consoles – do not use the recharger stand with any other device
•Do not use the USB Cable for downloading while recharging with AC/DC Adapter
•Do not use the USB Cable and Firewire Cable at the same time for downloading
•Do not store in temperatures greater than 60°C
•Please notice the adapter voltage and polarity when using other AC/DC adapters
•If your computer can not detect your iPOD, please unplug and reconnect to the USB or Firewire port
•Place your recharger stand on a stable, level surface
Warning
Disconnect the power adapter before connecting USB or Firewire. Only use one connection
at a time. Using more that one of the following at the same time, Power Adapter, Firewire or
USB, can damage the product.
Operation
1. Power off the iPOD/mini iPOD console before plugging into the Recharger Stand
2. Fit the iPOD/mini iPOD to match with the correct size of Plate
3. Insert iPOD/mini iPOD onto the Recharger Stand (with the correct size of Plate)
4. Using the Firewire or USB extension cable to download data from computer by connecting one end to
your computer and the other end to this Recharger Stand according to the connectors
5. Use the AC/DC Adapter for charging the iPOD/mini iPOD battery
6. Use the 3.5mm stereo jack cable socket with the 3.5mm cable to connect to external equipment
7. Turn on iPOD/mini iPOD and your computer before downloading with Firewire or USB extension cable
8. Turn off and unplug the iPOD/mini iPOD when it is not in use
9. Disconnect the cable(s) or AC/DC Adapter from Recharger Stand and your computer when not in use

Specification
Input Voltage: AC110-240V 47-63Hz 150mA (AC/DC adapter)
Output Voltage: DC 9V 530mA
USB version: 2.0
Line output jack for 3.5mm plug
USB and Firewire inputs
Partmaster Direct can provide accessories, spares, batteries and replacement
parts with Next Day Delivery available upon request.
Please call:
0870 600 1338
(UK customers only)
Calls charged at National Rate
…or visit our website at www.partmaster.co.uk
This symbol on the product or in the instructions means that your electrical and electronic equipment should be
disposed at the end of its life separately from your household waste. There are separate collection systems for
recycling in the EU.
For more information, please contact the local authority or your retailer where you purchased the product.
