Logik L22FPS10 User manual

Food Processor
Instruction Manual
L22FPS10
L22FPS10_IB_final110218.indd 1 18/02/2011 12:12 PM

L22FPS10_IB_final110218.indd 2 18/02/2011 12:12 PM

Contents
Unpacking.......................................................................................................4
Before Using for the First Time ......................................................................5
Product Overview...........................................................................................5
Operation. .......................................................................................................6
Mounting the Food Processing Bowl and the Safety Screw Cap ..................... 6
Knife Blade ........................................................................................................................... 6
Slicing / Shredding Plate................................................................................................. 7
Beater..................................................................................................................................... 7
Fitting the Lid on the Processing Bowl ...................................................................... 7
Built-in safety lock............................................................................................................. 8
Feed Tube and Pusher......................................................................................................8
Blender .................................................................................................................................. 9
Cleaning ........................................................................................................11
Blender quick-clean operation...................................................................................11
Hints and Tips ...............................................................................................12
Processing Quantities ..................................................................................13
Specication .................................................................................................15
Safety Warnings............................................................................................16
L22FPS10_IB_final110218.indd 3 18/02/2011 12:12 PM

4
Safety Screw Cap
(P.N. : 002396983)
Processor Bowl
(P.N. : 502647513)
Beater
(P.N. : 002396953)
Blender Lid
(P.N. : 002396923)
Shaft
(P.N. : 502647473)
Processor Lid
(P.N. : 502649873)
Food Pusher
(P.N. : 002260553)
Slicing / Shredding Plate
(P.N. : 502647483)
Blender Jar
(P.N. : 502647243)
Filler Cap
(P.N. : 002241073)
Knife Blade
(P.N. : 502647463)
Instruction Manual
(P.N. : L22FPS10-002)
Thank you for purchasing your new Logik Food Processor.
We recommend that you spend some time reading this instruction manual
in order that you fully understand all the operational features it offers. You
will also find some hints and tips to help you resolve any issues.
Read all the safety instructions carefully before use and keep this
instruction manual for future reference.
Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
If items are missing, or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
Food Processor
Instruction Manual
L22FPS10
L22FPS10_IB_final110218.indd 4 18/02/2011 12:12 PM

5
Before Using for the First Time
1. Remove all packaging including the plastic blade covers from the knife blade. The
plastic blade cover should be kept to protect knife blade.
2. Retain the packaging. If you dispose of it please do so according to your local
recycling regulations.
3. Wash the parts: see Cleaning.
Product Overview
Blender Lid
Filler Cap
Pusher
Safety Interlock
Safety Interlock
Safety Screw Cap Slicing / Shredding Plate Beater Knife Blade
Processor Bowl
Feed Tube
Processor Lid
Blender Jar
Motor Unit
Safety Interlock
PULSE/OFF/LOW/
HIGH Control
L22FPS10_IB_final110218.indd 5 18/02/2011 12:12 PM

6
Operation
The food processor bowl will only operate with the safety screw cap attached to
the motor unit. The blender will only operate with the processor bowl attached
to the motor unit see the table below.
Mounting the Food Processor
Bowl and the Safety Screw Cap
Mount the processor bowl on the motor unit
by turning the handle in the direction of the
arrow until you hear a click. Mount the safety
screw cap to the motor unit.
To Operate
Food Processor
Blender
The cutting edges of the blade are very
sharp. Avoid touching them!
1. Place the knife blade down onto the centre post
inside the processor bowl.
2. Put the ingredients in the processor bowl. Pre-cut
large pieces of food into pieces of approx. 3x3x3cm.
Put the processor lid on the processor bowl.
3. Put the pusher in the feed tube.
4. Turn the control to PULSE position (HIGH or LOW for continuous operation).
Hold the PULSE position for about 2-3 seconds and check your results. Repeat for
desired consistency. It is better to use several short operations rather than a single long
one unless mixing ingredients that require longer processing times.
After you have finished food processing, turn the control to OFF position. Allow the
Knife Blade to stop running.
Carefully remove the Knife Blade from the processor bowl. Unlock the processor bowl
by turning the handle to the left, and lift the processor bowl off.
Knife Blade
The knife blade can be used for chopping, mixing,
blending and pureeing.
L22FPS10_IB_final110218.indd 6 18/02/2011 12:12 PM

7
Never process hard ingredients like ice cubes. Cutting edges are very sharp.
Avoid touching them!
When you have to cut large amounts of food, process only small batches at a
time and empty the processor bowl regularly between batches.
Slicing / Shredding Plate
1. Put the processor bowl on the motor unit, turn the handle to lock into place and fit the
shaft onto the centre post.
2. Place the slicing / shredding plate onto the shaft.
3. Put the processor lid on the processor bowl.
4. Put the ingredients in the feed tube. Pre-cut large chunks to make them fit into the
feed tube.
5. Fill the feed tube evenly for the best results.
6. Select the preferred processing speed on the control.
7. Press the pusher lightly onto the ingredients in the feed tube.
Beater
You can use the beater to whisk eggs, egg whites, instant puddings and cream only.
1. Put the processor bowl on the motor unit and turn it to the left until you hear a ‘click‘.
2. Fit the beater onto the centre post.
3. Put the ingredients into the processor bowl, put the processor lid on the processor
bowl and turn it until it’s locked and you hear a click.
4. Select your preferred process speed by turning the control.
Fitting the Processor Lid on the Processor Bowl
Put the processor lid on the processor bowl. Turn
the processor lid in the direction of the arrow until
you hear a click (this requires some force).
L22FPS10_IB_final110218.indd 7 18/02/2011 12:12 PM

8
Feed Tube and Pusher
1. Use the feed tube to add liquid and/or solid
ingredients. Use the pusher to push solid ingredients
through the feed tube.
2. You can also use the pusher to close the feed tube in
order to prevent ingredients from escaping through
the feed tube.
M
A
X
F
I
L
L
• Control the chopping time to prevent the food from becoming too finely
chopped.
• Do not let the appliance run too long when you are chopping (hard) cheese.
The cheese will become too hot, start to melt and turn lumpy.
• Do not use the blade to chop very hard ingredients like coffee beans,
turmeric, nutmeg and ice cubes, as this may cause the blade to get blunt.
If food sticks to the blade or to the inside of the processor bowl:
• Turn the appliance off.
• Remove the processor lid from the processor bowl.
• Remove the ingredients from the blade or from the wall of the processor
bowl with a spatula.
• The processor bowl can only be used without the blender attached to the
motor unit. If you use the unit without the blender, the safety screw cap must
be fitted to the motor unit.
• The food processor can only operate when the safety screw cap is attached
to the motor unit. The processor bowl will not operate if the blender jar is
attached to the motor unit.
Built-in safety lock
(For both Food Processor and Blender)
The motor unit, the processor bowl and the processor lid have
been provided with lock and unlock marks. The appliance will
only function if the lock mark on the motor unit and the lock
mark on the safety screw cap are aligned properly.
Make sure that the lock mark on the processor lid and the lock
mark on the processor bowl are aligned properly.
L22FPS10_IB_final110218.indd 8 18/02/2011 12:12 PM

9
Blender
The blender is intended for:
• Blending fluids, e.g. dairy products, sauces, fruit juices, soups, mixed drinks, sweet teas
and shakes.
• Mixing soft ingredients, e.g. pancake batter or mayonnaise.
• Pureeing cooked ingredients, e.g. for making baby food.
• The blender can only operate with the food processor bowl attached to the motor unit.
1. To attach the blender jar, remove the safety
screw cap.
2. Mount the processor bowl on the motor unit by
turning the handle in the direction of the arrow
until you hear a click.
3. Mount the blender jar onto the motor unit by
turning it in the direction of the arrow until it is
firmly fixed.
4. Put the ingredients in the blender jar.
5. Close the blender lid before you start processing.
6. Select your preferred blending speed. The blender
will start to operate. During the blending process
the speed can be adjusted by turning the control.
The blender cannot be used without the
processor bowl attached to the motor unit.
• Pour the liquid ingredients into the
blender Jar through the hole in the
blender lid.
• Hot liquids (not boiling) and hot foods
can be processed in the blender jar.
• Be sure to process small amounts of
liquids - 2 cups or less at a time. Larger
amounts may leak from the blender jar.
• The longer you let the appliance run
(maximum 3 minutes), the finer the
blending result will be.
• Pre-cut solid ingredients into smaller pieces before putting them in the blender jar. If
you want to prepare a large quantity, process small batches instead of trying to process
a large quantity at once.
• Hard ingredients e.g. soy beans for soy bean milk, must be soaked in water before they
are processed.
• Crush ice cubes by placing the ice cubes in the jar, close the blender and use the pulse
function.
L22FPS10_IB_final110218.indd 9 18/02/2011 12:12 PM

10
If ingredients stick to the wall of the blender jar:
1. Switch the appliance off and unplug it.
2. Open the blender lid.
3. Use a spatula to remove the ingredients from the wall of the blender jar.
4. Keep the spatula at a safe distance from the blades (approx. 2 cm).
• Never open the blender lid while the appliance is still running.
• Never use your hands to reach into the blender jar.
• If you are not satisfied with the results, let the appliance run briefly using the PULSE
function. You can also achieve a better result by stirring the ingredients with a spatula
(not while the blender is running), or by pouring some of the contents out in order to
process a smaller amount.
• In some cases the ingredients are easier to blend if you add some liquid e.g. lemon
juice when blending fruits.
L22FPS10_IB_final110218.indd 10 18/02/2011 12:12 PM

11
Cleaning
• Always switch off and unplug the unit before cleaning.
• Never let the motor unit, mains cable or plug get wet.
• Wipe the motor unit with a damp cloth, then dry. Do not immerse the motor unit in
water.
• Immediately after use, always clean the parts that have come into contact with food,
using hot water and washing-up liquid.
• The slicing/shredding plate and knife blade can be cleaned in warm soapy water or in
the dishwasher.
• Make sure that the cutting edges of the blades and the plate do not come into contact
with hard objects. This could cause them to become blunt.
• Certain ingredients may cause discolourations of accessories. This is perfectly normal.
It will not harm the plastic or affect the colour of your food. The discolourations usually
disappear after some time.
• Handle blades and cutting plates with care especially during cleaning as they are
extremely sharp.
• Wash all attachments by hand, then dry thoroughly.
• Alternatively, they can be washed on the top rack of your diswasher. A short low
temperature programme is recommended.
Blender quick-clean operation
1. Pour lukewarm water (not more than 0.5 litres) and some washing-up liquid into the
blender jar.
2. Close the blender lid.
3. Let the appliance run for a few seconds by pressing the pulse control.
4. Detach the blender jar, remove the blender lid and rinse both with clean water.
L22FPS10_IB_final110218.indd 11 18/02/2011 12:12 PM

12
Hints and Tips
What is a Pulse Function?
• The pulse control is used when you need short bursts of power at the optimum speed.
This is controlled by the user which means you control how long the appliance runs for.
It is a useful way of avoiding over-processing. For example, it can be used to fold fruit
into a cake mixture at the end of processing.
What is the difference between a Food Processor and a Breadmaker?
• A breadmaker is primarily for mixing dough and cake mixtures. A food processor can do
these jobs but not with the efficiency of a breadmaker. If you are planning on making
cakes you should consider how often you will be doing this job. If it is going to be a
common occurrence then a breadmaker would be a better choice.
Why won’t my processor or blender switch on?
• Try checking that the interlock system is correctly in place. Both the processor and
blender need to have the processor bowl and the processor lid on properly in order
to start processing, this is a safety feature so that the blades cannot be spinning while
exposed. When interlocked properly the markings on the processor bowl, processor lid
and motor unit are aligned properly.
• Check whether the motor unit has the safety screw cap or the blender correctly
positioned on it. The appliance will not function if neither are properly mounted onto
the motor unit.
Can I process Hot ingredients?
• Hot liquids (not boiling) and hot foods can be processed in the blender.
Are the attachments dish washable?
• All attachments can be washed on the top rack of your dishwasher. The motor unit
must never be washed in a dishwasher. A short low temperature programme is
recommended.
L22FPS10_IB_final110218.indd 12 18/02/2011 12:12 PM

13
Processing Quantities
Ingredients &
results
Max.
Quantity Procedure Applications
Apples, carrots,
celeriac -
shredding and
slicing
500g Cut the vegetables into pieces that
fit into the tube. Fill the tube with
the pieces and slice them while
pressing the pusher lightly.
Salads, raw
vegetables
Batter (pancake) -
whisking
750ml
Milk
First pour the milk into the blender
and then add the dry ingredients.
Mix the ingredients for approx. 1
minute. If necessary, repeat this
procedure 2 times. Then stop for a
few minutes to allow the appliance
to cool down.
Pancakes,
waffles
Bread crumbs -
chopping
100g Use dry, crispy bread. Breadcrumbed
dishes, au
gratin dishes
Butter cream
(creme au beurre) -
whisking
300g Use soft butter for a light result. Deserts,
toppings
Cheese (Parmesan)
- chopping
200g Use a piece of rindless Parmesan
and cut it into approx. 3 x 3 cm
pieces.
Garnishing,
soups, sauces,
au gratin
dishes
Cheese (Gouda) -
shredding
200g Cut the cheese into pieces that fit
into the tube. Press carefully with
the pusher.
Sauces,
pizzas, au
gratin dishes,
fondues
Chocolate -
chopping
200g Use hard, plain chocolate. Break it
into 2cm pieces.
Garnishing,
sauces, pastry,
puddings,
mousses
Cooked peas,
beans - pureeing
250g Use cooked peas or beans. Purees, soups
Cooked vegetables
and meats -
pureeing
500g For a coarse puree, add only a little
liquid. For a fine puree, keep adding
liquid until the mixture is smooth.
Baby and
infant food
Cucumbers -
slicing
2
cucumbers
Put the cucumber in the tube and
press it down carefully.
Salads,
garnishing
Egg whites -
whisking
4
egg white
Use egg whites at room
temperature. Note: use at least 2
egg whites.
Puddings,
soufflees,
meringues
L22FPS10_IB_final110218.indd 13 18/02/2011 12:12 PM

14
Ingredients &
results
Max.
Quantity Procedure Applications
Fruit (e.g. apples,
bananas, water
chestnut) -
blending /
chopping
500g Tip: add a little lemon juice to
prevent the fruit from discolouring.
When blending add some liquid to
obtain a smooth puree.
Sauces, jams,
puddings,
baby food
Garlic - chopping 300g Peel the garlic. Press the pulse
button several times to avoid
chopping the garlic too fine. Use at
least 150g.
Garnishing,
dips
Herbs (e.g.
parsley) -
chopping
Min. 50g Wash and dry the herbs before
chopping.
Sauces, soups,
garnishing,
herb butter.
Juices (e.g. made
of apple carrots
etc.) Juicing -
blending
500ml
(Total
amount)
Juice the fruits in the juicer. Fruit juices
Mayonnaise -
emulsifing
3 eggs All the ingredients must be at room
temperature. Note: use at least one
large egg, two small eggs or two
egg yolks. Put the egg and a little
vinegar in the bowl and add the oil
drop by drop.
Salads,
garnishing
and barbecue
sauces.
Meats (lean) -
mincing
500g First remove any sinews or bones.
Cut the meat into 3cm cubes.
Press the pulse button to get a
coarser chopping result.
Steaks tartar,
hamburgers,
meat balls
Meats, fish,
poultry (streaky) -
mincing
400g First remove any sinews or bones.
Cut the meat into 3cm cubes.
Press the pulse button to get a
coarser chopping result.
Steaks tartar,
hamburgers,
meat balls
Milkshakes -
blending
500ml milk Puree the fruit (e.g. bananas,
strawberries) with sugar, milk and
some ice cream and mix well.
Milkshakes
Mixture (cake) -
mixing
4 eggs The ingredients must be at room
temperature. Mix the softened
butter and the sugar until the
mixture is smooth and creamy.
Then add milk, eggs and flour.
Various cakes.
Nuts - chopping 250g Use the pulse button for coarse
chopping. Stop the process if you
want a coarse result.
Salads,
puddings, nut
bread, almond
paste.
Onions - chopping 500g Peel the onions and cut them into 4
pieces. Stop the process after 2
pulses to check the result.
Salad, cooked
food, stir-fries,
garnishing
L22FPS10_IB_final110218.indd 14 18/02/2011 12:12 PM

15
Ingredients &
results
Max.
Quantity Procedure Applications
Onions - slicing 300g Peel the onions and cut them into
pieces that fit into the tube.
Note: use at least 100g.
Salad, cooked
food, stir-fries,
garnishing.
Poultry - mincing 200g First remove any sinews or bones.
Cut the meat into 3cm cubes. Use
the pulse button for a coarser
chopping result.
Minced meat.
Soups - blending 500ml Use cooked vegetables. Soups, sauces.
Whipping cream -
whipping
500ml Use cream that comes straight from
the refrigerator. Note: use at least
125ml cream. The whipped cream is
ready after approx. 20 seconds.
Garnishing,
cream,
icecream
mixtures
Specication
Model L22FPS10
Mains Supply: 230V ~50Hz
Power consumption: 500W
Features and specifications are subject to change without prior notice.
L22FPS10_IB_final110218.indd 15 18/02/2011 12:12 PM

16
Safety Warnings
When using electrical appliances basic safety precautions should always be followed,
including the following:
• Read all the instructions carefully before using the appliance and keep them for future
reference.
• The blades and plates are very sharp, handle with care. Always hold the knife blade
by the finger grip at the top, away from the cutting edge, both when handling and
cleaning.
• Always remove the knife blade before pouring contents from the processor bowl.
• Keep hands and utensils out of the processor bowl or blender jar while the appliance is
connected to the mains socket.
• In order to avoid a hazardous situation, this appliance must never be connected to a
timer switch.
• Excessive strain may cause the motor unit to overheat and stop. Please don’t operate
this appliance for longer than 3 minutes. Wait for around 5-10 minutes for the motor
unit to cool. A safety protector in the motor unit prevents overheating. If the motor
unit stops, turn the appliance off.
• Always switch off and unplug before fitting or removing parts, after use and before
cleaning.
• For your protection, this appliance has an interlock system so the food processor won’t
operate unless you remove the blender jar and close the fixing hole with the safety
screw cap. The processor bowl needs to lock onto the motor unit and the processor lid
must be correctly locked onto the processor bowl.
• Always lock the processor bowl or blender jar to the motor unit before attempting to
fit the processor lid.
• Always unlock the processor lid before attempting to remove the processor bowl from
the motor unit.
• This appliance will be damaged and may cause injury if the interlock mechanism is
subjected to excessive force.
• Before removing the processor lid from the processor bowl, switch the appliance off
and wait until the attachment / blades have completely stopped.
• Place the processor lid on the processor bowl in the right position. Both the motor unit
and the safety screw cap, processor bowl, processor lid and safety screw cap have been
provided with marks. Make sure the mark on the motor unit is directly opposite the
mark on the safety Screw cap, processor bowl and processor lid.
• Thoroughly clean the parts that will come into contact with food before you use the
appliance.
• Do not fill exceed the quantities and preparation times indicated in the table.
• Do not exceed the maximum mark indicated on the bowl.
• Never use your fingers to push food down the feed tube. Always use the supplied
pusher.
• Never use any accessories or parts other than those provided with this appliance.
• Never let the motor unit, mains cable or plug get wet.
• Do not attempt to chop ice in this food processor; it will damage the processor bowl
and dull the knife blade. Only chop ice in the blender jar.
L22FPS10_IB_final110218.indd 16 18/02/2011 12:12 PM

17
• This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning the use of the appliance
by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• Do not use the appliance if the mains cable, plug or other parts are damaged. Do not
let excess mains cable hang over the edge of a table or worktop or touch hot surfaces.
• Never leave the appliance unattended when operating.
• If the mains cable is damaged it must be replaced by the manufacturer, an authorised
service agent or a qualified technician in order to avoid a hazard.
• Never use a damaged appliance. Get it checked or repaired by a qualified technician.
• Never misuse your appliance and only use it for its intended domestic use.
• Make sure your electricity supply is the same as the one shown on the underside of
your appliance.
• Do not attempt to operate the appliance unless the processor bowl and processor lid
are correctly in place. Be sure the motor unit is on a flat, dry, clean surface before you
begin processing.
• Always switch the appliance off by turning the control to the OFF position before
changing accessories or approaching parts which move in use.
• Wait until moving parts have stopped running before you remove the lid of the
appliance.
• If you are processing a liquid that is hot or tends to foam, do not put more than 1.25
litre into the Blender Jar to avoid spillage.
• Unplug the appliance immediately after use.
L22FPS10_IB_final110218.indd 17 18/02/2011 12:12 PM

NOTE: If you require a replacement for any of the items listed below, please quote their
corresponding part numbers:
Replacement Part Part Number
Safety Screw Cap 002396983
Blender Jar 502647243
Blender Lid 002396923
Food Pusher 002260553
Processor Lid 502649873
Filler Cap 002241073
Processor Bowl 502647513
Shaft 502647473
Slicing / Shredding Plate 502647483
Knife Blade 502647463
Beater 002396953
DSGRetailLtd•MaylandsAvenue•HemelHempstead
Herts•HP27TG•England
This symbol on the product or in the instructions means that
your electrical and electronic equipment should be disposed
at the end of its life separately from your household waste.
There are separate collection systems for recycling in the EU.
For more information, please contact the local authority or
your retailer where you purchased the product.
(P.N.: L22FPS10-002)
Visit Partmaster.co.uk today for the easiest way to
buy electrical spares and accessories. With over 1
million spares and accessories available we can
deliver direct to your door the very next day. Visit www.partmaster.co.uk or call
0844 800 3456 (UK customers only) Calls charged at National Rate.
L22FPS10_IB_final110218.indd 18 18/02/2011 12:12 PM

L22FPS10_IB_final110218.indd 19 18/02/2011 12:12 PM

L22FPS10_IB_final110218.indd 20 18/02/2011 12:12 PM
