Logik LSBSX18 User manual

American Style Fridge
Freezer
Instruction Manual
LSBSX18 / LSBSW18
LSBSX_W18_IB_RC_190430_grace.indd 1 30/4/2019 2:04 PM

LSBSX_W18_IB_RC_190430_grace.indd 2 30/4/2019 2:04 PM

Contents
Safety Warnings...................................................................................................................................4
Unpacking............................................................................................................................................8
Installation ...........................................................................................................................................9
Location ...............................................................................................................................................................................9
Levelling the Unit .............................................................................................................................................................9
Free Space Requirements .............................................................................................................................................9
Moving the Unit................................................................................................................................................................9
Cleaning Before Use ..................................................................................................................................................... 10
Before Using Your Unit................................................................................................................................................. 10
Product Overview..............................................................................................................................11
Operation ...........................................................................................................................................12
Temperature Setting .................................................................................................................................................... 12
Super Cool Mode........................................................................................................................................................... 12
Super Freeze Mode....................................................................................................................................................... 12
Smart Mode..................................................................................................................................................................... 13
Lock and Unlock............................................................................................................................................................. 13
Door Alarm....................................................................................................................................................................... 13
Noises Inside the Unit!................................................................................................................................................. 13
Tips for Keeping Food in the Unit............................................................................................................................ 14
Preparations for Freezing............................................................................................................................................ 14
Defrosting Frozen Food............................................................................................................................................... 15
Cleaning .............................................................................................................................................16
Defrosting ........................................................................................................................................................................ 16
Cleaning the Interior and the Exterior of the Unit............................................................................................. 16
Maintenance ......................................................................................................................................17
Changing the Internal Light ...................................................................................................................................... 17
Care When Handling / Moving the Unit................................................................................................................ 17
Servicing........................................................................................................................................................................... 17
Switching O for Long Periods of Time................................................................................................................. 17
Condensation.................................................................................................................................................................. 17
Disposal..............................................................................................................................................17
Specications.....................................................................................................................................18
Product Fiche .....................................................................................................................................18
LSBSX_W18_IB_RC_190430_grace.indd 3 30/4/2019 2:04 PM

Safety Warnings
For your continued safety and to reduce the risk of injury or electric shock,
please follow all the safety precautions listed below.
• Read all instructions carefully before using the unit and keep them for
future reference.
• Retain the manual. If you pass the unit onto a third party, make sure to
include this manual.
• This appliance is intended for indoor household use and similar
applications such as:
- farm houses and by clients in hotels, motels and other residential type
environment;
- bed and breakfast type environment;
- catering and similar non-retail applications.
• Ensure that the plug is easily accessible to enable disconnection from
the mains supply.
• If the mains cable is damaged, it must be replaced by the manufacturer,
its service agent or a qualied technician in order to avoid a hazard.
• Choose a location for your unit away from heat sources such as
radiators or res as refrigerant and vesicant are burnable.
• The unit must be manoeuvred by a minimum of 2 persons.
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
• Children aged from 3 to 8 years are allowed to load and unload
refrigerating appliances.
• Children should be supervised to ensure that they do not play with the
unit.
• If your unit is tted with a lock to prevent children being trapped inside,
keep the key out of reach and not in the vicinity of the unit.
• Do not store explosive substances such as aerosol cans with a
ammable propellant in this appliance.
• Do not store bottles or glass containers in the freezer compartment.
Contents can expand when frozen (zzy drinks) which may break the
bottle and damage your freezer compartment. (If applicable)
4
LSBSX_W18_IB_RC_190430_grace.indd 4 30/4/2019 2:04 PM

• To avoid contamination of food, pay attention to the following:
-opening the door for long periods can cause a significant increase of
the temperature in the compartments of the appliance;
-clean regularly surfaces that can come in contact with food and
accessible drainage systems;
-clean water tanks if they have not been used for 48 hours; flush the
water system connected to a water supply if water has not been
drawn for 5 days;
-store raw meat and fish in suitable containers in the refrigerator so
that it is not in contact with or drip onto other food;
-two-star frozen-food compartments are suitable for storing pre-
frozen food, storing or making ice-cream and making ice cubes;
-one-, two- and three-star compartments are not suitable for the
freezing of fresh food;
-if the refrigerating appliance is left empty for long periods, switch
off, defrost, clean, dry and leave the door open to prevent mould
developing within the appliance.
WARNING
IT IS HAZARDOUS FOR ANYONE OTHER THAN AUTHORISED
SERVICE PERSONNEL TO CARRY OUT SERVICING OF REPAIRS WHICH
INVOLVE THE REMOVAL OF COVERS.
TO AVOID THE RISK OF AN ELECTRICAL SHOCK DO NOT ATTEMPT
REPAIRS YOURSELF.
5
LSBSX_W18_IB_RC_190430_grace.indd 5 30/4/2019 2:04 PM

The table below contains general guidelines on the storage of food in the
refrigerator.
Refrigerator location Type of food
Fridge door • Foods with natural preservatives, such as
jams, juices, drinks, condiments.
• Do not store perishable foods.
Crisper bin (salad bin) • Fruits, herbs and vegetables should be
placed separately in the crisper bin.
• Do not store bananas, onions, potatoes,
garlic in the refrigerator.
• Fridge shelf – bottom
• Chiller bin
Raw meat, poultry, fish (for short-term
storage)
Fridge shelf – middle Dairy products, eggs
Fridge shelf – top Foods that do not need cooking, such as
ready-to-eat foods, deli meats, leftovers.
Freezer drawer/shelf • Foods for long-term storage.
• Bottom drawer/shelf for raw meat, poultry,
fish.
• Middle drawer/shelf for frozen vegetables,
chips.
• Top drawer/shelf for ice cream, frozen
fruit, frozen baked goods.
6
LSBSX_W18_IB_RC_190430_grace.indd 6 30/4/2019 2:04 PM

WARNING
• Keep ventilation openings in the unit enclosure or in the built-in
structure clear of obstructions.
• Do not use mechanical devices or other means to accelerate
the defrosting process, other than those recommended by the
manufacturer.
• Do not use electrical appliances inside the food storage
compartments of the unit, unless they are of the type
recommended by the manufacturer.
• Do not damage the refrigerant circuit (The refrigerant is a
very environmental-friendly gas but is also combustible. Take
care when transporting or moving the unit to ensure that the
refrigeration circuit is not damaged. In the event of damage
avoid naked ames or ignition sources and ventilate the room in
which the unit is placed for a few minutes.)
• When positioning the appliance, ensure the supply cord is not
trapped or damaged.
• Do not locate multiple portable socket-outlets or portable power
supplies at the rear of the appliance.
WARNING: Risk of fire/flammable materials
7
LSBSX_W18_IB_RC_190430_grace.indd 7 30/4/2019 2:04 PM

Unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
Main Unit
Freezer Glass Shelf x 4
Fridge Door Shelf x 3
Freezer Drawer x 2 Fridge Drawer x 2
Egg Tray x 2 Ice Tray
Instruction Manual
Freezer Door Shelf x 4
Instruction
Manual
Fridge Glass Shelf x 4
Thank you for purchasing your new product.
We recommend that you spend some time reading this instruction
manual in order that you fully understand all the operational features it
oers.
Read all the safety instructions carefully before use and keep this
instruction manual for future reference.
If items are missing or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
8
LSBSX_W18_IB_RC_190430_grace.indd 8 30/4/2019 2:04 PM

Location
When selecting a position for your unit you should make sure the oor is at and rm, and
the room is well ventilated with an average room temperature of between 10°C and 38°C.
Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct
sunlight as it may increase the electrical consumption. Extreme cold ambient temperatures
may also cause the unit not to perform properly. This unit is not designed for use in a garage
or outdoor installation. Do not drape the unit with any covering.
Levelling the Unit
To do this adjust the two levelling feet at the front of the unit.
If the unit is not level, the doors and magnetic seal alignments
will not be covered properly.
Make sure the levelling feet (not the rollers) are well secured to
the oor to prevent movement of the appliance.
Free Space Requirements
When installing the unit, ensure that 25
mm of free space is left at both sides, 50
mm at the rear and 25 mm at the top of
the unit.
Please ensure there is more than twice
the width and depth distance space of
the unit to fully open the door.
Y mmY mm
X mmX mm
Moving the Unit
Adjust the levelling feet until the rollers can roll freely.
9
INSTALLATION
LSBSX_W18_IB_RC_190430_grace.indd 9 30/4/2019 2:04 PM

Before Using Your Unit
Before placing any food in your unit, turn it on and wait for 24 hours, to make sure it is
working properly and to allow it time to fall to the correct temperature. Your unit should not
be overlled.
Cleaning Before Use
Wipe the inside of the unit with a weak solution of bicarbonate soda. Then rinse with warm
water using a sponge or cloth. Wipe completely dry before replacing the shelves, drawers and
salad bin. Clean the exterior of the unit with a damp cloth.
If you require more information refer to the Cleaning section.
• Before Plugging in YOU MUST
Check that you have a socket which is compatible with the plug supplied with the
unit.
• Before Turning On!
Do not turn on until two hours after moving the unit. The coolant uid needs time
to settle.
10
INSTALLATION
LSBSX_W18_IB_RC_190430_grace.indd 10 30/4/2019 2:04 PM
