Logitech LIGHTSPEED G913 TKL User manual

G913 TKL / G915 TKL
LIGHTSPEED Wireless RGB Mechanical Gaming Keyboard
LIGHTSPEED 无线 RGB 机械游戏键盘
LIGHTSPEED 無線 RGB 機械式遊戲鍵盤
LIGHTSPEED 무선 RGB 기계식 게임 키보드

CONTENTS
English . . . . . . . . . . . . . . . . 3
简体中文 . . . . . . . . . . . . . . .14
繁體中文 . . . . . . . . . . . . . . 25
한국어 . . . . . . . . . . . . . . . 36

English 3
LIGHTSPEED CONNECTION
logitechG.com/support/G915-tkl

4English
BLUETOOTH®CONNECTION
G915 TKL
1 2 3
4
3 Sec.

English 5
CHARGING

6English
KEYBOARD FEATURES
1 2 3 4
1. Game Mode
2. Brightness
3. Battery Indicator
4. Media Controls

English 7
In addition to the lighting features available through G HUB software, G915 TKL has onboard
lightingeects. To select these eects, press and hold the Brightness button while pressing
thekeyboard number keys to select an eect:
• Brightness + key 1: Colorwave (left to right)
• Brightness + key 2: Colorwave (right to left)
• Brightness + key 3: Colorwave (center out)
• Brightness + key 4: Colorwave (bottom up)
• Brightness + key 5: Color cycle
• Brightness + key 6: Ripple
• Brightness + key 7: Breathing
• Brightness + key 8: User-stored lighting
• Brightness + key 9: User-stored lighting
• Brightness + key 0: Cyan blue
• Brightness + key -: Decreases eect speed
• Brightness + key +: Increased eect speed
User-stored eects are saved to the keyboard by G HUB software.
KEYBOARD FEATURES  LIGHTING FUNCTIONS

8English
GAME MODE BUTTON
KEYBOARD BACKLIGHTING
ONBOARD MEMORY
This button disables the standard Windows key and Menu key to prevent the Windows Start menu
fromactivating during a game, which might disrupt play. The game mode LED is lit during game mode.
Three onboard proles can be saved to G915 TKL. The proles are downloaded into the G915 TKL
through GHUB software, and are accessed by selecting M1, M2, or M3 when the keyboard is
inOnboard mode (selected from G HUB software, or when G HUB software is o or not installed).
Adjust keyboard brightness by cycling the keyboard brightness button.

English 9
KEYBOARD FEATURES  MEDIA CONTROLS
G915 TKL has media controls, located in the upper right corner of the keyboard.
• Volume roller — controls volume of the active audio on your PC.
• Skip back — goes to the beginning of a track, or to a previous track, depending on
theapplication.
• Play/Pause — starts or stops the audio or video source playback.
• Skip forward — goes to the end of the track or to the next track, depending on
theapplication.
• Mute — stops audio output.

10 English
KEYBOARD FEATURES  BATTERY INDICATOR
<15%
>15%
• Pulses green when charging.
• Shows green momentarily when started when battery is above 15%.
• Shows red when keyboard needs charging.

English 11
KEYBOARD FEATURES  WIRELESS CONTROLS
• LIGHTSPEED button selects LIGHTSPEED wireless connection, which connects to the PC or Mac
using the included receiver dongle. It shows white when connected, blue when wired connection.

12 English
KEYBOARD FEATURES  BLUETOOTH®
• Bluetooth button connects to devices via a Bluetooth connection. It shows blue when connected.

English 13
KEY CAP REMOVAL +REPLACEMENT
CARE AND CLEANING
To clean the keyboard, use a soft, lint-free or microber cloth. A damp cloth can be used.
Donotuseharsh cleaning solutions.
Do not immerse the keyboard or expose it to liquids.

14 简体中文
LIGHTSPEED 连接
logitechG.com/support/G915-tkl

简体中文 15
蓝牙™ 连接
1 2 3
4
代码
3 秒
G915 TKL
G913 TKL

16 简体中文
正在充电

简体中文 17
键盘特性
1 2 3 4
1.游戏模式
2.亮度
3.电池指示灯
4.媒体控制

18 简体中文
除了通 过 G HUB 软件提供的灯光功能外，G913 TKL 还具有板载灯光效果。欲选择板载效果，请在按住键
盘数字键的同时按住亮度按钮以选择效果：
• 亮度 + 1 键：色彩波浪（从左至右）
• 亮度 + 2 键：色彩波浪（从右至左）
• 亮度 + 3 键：色彩波浪（从中间向外扩散）
• 亮度 + 4 键 ：色 彩 波 浪（ 自 下 而 上 ）
• 亮度 + 5 键 ：色 彩 循 环
• 亮度 + 6 键 ：涟 漪
• 亮度 + 7 键 ：呼 吸 灯
• 亮度 + 8 键 ：用 户 存 储 的 光 效
• 亮度 + 9 键 ：用 户 存 储 的 光 效
• 亮度 + 0 键 ：青 蓝 色
• 亮度 + - 键 ：降 低 光 效 速 度
• 亮度 + + 键 ：提 高 光 效 速 度
用户存储的光效通过 G HUB 软件保存至键盘。
键盘特性  灯光功能

简体中文 19
游戏模式按钮
键盘背光
板载内存
此按钮将禁用标准的 Windows 键和菜单键，防止在游戏中激活 Windows 开始菜单，避免游戏中断。
游戏模式 LED 指示灯在游戏模式期间将亮起。
G913 TKL 可保存三个板载配置文件。通过 G HUB 软件将配置文件下载至 G913 TKL，当 键 盘 处 于 板 载
模 式 时（ 从 G HUB 软件中选择，或者当 G HUB 软件关闭或未安装时），可选择 M1、M2 或M3 启用这些
配置文件。
通过键盘亮度按钮循环调节键盘亮度。

20 简体中文
键盘特性  媒体控制
G913 TKL 具有媒体控制按钮，位于键盘右上部。
• 音量滚轮 - 控制 PC 正播放音频的音量。
• 后退 - 根据应用程序的不同，可跳转至此音轨的开始或前一个音轨。
• 播放/暂停 - 开始或停止音频或视频播放。
• 前进 - 根据应用程序的不同，可跳转至此音轨的结尾或下一个音轨。
• 静音 - 停止音频输出。
