Logitech ZONE WIRELESS Assembly Instructions

ZONE WIRELESS RECEIVER
Complete Setup Guide
Guide d'installation complet

CONTENTS
English . . . . . . . . . . . . . . . . .3
Français . . . . . . . . . . . . . . . .6
Español . . . . . . . . . . . . . . . . .9
Português . . . . . . . . . . . . . . 12

USB-A receiver
Light indicator
KNOW YOUR PRODUCT
WHAT’S IN THE BOX
USB-A receiver
3English

USB-C
USB-A
New receiver found
Press and hold the paring button on your
headset for 3 sec to enter pairing mode.
Show me how
Continue
Power
CONNECTING THE RECEIVER TO THE HEADSET
1. a. Insert the receiver into the computer USB-A
port.
b. Insert the receiver into the USB-C adapter.
Then insert the adapter into the computer
USB-C port.
2. Install and open Logi Tune Desktop. Download it from
www.logitech.com/logitune
3. Logi Tune Desktop will conrm that a new receiver
is found. Enter pairing mode on headset by pressing
the power button for 3 seconds. Click Continue.
4English

Connecting to your headset
Keep your receiver plugged in during the
connection process and make sure your
headset for is in pairing mode.
Cancel pairing
Zone Wireless connected
Your headset is ready to use.
Done
RECEIVER:
Height x Width x Depth: 21.5 mm x 13.6 mm x 6 mm
DIMENSIONS
www.logitech.com/support/zone-wireless-receiver
