Logitech Z323 User manual

Z323 SPEAKER SYSTEM
WITHSUBWOOFER
SYSTÈME DE HAUT-PARLEURS Z323
AVEC CAISSON DE BASSES
Complete Setup Guide
Guide d’installation complet

English 3
KNOW YOUR PRODUCT
RCA cable to
subwoofer
3.5 mm
auxiliarycable
Bass control
knob
Power and
volume controls
Subwoofer
Power plug
d-sub connector
tosubwoofer
Headphone jack
Left satellite
Right satellite
RCA input
3.5 mm auxiliary
input jack

English 4
CONNECT THE SPEAKERS
1. Plug the d-sub connector on the right satellite into the d-sub subwoofer port. Then plug the RCA connector
on the left speaker into the corresponding jack on the back of the subwoofer.
2. Plug the power plug into an electrical outlet.
3. Turn the speaker on using the power knob.
2
1
3
ON

English 5
CONNECT TO AUDIO SOURCE
1. For 3.5 mm connection:
Connect the 3.5 mm plug from the right speaker to the audio jack on your device (computer, tablet, smartphone, etc.)
Youcan also connect a device to the auxiliary input on the side of the right speaker.
2. For RCA connection:
Connect one end of the RCA cable to the corresponding RCA jack on the back of the subwoofer and the other end
totheRCA jack on your device (TV, gaming console, etc.).
Note: The RCA cable is not included in the box and must be purchased separately.
3. Plug your headphones into the headphone jack on the side of the right speaker. To adjust the volume of yourheadphones,
use the volume control knob on the front of the right speaker.
1
2
3
3.5mm

English 6
ADJUST THE VOLUME
To adjust the volume on the speakers, usethecontrol
knob on the right speaker. Turn clockwise
(counter-clockwise) to increase (decrease) the volume.
ADJUST THE BASS
Adjust the bass level by turning the bass control knob
onthe back of subwoofer. Turn bass knob to the right
fordeeper bass or to the left for less bass.
Bass Volume
