Logitech Z607 User manual

Z607
Setup Guide | Guide d’installation

2
English . . . . . . . . . . . . . . . . 3
Français . . . . . . . . . . . . . . .14
Español . . . . . . . . . . . . . . 25
Português . . . . . . . . . . . . . 36

English 3
3X
WHAT’S IN THE BOX
1. Subwoofer with xed power cable
and FM Radio Antenna
2. Five satellites - 2 front satellites,
2rear satellites, 1 center satellite
3. Remote control with button cell battery
4. Three RCA to RCA cables
5. One 3.5mm to RCA cable
6. User documentation

4English
AUX DVD (5.1CH)
R
F.R
R.R
SUB
F.L
R.L
CEN
L
FRONT
RIGHT
FRONT
LEFT
REAR
RIGHT
REAR
LEFT
CENTER
INPUT
OUTPUT
SPEAKER TERMINALS
– +
– +
AUX DVD (5.1CH)
R
F.R
R.R
SUB
F.L
R.L
CEN
L
FRONT
RIGHT
FRONT
LEFT
REAR
RIGHT
REAR
LEFT
CENTER
INPUT
OUTPUT
SPEAKER TERMINALS
– +
– +
1. Connect each satellite to its corresponding
plug on the subwoofer back panel.
2. Plug power cord in AC power outlet.
3. Turn on the system from the subwoofer
back panel switch.
5.1 SYSTEM SETUP

English 5
110˚
30˚
2
1
OPTIMAL 5.1 SURROUND SOUND SPEAKER PLACEMENT
1. For optimal sound place each
front speaker 30 degrees
from the center point.
2. For optimal sound place each
rear speaker 120 degrees from
center point.

6English
S
O
U
N
D
/SCAN/
1
6
2
3
4
5
7
8
1. Power ON/OFF
2. Sound
3. Decrease volume
4. Previous
5. Play/Pause/Scan/
Bluetooth®Pairing
6. Source
7. Increase volume
8. Next
CONTROLS ON SUBWOOFER

English 7
CONTROLS ON SUBWOOFER
1. Power ON/OFF:
Turns unit on/o.
2. Sound:
Switches between 5.1 and 2.1 channels
(only if input supports 5.1 channels)
3. Decrease the volume level:
4. Previous:
a. USB/SD mode:
i. Short press to select previous song.
ii. Long press to select previous folder.
b. FM mode:
i. Short press to select previous station.
ii. Long press to select previous automatically stored channel/station.
c. Bluetooth mode: short press to select previous song
5. Play/Pause/Scan/Bluetooth Pairing:
a. USB/SD Mode: Short press to play/pause music.
b. FM mode:
i. Short press to start auto search, second short press to select a station.
ii. All active frequencies are stored automatically in dierent channels.
c. Bluetooth mode:
i. Short press to play/pause music.
ii. Long press will start bluetooth pairing mode, LED will quickly blink ‘bt’
onthe display.

8English
6. Source:
a. Switch between Bluetooth, AUX, DVD, USB/SD and FM mode.
LED display on subwoofer panel will indicate related source
mode.
7. Increase the volume level:
8. Next:
a. USB/SD mode:
i. Short press to select next song.
ii. Long press to select next folder.
b. FM mode:
i. Short press to select next station.
ii. Long press to select next saved channel/station.
c. Bluetooth mode: short press to select next song.

English 9
1
2
LOCAL AUDIO SOURCES
1. SD card slot 2. USB drive slot
i. To play audio fully insert SD card into
SD card slot and select SD/USB source
from either remote control or controls
on the subwoofer.
ii. To remove SD card simply pull it out
of the slot.
iii. Z607 supports up to 32GB SDHC
cards with the following audio
leformats: MP3, WMA, WAV,
APE,FLAC.
SD card not included
i. To play audio insert USB drive into
USB slot and select SD/USB source
from either remote control or controls
on the subwoofer.
ii. To remove USB drive simply pull it out
of the slot.
iii. Z607 supports up to 32GB USBdrives
formatted FAT16 or FAT32 with
thefollowing audio le formats:
MP3,WMA, WAV, APE, FLAC.
USB drive not included

10 English
TUNE –
FM
RADIO
AUX
CHANNEL
LEVEL
—
VOL
+
VOL
RCA
5.1
2.1
SD
USB
TUNE + SCAN
1
46
8
11
10
14
7
9
5
12
13
2 3 1. Power ON/OFF:
Turns unit on/o.
2. Mute: Mutes the system.
3. 5.1 / 2.1: Switches from 5.1
to2.1channels as needed (only if
input supports 5.1 channels).
4. -Vol:
a. Decreases the master volume.
b. When selecting channel level
button rst, -voldecreases
thevolume of the selected
channel.
5. Channel Level:
Controls volume of speaker
channels. Press once to cycle
through front (F) speakers,
rear(R) speakers, center (C)
speaker, and subwoofer (S),
selectthe channel and adjust
thevolume of that unit or channel
from 5 to -5. System will save
channel volume adjustment.
REMOTE CONTROL
