Logitech Z607 User manual

Z607
Setup Guide

2
English . . . . . . . . . . . . . . . . 3
Deutsch . . . . . . . . . . . . . . .14
Français . . . . . . . . . . . . . . 25
Italiano. . . . . . . . . . . . . . . 36
Español . . . . . . . . . . . . . . 47
Português . . . . . . . . . . . . . 58
Nederlands . . . . . . . . . . . . 69
Svenska . . . . . . . . . . . . . . 80
Dansk . . . . . . . . . . . . . . . .91
Norsk. . . . . . . . . . . . . . . . 102
Suomi . . . . . . . . . . . . . . . 113
Ελληνικά . . . . . . . . . . . . . . 124
По-русски. . . . . . . . . . . . . . 135
Po polsku. . . . . . . . . . . . . . 146
Magyar. . . . . . . . . . . . . . . 157
Česká verze . . . . . . . . . . . . 168
Slovenčina . . . . . . . . . . . . . 179
Українська . . . . . . . . . . . . . 190
Eesti . . . . . . . . . . . . . . . . 201
Latviski. . . . . . . . . . . . . . . 212
Lietuvių. . . . . . . . . . . . . . . 223
Български. . . . . . . . . . . . . . 234
Hrvatski . . . . . . . . . . . . . . 245
Srpski. . . . . . . . . . . . . . . . 256
Slovenščina . . . . . . . . . . . . 267
Română . . . . . . . . . . . . . . 278
Türkçe . . . . . . . . . . . . . . . 289
300 . . . . . . . . . . . . . . . . ةيبرعلا
311 . . . . . . . . . . . . . . . .תירבע

English 3
3X
WHAT’S IN THE BOX
1. Subwoofer with xed power cable
and FM Radio Antenna
2. Five satellites - 2 front satellites,
2 rear satellites, 1 center satellite
3. Remote control with button cell battery
4. Three RCA to RCA cables
5. One 3.5mm to RCA cable
6. User documentation

4English
AUX DVD (5.1CH)
R
F.R
R.R
SUB
F.L
R.L
CEN
L
FRONT
RIGHT
FRONT
LEFT
REAR
RIGHT
REAR
LEFT
CENTER
INPUT
OUTPUT
SPEAKER TERMINALS
– +
– +
AUX DVD (5.1CH)
R
F.R
R.R
SUB
F.L
R.L
CEN
L
FRONT
RIGHT
FRONT
LEFT
REAR
RIGHT
REAR
LEFT
CENTER
INPUT
OUTPUT
SPEAKER TERMINALS
– +
– +
1. Connect each satellite to its corresponding
plug on the subwoofer back panel.
2. Plug power cord in AC power outlet.
3. Turn on the system from the subwoofer
back panel switch.
5.1 SYSTEM SETUP

English 5
110˚
30˚
2
1
OPTIMAL 5.1 SURROUND SOUND SPEAKER PLACEMENT
1. For optimal sound place each
front speaker 30 degrees
from the center point.
2. For optimal sound place
eachrear speaker 120 degrees
from center point.

6English
S
O
U
N
D
/SCAN/
1
6
2
3
4
5
7
8
1. Standby
2. Sound
3. Decrease volume
4. Previous
5. Play/Pause/Scan/
Bluetooth®Pairing
6. Source
7. Increase volume
8. Next
CONTROLS ON SUBWOOFER

English 7
CONTROLS ON SUBWOOFER
1. Standby:
Activates/Deactivates standby mode (the system automatically
goes into standby mode after 20 min if there is no audio input
signal, if the input signal is paused or if it is at 1kHz volume level).
2. Sound:
Switches between 5.1 and 2.1 channels
(only if input supports 5.1 channels)
3. Decrease the volume level:
4. Previous:
a. USB/SD mode:
i. Short press to select previous song.
ii. Long press to select previous folder.
b. FM mode:
i. Short press to select previous station.
ii. Long press to select previous automatically stored channel/station.
c. Bluetooth mode: short press to select previous song

8English
5. Play/Pause/Scan/Bluetooth Pairing:
a. USB/SD Mode: Short press to play/pause music.
b. FM mode:
i. Short press to start auto search, second short press to select a station.
ii. All active frequencies are stored automatically in dierent channels.
c. Bluetooth mode:
i. Short press to play/pause music.
ii. Long press will start bluetooth pairing mode, LED will quickly blink ‘bt’
onthe display.
6. Source:
a. Switch between Bluetooth, AUX, DVD, USB/SD and FM mode.
LED display on subwoofer panel will indicate related source
mode.
7. Increase the volume level:
8. Next:
a. USB/SD mode:
i. Short press to select next song.
ii. Long press to select next folder.
b. FM mode:
i. Short press to select next station.
ii. Long press to select next saved channel/station.
c. Bluetooth mode: short press to select next song.

English 9
1
2
LOCAL AUDIO SOURCES
1. SD card slot 2. USB drive slot
i. To play audio fully insert SD card into
SD card slot and select SD/USB source
from either remote control or controls
on the subwoofer.
ii. To remove SD card simply pull it out
of the slot.
iii. Z607 supports up to 32GB SDHC
cards with the following audio
leformats: MP3, WMA, WAV,
APE,FLAC.
SD card not included
i. To play audio insert USB drive into
USB slot and select SD/USB source
from either remote control or controls
on the subwoofer.
ii. To remove USB drive simply pull it out
of the slot.
iii. Z607 supports up to 32GB USBdrives
formatted FAT16 or FAT32 with
thefollowing audio le formats:
MP3,WMA, WAV, APE, FLAC.
USB drive not included

10 English
TUNE –
FM
RADIO
AUX
CHANNEL
LEVEL
—
VOL
+
VOL
RCA
5.1
2.1
SD
USB
TUNE + SCAN
1
46
8
11
10
14
7
9
5
12
13
2 3 1. Standby:
Activates/Deactivates
standby mode (the system
automatically goes into
standby mode after 20 min
if there is no audio input
signal, if the input signal
is paused or if it is at 1kHz
volume level).
2. Mute: Mutes the system.
3. 5.1 / 2.1: Switches from 5.1
to 2.1 channels as needed
(only if input supports 5.1
channels).
4. -Vol:
a. Decreases the master
volume.
b. When selecting channel
level buttonrst,
-voldecreases
thevolume of
theselected channel.
REMOTE CONTROL

English 11
5. Channel Level:
Controls volume of speaker channels. Press once to cycle
through front (F) speakers, rear (R) speakers, center (C) speaker,
andsubwoofer (S), select the channel and adjust the volume of
that unit or channel from 5 to -5. System will save channel volume
adjustment.
6. +Vol:
a. Increases the master volume.
b. When selecting channel level button rst, +vol increases
thevolume of the selected channel.
7. AUX: Selects 3.5mm AUX input.
8. RCA/DVD: Selects RCA input.
9. FM RADIO: Selects FM Radio.
10. Bluetooth/Bluetooth Pairing:
a. Short press selects Bluetooth mode.
b. Long press will start Bluetooth pairing mode, LED will quickly
blink‘bt’ on the display.
11. SD/USB: Selects SD/USB input.

12 English
12. Back/Previous/Tune-:
a. On FM Radio Mode:
i. Short press to advance to previous station.
ii. Long press to select the previous saved station.
b. On Bluetooth mode: short press to select previous song.
c. On USB/SD mode:
i. Short press to select previous song.
ii. Long press to select previous folder.
13. Play/Pause/Scan:
a. On FM Radio Mode: Short press to start auto search,
secondshortpress to select a station.
b. On Bluetooth mode: Short press to play/pause music.
c. On USB/SD mode: Short press for play/pause music.
14. Next/Tune+:
a. On FM Radio Mode:
i. Short press to advance to next station.
ii. Long press to advance to the next saved station.
b. On Bluetooth mode: Short press to select next song.
c. On USB/SD mode:
i. Short press to select next song.
ii. Long press to select next folder.

English 13
2.2M
2.2M
2.2M
6.2M
6.2M
LONGER CABLE LENGTH FOR FLEXIBLE PLACEMENT

WEB-621-001215.002
© 2018 Logitech. Logitech, Logi and the Logitech logo are trademarks or registered
trademarks of Logitech EuropeS.A. and/or its aliates in the U.S. and other countries.
TheBluetooth®word mark and logos are registered trademarks owned by the BluetoothSIG,
Inc. andany use of such marks is under license. SD and SDHC Logos are trademarks of SD-3C
LLC. All other trademarks are the property of theirrespective owners.
www.logitech.com/support/z607
