Logitech Z337 Assembly Instructions

Z337 SPEAKER SYSTEM
WITHBLUETOOTH®
Complete Setup Guide
完整设置指南
完整設定指南
설치 가이드

CONTENTS
English . . . . . . . . . . . . . . . . .3
简体中文 . . . . . . . . . . . . . . . .9
繁體中文 . . . . . . . . . . . . . . . 15
한국어 . . . . . . . . . . . . . . . . 21

English 3
KNOW YOUR PRODUCT
Wired
control pod
Power plug
Volume control
knob
Headphone jack
Subwoofer
Bass control
RCA cable
tosubwoofer
3.5 mm audiocable
Power on/o button
Bluetooth
pairingbutton
Left satellite
Right satellite

English 4
CONNECT THE SPEAKERS
1. Plug the blue RCA connector on the left satellite into the blue subwoofer jack.
2. Plug the black RCA connector on the right satellite into the black subwoofer jack.
3. Plug the power plug into an electrical outlet.
21
3

English 5
CONNECT TO AUDIO SOURCE
Using Bluetooth® :
1. Turn on Bluetooth on your device.
2. Turn the speakers on.
3. Press and hold the Bluetooth button to activate pairing mode. The LED on the control pod will blink quickly.
4. Select and connect to “Logitech Z337” on your Bluetooth device list.
5. To pair with your second device via Bluetooth, repeat step 3 and step 4. Make sure to turn on Bluetooth on your device.
2
4
1
3
Z337
Logitech

English 6
CONNECT TO AUDIO SOURCE (CONT’D)
1A. For RCA connection:
Connect one end of the RCA cable to the corresponding RCA jack on the back of the subwoofer.
Thenconnectthe other end of the cable to the RCA outlet on your device (TV and gaming console, etc.).
Note: the RCA cable is not included in the box and must be purchased separately.
1B. For 3.5 mm connection:
Connect one end of the provided 3.5 mm cable to the auxiliary input on the back of the subwoofer.
Thenconnectthe other end of the cable to the 3.5 mm audio jack on your device.
2. Plug your headphones into the headphone jack on the control pod. Adjust the volume either from
thecontrolpodor the audio source.
3. Power speakers on/o by sliding the power on/o button on the wired control pod.
1A 1B
2 3

English 7
CONNECT TO THREE DEVICES SIMULTANEOUSLY
1. Connect up to three devices at the same time through the RCA connector on the back of the subwoofer,
the 3.5mm cable on the subwoofer and Bluetooth.
2. You can pair up to eight Bluetooth source devices with your speakers and connect to 2 of them at once.
3. To switch between audio sources just pause audio on one connected device and play audio from the other
connected device.
1
2
3
Z337
Logitech
Z337
Logitech

English 8
www.logitech.com/support/Z337
1 2
- + BASS
ADJUST THE VOLUME
1. Adjust the volume of Z337 with the knob on the control pod.
Turn the knob clockwise (to the right) to increase volume.
Turn the knob counter-clockwise (to the left) to decrease volume.
ADJUST THE BASS
2. Adjust the bass level by turning the bass control knob located at the back of your subwoofer.
Turn bass knob to the right for deeper bass or to the left for less bass.
BASS

简体中文 9
了解您的产品
有线控制器
电源插头
音量控制旋钮
耳机插孔
低音炮
低音控制
连接低音炮的 RCA 线缆
3.5 毫米音频连接线
电源打开/关闭按钮
蓝牙 配对按钮
左卫星音箱
右卫星音箱

简体中文 10
连接音箱
1. 将左侧卫星音箱上的蓝色 VGA 插头插入蓝色低音炮端口。
2.将右侧卫星音箱上的黑色 VGA 插头插入黑色低音炮端口。
3.将电源线插入电源插座。
21
3
