Loll Designs TimberTech ADIRONDACK User manual

*Bolt shown
actual size
INCLUDED PARTS
1˝
BOLT 18x
LEFT LEG
1x
RIGHT LEG
1x
CB
4x
P16
1x
GB
12x
P9
1x
P8
1x
P7
1x
BACK
1x
P2
1x
P5
1x
P6
1x
P5
PRODUCT CARE
Your new furniture is avery low maintenance product. You’ll never need to paint or stain it and it can
be left outside all year regardless of the season.However,we are pretty sure your furniture will get a
lot of use and will at some point need cleaning. We recommend using clean water from a faucet or
garden hose and incorporating asoft bristle brush to remove light dirt or spills.Adding atablespoon
or two of your favorite eco-friendly soap to the wash will get everything squeaky clean.Removing
mineral deposits from hard water or other tougher cleaning jobs can be done with a solution of
vinegar and water or with TimberTech Deck Cleaner which is specially formulated for this type of
cleaning.
WARRANTY
TimberTech is known for making beautiful, high-quality, outdoor living products that last and our Invite
Collection of Outdoor Furniture is no exception. We want you to be happy that you chose our
furniture and satisfied with your purchase and we back that up with a comprehensive Warranty.
Please see the TimberTech + Loll Invite Collection Warranty for complete details.
PRODUCT DAMAGED IN SHIPMENT
Sometimes accidents happen.Please inspect your furniture when you receive it to make sure that it
has not been damaged during shipping. If damage has occurred, please take digital pictures of the
damaged furniture and the box it was shipped in, and call Customer Service using our toll free
number:877.275.2935.The damage will be assessed and you will be contacted with a solution to
the problem.If there is any damage, please save all of your packaging material in case areturn is
necessary.
ASSEMBLY TIPS
Please read before beginning assembly and be sure to wear eye protection to
avoid injury, particularly if using power tools
To avoid damaging the furniture, perform the assembly of your new furniture on a clean,
soft surface like a blanket, carpet, or the flattened cardboard box the furniture was shipped in.
When removing the furniture from the carton and if using the carton for an assembly surface,
please CAREFULLY remove all staples that held the shipping carton together. These can
scratch you and the furniture and we don't want that to happen to either of you. Components
should not be unnecessarily forced together! If it seems parts aren’t fitting together you likely
have something wrong and you should reread the instructions to ensure you
are aligning the proper components. The various “Blocks” used in assembly may have a
protective film on one side. This surface is hidden after assembly so the film can remain on the
Block or it can be removed. Use a Cordless Screw Gun if you have one and know how to use
it. Set the clutch setting at medium torque. We do not recommend using an electric drill with a
cord and without a clutch to install bolts in inserts as you can easily overtighten and
damage the product. All bolts come standard with a thread coating to reduce bolts
loosening after assembly while still allowing removal and reuse of the bolt. Start all bolts by
hand and then use the Allen Key/Hex Wrench to tighten firmly until parts are drawn tightly
and firmly together.
**Please recycle the cardboard box and all paper and plastic packaging materials.
BLOCK & BOLT INSTALLATION
Insert bolts through countersunk hole side of blocks as shown below. When done properly, the top of
the bolt will sit even or flush with the top surface of the block.
Allen Key/Hex Wrench Install Tool
Included in the carton for use in tightening all bolts..
CORRECT INCORRECT
We want you to love your new furniture.
Reach out if you need assistance.
1.877.275.2935
1330 W Fulton Market, Suite #350,
Chicago, IL 60607
Countersunk
Hole
ASSEMBLY INSTRUCTIONS & PRODUCT INFO: | ADIRONDACK CHAIR
G-BlockC-Block

4
p
e
t
S
1 2 3 4
1
ep
St
3
ep
St
LEFT
LEG
P7
P5
P8 P9
GB
1x
1˝
BOLT
18x
T
˝
BOL
1
18x
T
˝
BOL
1
1˝
BOLT
1x
1˝
BOLT
1x
1x
1˝
BOLT
GBGB
GB

5 6 7
1x
1˝
BOLT
2x
1˝
BOLT
P6
BACK
P2
GB
GB
GB

8 9
10
5x
1˝
BOLT
4x
1˝
BOLT
CB
4x
RIGHT
LEG
GB
5x
P16
2x
1˝
BOLT
