Longshine LCS-SW2402S User manual

FCC Certifications
This Equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference
in which case the user will be required to correct the interference at his own expense.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)

this device must accept any interference received; including interference that may
cause undesired operation.
CE Mark Warning
This equipment complies with the requirements relating to electromagnetic
compatibility, EN 55022 class A for ITE, the essential protection requirement of Council
Directive 89/336/EEC on the approximation of the laws of the Member States relating
to electromagnetic compatibility.
Company has an on-going policy of upgrading its products and it may be possible that
information in this document is not up-to-date. Please check with your local distributors
for the latest information. No part of this document can be copied or reproduced in any
form without written consent from the company.
Trademarks:
All trade names and trademarks are the properties of their respective companies.
Copyright © 2003, All Rights Reserved.
Document Version: 2.0
E-1

E-2
Table of Contents
1. Overview
2. Unpacking Information
3. Introduction to 24F.E.+2G.E. Gigabit Clustering Switch
3.1 General Description
3.2 Key Features
3.3 The Front Panel
Port Operation
Wiring for 10/100Mbps (Fiber Optical/Copper)
LEDs Definition
Power LED
RTC LED
STATUS 0 LED
STATUS 1 LED
Port LEDs (10/100Mbps Copper/Fiber Optical)
SPD/LINK/ACT LED
FULL/COL LED
LINK/ACT LEDs (For slide-in slots on the rear panel)
LINK LED (“STACK” port)
HUB ID
RESET button
3.4 The Rear Panel
Gigabit Slide-in slots
Gigabit Module Operation
Wiring for Gigabit Slide-in Module
Console Port
Power Receptacle

E-3
4. Installing 24F.E.+2G.E. Gigabit Clustering Switch
4.1 Desktop Installation
4.2 Rack-mount Installation
4.3 Installing Network Cables
Station Connections
Switch-to-Switch Connections
4.4 Module Installation
4.5 Management Stack
4.6 Network Application
5. Management Guide
5.1 Console Port (Out-of-Band) connection
5.2 In-Band Connections (Web Browser/ Telnet)
Starting a Telnet Session
Starting a Web Browser Session
Topology
System Configuration
Device
Panel Display
Port Status
Network Configuration
Device Information
Topology Info
Ports
Information
Configuration
Setup Port Attributes
Duplicate Port Attributes
Statistic
Location Search
VLAN
802.1Q VLAN
VLAN Static List
To create a new VLAN group
To remove a VLAN group
To modify a VLAN group

E-4
VLAN Static Table
To add member port
To remove member port
VLAN Port Configuration
To change the PVID
Port Group VLAN
All Together
All Independent
Port Aggregation
Priority
Address Table
MAC Address list
Configuration
To add a static address
To remove a static address
Mirror
6. Product Specifications

E-5
1. Overview
The Gigabit Managed Cluster is a powerful, high-performance, high
port-density networking system, which can upgrade and integrate your existing
network from 10/100Mbps to a simplex, efficient, centralized management
environment and very high-speed network architecture. As all members operate
as teamwork, all connected members of the family are treated as a
Single-Managed device.
With its built-in rich, various and advanced management functions, system
administrator can monitor and control the whole system or individual port of any
members easily and remotely.
The members of the Gigabit Managed Cluster are:
 24F.E.+2G.E Gigabit Clustering Switch
 14+2G.E. Gigabit Clustering Switch
 16V+2G.E. VDSL Clustering Switch

E-6

2. Unpacking Information
Thank you for purchasing the 24F.E.+2G.E. Gigabit Clustering Switch. Before you
start, please check all the contents of this package.
The product package should include the following:
1. One 24F.E.+2G.E. Gigabit Clustering Switch
2. One power cord
3. Rubber foot and screws
4. Rack-mount brackets
5. User’s Manual
E-7

E-8
3. Introduction to 24F.E.+2G.E. Gigabit Clustering Switch
3.1 General Description
The device is a 24+2-port 10/100/Gigabit Ethernet clustering switch with
twenty-four 10/100Mbps RJ-45 ports and two Gigabit slide-in slots on the rear
panel for optional fiber/copper Gigabit modules.
Compare to the traditional 10/100Mbps Ethernet, the switch delivers a dedicated
10/100Mbps connection to every attached client with no congestion issue. The
gigabit ports also provide the fat pipe to the server or backbone connectivity for
boosting the total system performance. Moreover, the NWay auto-negotiation
operation automatically negotiates with the connected partners on the network
speed and duplex mode; that provides an easy way to integrate 10 / 100 /
1000Mbps networks with no pain. It is ideal for micro-segmenting large networks
into smaller, connected subnets for improved performance, enabling the
bandwidth demanding multimedia and imaging applications.
Out of the ordinary dumb switches, the 24F.E.+2G.E. Gigabit Clustering Switch
embedded advanced management capability; that the device can be remote
managed by Telnet, SNMP manager and Internet browser. This is much useful for
system manager to monitor and control the system efficiently.
Store-and-forward switching mode promises the low latency plus eliminates all
the network errors, including runt and CRC error packets. To work under
full-duplex mode, transmission and reception of the frames can occur
simultaneously without causing collisions as well as double the network
bandwidth.
The switch is plug-n-play without any software to configure and also fully
compliant with all kinds of network protocols. Moreover, the rich diagnostic
LEDs on the front-panel provide the operating status of individual port and
whole system.

E-9
3.2 Key Features
 Complies IEEE 802.3, IEEE 802.3u, IEEE802.3x, IEEE 802.3z/ab standards
 Complies with IEEE802.1Q VLAN tag (IVL)
 Complies with IEEE802.1p CoS with 2-level priority
 The whole management stack can stack up to 8 sets
 24 * RJ-45 ports for 10/100Mbps
 2 * 1000Mbps Copper/Fiber slide-in slots
 1 * 100Mbps Fiber slot (Alternative to copper port-1)
 Proprietary management bus extend up to 800 meters for management stacking
 Every switching port is automatically cross-over detection
(MDI/ MDI-X auto-detected)
 Supports real-time clock (optional)
 Supports IGMP snooping
 Supports MIB counters
 Supports port sniffering
 Supports Port Aggregation and up to 7 groups
 Supports port group VLAN and up to 255 groups
 Supports 802.1Q VLAN and up to 255 groups
 Supports 802.1D Spanning Tree
 One RS-232 female console connector
 Supports 8MB SDRAM for run time data storage
 Supports 2MB Flash EPROM for cooperation and configuration data storage
 Supports 6K MAC entries
 Supports 3Mbit packet switching
 19” rack mountable
 Internal universal switching power supply
 FCC Class A, CE

3.3 The Front Panel
The front panel of the switch is shown as below
Port Operation
There are 24 * 10/100Mbps RJ-45 (copper) ports with 1 * 10/100Mbps fiber optical
slide-in slot (Alternative to copper port-1).
--10/100Mbps Fiber SC
The auto-negotiation feature of the switch allows each port of the device running at
one of the following operation modes:
Port Media Speed Duplex Mode
Full Duplex10Mbps
Half Duplex
Full Duplex
10/100Mbps fiber optical SC
(Alternative to copper port-1)
100Mbps
Half Duplex
Full Duplex10Mbps
Half Duplex
Full Duplex
10/100Mbps
10/100Mbps RJ-45 (copper)
100Mbps
Half Duplex
All copper ports supports MDI/MDI-X auto crossover capability that is the port can
connect either the PC or hub without crossover cable adjustment.
E-10

Wiring for 10/100Mbps (Fiber Optical/Copper)
Following are the summaries of cabling required:
Media Speed Wiring
10Mbps Category 3,4,5 UTP/STP10/100Mbps copper
100Mbps Category 5 UTP/STP
10/100Mbps
Fiber SC
10/100Mbps 62.5/125 or 50/125µm
multi-mode fiber optic
AttentionΚ1. Category 5 cable is preferred to use with this product in
structured wiring environments. This will ensure correct
operation of RJ-45 ports at 10Mbps, 100Mbps or 1000Mbps.
2. The proprietary management bus (“STACK” RJ-45 ports) on
the front panel is reserved for management stacking, only
straight-through UTP/STP cable can be used. There is no
Duplex Mode issue and the extended distance can up to 800
meters.
E-11

E-12
LEDs Definition
The rich diagnostic LEDs on the front panel can provide the operating status of
individual port and whole system.
Power LED
This indicator lights green when the switch is receiving power; otherwise, it is off.
RTC LED
When standalone using the switch, this indicator indicates the optional Real Time
Clock is functioning or not. If it does, the RTC LED lights green. In the
management stack, the RTC LED blinks green to indicate management bus activity
STATUS 0 LED
When this LED steady green, it means the device acts competent leading role, an
indispensable essential for system administrator to control and monitor whole
system. At the time one member of the cluster disconnected or new member joined,
the “STATUS 0” LED blinks. Soon, one and only one master will be raised. You can
reference to “HUB ID” for relative information in the next.
STATUS 1 LED
The “STATUS 1” LED flashes green when Run Time Error occurs.
Port LEDs (10/100Mbps Copper/Fiber)
Every 10/100Mbps port relevant two LEDs (SPD/LINK/ACT; FULL/COL) for
indicating the speed and connection status.
SPD/LINK/ACT LED
SPD/LINK/ACT LED Status
Off No Connection
Green Connected as 100Mbps
Flashing Green There is traffic transverses the port
Amber Connected as 10Mbps
Flashing Amber There is traffic transverses the port

If the port is connected but the SPD/LINK/ACT LED is dark, check the
following items:
1. The switch and the connected device’s power are on or not.
2. The connecting cable is good and with correct type
3. The cable is firmly seated in its connectors in the switch and in the
associated device
4. The connecting device, including any network adapter is well installed
and functioning
FULL/COL LED
A collision occurs when two stations within a collision domain attempt to
transmit data at the same time. Intermittent flashing amber of the collision
LED is normal; the contending adapters resolve each collision by means of a
wait-then-retransmit algorithm. Frequency of collisions is an indicator of
heavy traffic on the network.
If the FULL/COL LED lights amber, means the port is under Full-Duplex
operation or dark for Half-Duplex mode.
FULL/COL LED Status
Steady Amber Full-Duplex mode
Dark Half-Duplex mode
Flashing Amber Collision
AttentionΚThe 10/100Mbps fiber optical SC slot shares with copper
port-1 in the same LED indicators
E-13

LINK/ACT LEDs (For slide-in slots on the rear panel)
The slide-in slot has a LINK/ACT LED itself. When one slide-in module is well
installed and functioning, the relevant one lights green.
LINK LED (“STACK” port)
The LED lights green, when a management stack is made via the “STACK” port
and negotiates with associated devices successfully.
HUB IDΰRotary Switchα
All members of the management stack are ranked according to their “HUB ID”(Device
ID). There are eight degrees (0~7) in the rotary switch. The smaller number, the higher
degree. Device with smallest “HUB ID” will be the “Master” device. Then, system
management can perform by the way of the “Master Device”.
AttentionΚEvery device in the management stack should have a unique
“HUB ID”. In the meanwhile, a “HUB ID” which has been
using by a device, reused by another, the management stack
will fail.
RESET Button
The system will reboot when “RESET” button is pressed.
E-14

3.4 The Rear Panel
The rear panel of the switch is shown as below
Gigabit Slide-in slots
The two slide-in slots on the rear panel are reserved for following optional gigabit
modules. They can provide fat pipes for up linking to backbone or connecting to
servers.
--Gigabit Fiber SC
--Gigabit Copper
Gigabit Module Operation
Port Media Speed Duplex Mode
Full Duplex10Mbps
Half Duplex
Full Duplex100Mbps
Half Duplex
Gigabit RJ-45 port
1000Mbps Full Duplex
Gigabit port
Gigabit Fiber SC 1000Mbps Full Duplex
E-15

E-16
Wiring for Gigabit Slide-in Module
Following are the summaries of cabling required:
Media Speed Wiring
10Mbps Category 3,4,5 UTP/STP
100Mbps Category 5 UTP/STP
Gigabit copper
1000Mbps Category 5 UTP/STP
Gigabit Fiber SC 1000Mbps 62.5/125 or 50/125µm
multi-mode fiber optic
Console Port
The RS-232 console is an interface for connecting a terminal directly. Through
the console port, it provides rich diagnostic information includes network
statistics, link status and system setting. The operating mode of the console
port is:
 DCE
 9600 (Fix baud rate)
 n (No parity checking)
 8 (8 Data bits)
 1 (1 stop bit)
 None (No flow control)
You can use a normal RS-232 cable and connect to the console port on the device. After
the connection, you can run any terminal emulation program (Hyper Terminal,
Winterm, Telix, … and so on) to enter the startup screen of the device. All the detail
software operation, please refer to “Console port (out-of-band) connection” session of
chapter 5.

E-17
Power Receptacle
For compatibility with electric service in most areas of the world, the switch’s power
supply automatically adjusts to line power in the range 100-240 VAC and 50-60 Hz.
Plug the female end of the power cord firmly into the receptacle on the rear panel of
the switch. Plug the other end of the power cord into an electric service outlet then the
power will be ready.

E-18
4. Installing 24F.E.+2G.E. Gigabit Clustering Switch
This switch can be placed directly on your desktop, or mounted in a rack. If you
install the device in a normal-standalone standard, the switch is an Intelligent
Switch, and users can immediately use most of the features simply by attaching
the cables and turning the power on. In this case, any managerial proceedings are
effective only in the range of the switch. After management stacking, you can
enjoy the powerful management functions and control the whole system.
4.1 Desktop Installation
For desktop installation, the switch needs to put on a clean, flat desk or table close
to a power outlet. Plug in all network cables and the power cord, then the system
is ready.
Before installing the switch, you must ensure:
1. It is accessible and cables can be connected easily
2. Cabling is away from:
ϠSources of electrical noise such as radios, transmitters and broadband
amplifiers
ϠPower lines and fluorescent lighting fixtures.
3. Keep water or moisture off
4. Airflow around the unit and through the vents in the side of the case is great
for heat radiation (company recommend that you provide a minimum of 25
mm clearance)
To prolong the operational life of your units:
1. Never stack unit more than eight sets high if freestanding
2. Do not place objects on top of any unit or stack
3. Do not obstruct any vents at the sides of the case

E-19
4.2 Rack-mount Installation
The switch may standalone, or may be mounted in a standard 19-inch equipment
rack. Rack mounting produces an orderly installation when you have a number of
related network devices. The switch is supplied with rack mounting brackets and
screws. These are used for rack mounting the unit.
Rack Mounting the Switch in the 19-inch rack:
1. Disconnect all cables from the switch before continuing.
2. Place the unit the right way up on a hard, flat surface with the front facing
toward you.
3. Locate a mounting bracket over the mounting holes on one side of the unit.
4. Insert the screws and fully tighten with a suitable screwdriver.
5. Repeat the two previous steps for the other side of the unit.
6. Insert the unit into the 19" rack and secure with suitable screws (not
provided).
7. Reconnect all cables.
