LOOP 3D LOOP PRO X User manual

1
Quick Installation Guide

2
CONTENTS
Setting-up ................................................................................3
Inside the Box ........................................................................14
Registering & Activating ........................................................17
Getting Started ......................................................................25
Follow the QR code for installation video

3
Setting-up

4
Lift down the crates with a forklift or a
pallet jack into the desired place. Make sure
that you placed the crates on the same oor
which you are going to make the installation
of the 3d printer.
1

5
3
Unscrew the screws located at the
bottom connection points of the crate and
then remove the top and side lids together
as one piece.
2
Unlock the cabinet crate’s fasteners
and remove all lids.

6
5
Place the cabinet on a rigid and stable ground.
4
Carry the rest of the crate away with caution.

7
6
7
Place the cabinet and the machine next
to each other to make the carrying process
easier.
Unlock the fasteners located on right,
left and front bottom of the crate.
Unscrew the screws located at the
bottom connection points of the
crate and then remove the top and
side lids together as one piece.

8
8
Machine shall be carried to the
installation site with the help of cabinet wheels,
and then the machine feet must be xed.
At least 3 people will be necessary
to place the machine on top of the cabinet.
As two persons will lift from the side handles,
one person will need to support from the
back of the machine to help balancing.
Please wear protective equipment as the
machine itself is heavy. Then lift and place
the machine on top of the cabinet carefully.
While lifting the machine,
please hold it from the gaps.

9
9
14
25
3 6
Unscrew the six screws behind
the cabinet which hold the back lid,
then remove and place the lid in a safe
location.

10
11
10
When done, place the lid at the back
of the cabinet and tighten the six screws.
Remove the clip from bottom adapter
inlet and insert the tube coming out from the
drybox to the adapter's bottom inlet. Push
the tube as much as it goes in, then place
the locking clip to the adapter. After locking,
push the tube a little more one last time to
ensure that it is mounted successfully.
14
25
3 6

11
13
12
Plug the power cord to the power inlet
behind the machine and then plug the other
end to a voltage regulated UPS or at least to
a surge protected socket.
Open the front and top lids of the
machine and remove the safety llings,
remove the tools that hold the axes from
moving, then cut the cable ties with a side
cutter.

12
15
14
Turn on the machine using the power
switch that is placed at the back of the machine.
Connect an active ethernet line cable
to the ethernet port behind the machine.

13
16
After the installation is fully complete,
if you want to use the machine wireless
instead of ethernet, you can go to settings
from the main screen and connect to your
wi from the network tab.

14
Inside the Box

15
1x Spool
Dynamide CF Filament (2 Kg)
1x Spool
Dynamide GF Filament (2 Kg)

16
Nozzle Needle
Wheel
Plug
Cutter Pliers
Stick Glue
Tweezer Allen Key
Installation Guide
Safety GlassesSafety Gloves
Box 1
Box 2

17
Registering & Activating

18
1
When the machine is turned on, if you
don't have an active ethernet connection,
the screen will prompt that it can't connect
to a network so you will have to press Wi-Fi
setup to proceed.
2
Find your Wi-Fi on the list and select
it, enter your password if the connection is
password protected.

19
3
In the next step, screen will greet
you with a QR-code and a Registration ID.
Please note that registration ID down for
further use.
4
Go to my.loop3dprinter.com and
sign-up for your LOOP 3D CLOUD account.

20
6
5
There will be an activation e-mail
sent to your e-mail address after signing-
up. If you did not receive the activation
e-mail click 'resend e-mail' option.
Please click the activation link from
your e-mail. The link will lead you to the
sign-in screen.
7
Sign-in to your LOOP
3D CLOUD account with your
e-mail and password.
