Lopi Leyden User manual

leydentm
TOP LOADING CAST IRON WOOD STOVE
Love Life, Live Large
It's not just something we say, we believe it! So much that we designed a stove around the phrase and
inscribed it in the lid! Life should be enjoyed and lived to the fullest. That's why we created the Leyden
(LYE-den), the easiest to use wood stove we've ever made. With a top load design, the largest firebox
in a medium-sized stove to hold more wood than ever before and cross-draft technology that gives you
longer burn times with less refueling. The ash removal system is the most convenient to date with our
slide out ash pan on drawer glides. All these features let you spend more time enjoying living in your
home instead of heating it. The Leyden is just one more reason Lopi is America's Favorite Fire!
22 7/8” 2 5/8”
17”
Visit our Website at: www.lopifire.com
© Copyright T. I. 2006 Printed in U.S.A.
Photos and illustrations are for descriptive purposes only. We reserve the right to improve or change our products without prior notification. Consult the Owner’s Manual for complete installation requirements.
leydentm
TOP LOADING CAST IRON WOOD STOVE
#98800235
Measure rear hearth pad clearances
from the back of the heat shield.
Measure front hearth pad clearances from
the face of the stove (door opening).
Back Wall
Minimum Flue Center 31-3/4”
Side Wall
Typical flue center
Single Wall 24”
Reduced
Clearance 17.5”
Single Wall
with Pipe
Shield 14”
16”Min.
6”Min.
6”Min.
A
B
Typical flue
center
Single Wall 26”
Reduced
Clearance 21”
Single Wall with
Pipe Shield 21”
16”Min.
6”Min.
6”Min.
Note: Vent
diameter
may vary
depending
on brand and
model.
Measure side hearth pad clearances from
the nearest edge of the stove top.
Floor Protection
C
Your Lopi Authorized Dealer is Located At:
21”
28 3/4”
23”
19”
Single Wall
Connector
Single Wall
Connector
w/Pipe Shield
Double Wall
Connector
11”
28 3/4”
18”
14”
14”
28 1/4”
17 1/ 2 ”
14”
48”
631/4”
84”
A = Maximum Depth
B = Maximum Width
C = Minimum Height
D
Close Clearances To Combustibles
Dimensions Alcove Clearances
A =
B =
C =
D =
C
A
B
Measured From
Combustible Surfaces
27 1/4”
27 3/4”
5 3/4”
25 1/4”
Floor Protection
Measure side, corner, and back
clearances from the stove top.
(Rear heat shield is a standard feature)

leydentm
TOP LOADING CAST IRON WOOD STOVE
It’s All In The Details
The Leyden features details found
in early American style
architecture. The balance and
symmetry of this stove impart an
elegant charisma, and the fine
quality details are featured on
every inch of the stove from the
sculptured castings to the special
refractory lining. The large double
doors feature a view of the fire
with 190 sq. in. of ceramic glass.
The Leyden is the only
wood stove that ships
with its own extra-long,
custom-designed
wrought iron poker and
leather gloves so you can
easily load and adjust
wood around and inside
the deep firebox. It is
touches like this that
make the Leyden the
most convenient stove
on the market.
Our user-friendly ash
pan glides on ball
bearings and has a
handle for easy lifting
so you can quickly
and easily empty the
ashes. Our system
requires no awkward
or uncomfortable
bending or stooping
and results in faster,
more efficient ash removal.
Easy-Glide Ashpan
Optional
Convection Blower
Wood Poker & Gloves
Besides the radiant
heat that cast iron is
so famous for, the
Leyden is designed
with a built-in heat-
exchange chamber
that transfers heat off
the stove and into
your home. This
natural convection can
be enhanced with the whisper-quiet 160 CFM blower
accessory option.
Top loading stoves are the
easiest to fill. Simply lift
the lid and drop in the
wood. No wood or ashes
tumble out or spill. The
Leyden holds an amazing
45-65* pounds of wood
and accepts 21 inch log
lengths.
* Weights will vary depending
on wood type and moisture
* content of the wood.
Top Load Convenience
Weight
375 Lbs.
EPA
Emissions
2.4 Grams/Hr.
Overall
Efficiency
70 %
Maximum
Btu’s/Hour**
73,100
Firebox
Size
2.3 Cu. Ft.
Heating
Capacity*
Up to
2,000 Sq. Ft.
Maximum
Burn Time**
Up to
12 to 18 Hours
Maximum
Log Length
Up to
21 inches
* Heating Capacity may vary depending on the degree of home insulation, floor plan, ambient temperature zone of the area in which you live.
•• BTU Output and Burn Times may vary depending on moisture content of wood, wood type, chimney draft and oxygen supply.
Wood
Capacity
45-65
Pounds
The Leyden's state-of-the-art
cross-draft combustion
technology was designed to
allow an enormous, un-
obstructed firebox (no baffles or
tubes) for maximum wood
capacity and convenience. This
results in adjustable heat output
from a single air control and
extremely long burn time for
less frequent refueling. The
combustion system also creates
an aggressive, clean burning fire.
High Efficiency Performance
"We try to add a sense of
fun to everything we do
here at Lopi. I love what I
do, and try to remember to
live life fully each day. I cast
the message “Love Life, Live
Large”in the lid because I
wanted to remind others in
a small way to do the same
in their daily life, each time
they load wood into their
Lopi Leyden stove."
Kurt W. F. Rumens
President, Travis Industries
Paint & Premium Enamel Finishes
New Iron
Paint Finish
Oxford Brown
