Lorex LBV2561U Series User manual

Copyright © 2017 Lorex Corporation
As our products are subject to continuous improvement, Lorex reserves the right to modify product
design, specifications and prices, without notice and without incurring any obligation. E&OEts
reserved.
LBV2561U_QSG_EN_R2
1080P MPX IR BULLET CAMERA
Quick Start Guide
English Version 2.0
LBV2561U SERIES
Contents
• IR Night Vision Camera*
• Mounting Kit*
• BNC / Power Extension Cable*
• Power Adapter**
Warning/Caution
• Read this guide carefully and keep it for future reference.
• Follow all instructions for safe use of the product and handle with care.
• Use the cameras within given temperature, humidity and voltage levels
noted in ‘Camera Specifications’.
• Do not disassemble the cameras.
• Do not point the cameras directly towards the sun or a source of intense
light.
• Use only the supplied regulated power supply. Use of a non-regulated,
non-conforming power supply can damage this product and voids the
warranty.
• Periodic cleaning may be required. Use a damp cloth only. Do not use
harsh cleaners or aerosol cleaners.
Installation Tips
• Point the cameras where there is the least amount of obstructions (i.e. tree
branches).
• Install the cameras where they are difficult for vandals to reach.
• Secure cabling so that it is not exposed or easily cut.
• Cameras rated for outdoor use. Installation in a sheltered location
recommended.
* Per camera in multi-camera packs.
**A Multi-Camera Power Adapter that provides power to multiple cameras or individual power
adapters may be provided, depending on product configuration.
Disclaimers:
* For a full list of compatible recorders, visit lorextechnology.com/compatibility
** Stated IR illumination range is based on ideal conditions in typical outdoor night time ambient
lighting and in total darkness. Actual range and image clarity depends on installation location,
viewing area and light reflection / absorption level of object.
*** Not intended for submersion in water. Installation in a sheltered location recommended.
7.8” /199 mm
2.8” / 71mm
Dimensions
Resources
Need Help?
Visit us online for up-to-date software and complete
instruction manuals
ATTENTION - A REGULATED power supply is REQUIRED for use with this
camera. Use of a non-regulated, non-conforming power supply can damage
this product and voids the warranty.
Vist www.lorextechnology.com
Search the model number of your product
Click on your product in the search results
1
2
3
4
Click the Downloads tab
2.8” / 71mm

Setup Diagram
Power Adapter Types
Individual Power Adapter Multi-Camera Power
Adapter
A multi-camera power adapter that provides power to multiple
cameras or individual power adapters may be provided,
depending on product configuration.
Before installing the cameras:
• Decide whether to run the cables
through the wall / ceiling (drilling
required) or along the wall / ceiling.
• If you run the cables along the wall
/ ceiling, you must run the cable
through the cable notch on the base.
This will keep the camera base flush
to the surface when mounted.
To install the cameras:
1. Set the camera in the desired mounting position and
mark holes for screws through the camera base.
2. Drill the holes, then feed the cable through the
mounting surface or cable notch.
NOTE: Insert the included drywall anchors if
installing the camera in drywall.
3. Mount the camera stand to the surface using the
provided screws. Make sure all screws are fastened
tightly.
Installing the Cameras Cable Extension Options
Extend the cable run for your camera depending on the cable type
used. Additional extension cables sold separately. See table below:
Option Cable Type Max Cable Run
Distance
1 Lorex model MCBL-60BNCU / MCBL-
60BNCU2 BNC Cable (included with
camera)
60ft / 18m
2 ‘RG59’ or ‘Coax’ or ‘Coaxial BNC’
Siamese (Video and Power)
300ft / 92m
3 ‘RG59’ or ‘Coax’ or ‘Coaxial BNC’
(Video Only)2
800ft / 242m
Notes:
1. The extension cable must be a single stretch of cable between the DVR
and camera. You cannot connect multiple extension cables to each other.
2. For cable runs above 300ft / 92m (option 3), you must connect the
power adapter directly to the camera, rather than at the end of the
extension cable.
3. Indicators that your cable run may be too long:
• Video is permanently black & white (even during day time)
• Video is unclear, soft, or distorted
4. For more information on extension cables, visit
www.lorextechnology.com.
To Camera: To DVR:
Male Power
BNC
1. Connect the BNC and
power connectors to the
camera.
Female Power
2. Connect the BNC connector to
the video input of your DVR.
3. Connect the power connectors
to the power adapter.
Connecting the Cameras
Cable Notch
Adjusting the Camera
ATTENTION - Test each camera prior to selecting a permanent mounting
location by temporarily connecting the camera(s) and cables to the DVR.
BC
B) Bending the arm: Use an Allen
key (included) to loosen the adjustment
screw. Bend the arm of the camera
to the position you want (up to 90°).
Tighten the screw.
C) Rotating the camera:
Use the Allen key to loosen
the adjustment screw. Rotate
the camera to the position you
want (up to 360°). Tighten the
screw.
A
A) Rotating the arm: Loosen the adjustment ring between the
camera arm and base by turning the ring counter-clockwise. Rotate the
arm of the camera (up to 360°). When the arm is in the position you
want, tighten the adjustment ring against the base by turning the ring
clockwise.
ATTENTION - This camera includes an Auto Mechanical IR Cut Filter. When
the camera changes between Day/Night viewing modes, an audible clicking
noise may be heard from the camera. This clicking is normal, and indicates
that the camera filter is working.
MPX DVR
LBV2561U_SERIES_TRIFOLDQSG_EN_R1
Problem Solution
No picture / signal •1080p cameras are compatible with 1080p HD
DVR recorders. 720p cameras are compatible with
720p & 1080p HD DVR recorders.
•Ensure connections are properly connected.
•Ensure the camera power supply is plugged in.
Picture is too bright •Ensure your camera isn’t pointed directly at a
source of light (e.g. sun or spot light).
•Move your camera to a different location.
Picture is too dark •Check the brightness and contrast settings of the
DVR or monitor.
Night vision is not working •The night vision activates when light levels drop.
The area may have too much light.
Picture is not clear •Check the camera lens for dirt, dust, spiderwebs.
Clean the lens with a soft, clean cloth.
•Make sure that the cable run is within the
limitations specified in the section ‘Cable Extension
Options’.
Bright spot in video when
viewing camera at night
•Night vision reflects when pointing a camera
at a window. Move the camera to a different
location.
Picture is curved •Cameras with a very wide field of view (i.e.,
Fish-Eye lens) may display a curved image. That is
normal for this type camera and does not require
troubleshooting.
Troubleshooting
