LOUIS CHEVROLET
SWISS WATCHES
INSTRUCTION MANUAL LC-01

Version 1
November 2018

Congratulations and thank you for your purchase.
By choosing this watch you have entered the
Louis Chevrolet universe!
Being of Swiss origin and born just a few kilometers from our
factory, we had to honor Louis Chevrolet, the illustrious man who
made history.
From car mechanics to watchmaking precision, there was only
one step to take. The latter was all the easier because his father
was himself a talented watchmaker.
You are now one of the thousands of ambassadors of our brand!
Welcome to the Louis Chevrolet family
André SAUNIER
CEO
3
LC

Contact
LC
4
LOUIS CHEVROLET SWISS WATCHES SA
En Roche de Mars 10
2900 Porrentruy - Switzerland
[email protected]
[phone]
@louischevrolet
louischevroletwatches
@Louis_Chevrolet
Louis Chevrolet Swiss Watches

5
LC
Technical specifications p.6
Watch presentation p.7
Quick date correction p.8
Setting the time p.9
Setting the date, day of the week, time p.10
Chronograph: Basic function p.12
Chronograph: Accumulated timing p.13
Chronograph: Intermediate or interval timing p.14
Adjusting the chronograph hands to zero position p.15

6
LC
Case
130 grams
316L stainless steel
Sapphire convex two sides
anti-reflective crystal
Water resistant 100 meters / 330 feet
Luminous hands and index
Movement
RONDA 8040.N
Hours, minutes, seconds, date, retrograde days
Split-seconds chronograph :
hours, minutes, seconds, 1/10 sec.
Autonomy of 48 months
150 FEET
17.6 MM
24 MM
44 MM
51.6 MM
Technical specifications

7
LC
6-Crown
A : Normal position
B : Date correction position
C : Setting time and day position (stopping second)
3- Hours hand
1- Minutes hand
4- Seconds hand
5-Date
2 - Days hand
9- Seconds counter
8- Minutes counter
7- 1/10 second counter
(hours counter after 30 min.)
10 - Push-button I and II
Chronograph
Watch presentation
150 FEET
2
10.I
A B C
1
3
4
5
6
8
7
9
10.II

LC
- Pull the crown out to position B.
(watch still running)
- Turn the crown anticlockwise until the required date appears.
- Push the crown back into position A.
Quick date correction
AB
8

9
LC
- Pull the crown out to position C.
(watch stopped)
- Turn the crown, until the current time is displayed.
(remember the 24-hour cycle)
- Push the crown back into position A.
Setting the time
A B C

10
LC
- Pull the crown out to position C.
(watch stopped)
- Turn the crown until yesterday’s day appears.
(make round trips between 11:00 and 1:00 to pass the days faster)
- Push the crown to position B.
- Turn the crown anticlockwise until yesterday’s date appears.
Setting the date, day of the week, time (1/2)
ABC

11
LC
- Pull the crown out to position C.
(watch stopped)
- Turn the crown until the correct date and day appears.
- Continue to turn the crown until the correct time appears.
(remember the 24-hour cycle)
- Push the crown back into position A.
Setting the date, day of the week, time (2/2)
ABC

12
LC
- Start the timing by pressing on I.
Chronograph: Basic function
- Stop the timing by pressing on Ithen read the measured time on
the counters.
- Press on II to reset.
I
II

13
LC
Chronograph: Accumulated timing
I
II
- Start the timing by pressing on I.
- Stop the timing by pressing on Ithen read the measured time on
the counters.
- Press on II to reset.
- Restart the timing by pressing on I.
- Stop the timing by pressing on Ithen read the total measured
time on the counters.

14
LC
Chronograph: Intermediate or interval timing
I
II
- Start the timing by pressing on I.
- Stop the timing by pressing on II then read the measured time on
the counters. (the timing continues in the background))
- Press on II to reset.
- Restart the timing by pressing on II. (the chronograph hands are
advanced to the ongoing measured time)
- Stop the timing by pressing on Ithen read the final measured
time on the counters.

15
LC
Adjusting the chronograph hands to zero position (1/2)
I
II
If the chronograph hands are not in their correct zero positions,
then they have to be adjusted.
- Pull the crown out to position C.
- Keep Iand II pressed simultaneously for 2 seconds.
(the second counter hand rotates by 360°.
Corrective mode is activated)
A B C

16
LC
Adjusting the chronograph hands to zero position (2/2)
I
II
- Adjust the second counter hand by pressing on I.
A B C
- Push the crown back into position A. (can be carried out at any time)
- Press on II to adjust the next counter.
- Adjust the 1/10 second counter by pressing on I.
- Press on II to adjust the next counter.
- Adjust the minutes counter by pressing on I.
NB : To adjust precisely, press briefly.
To adjust quickly, press in continuously.
