Lovencare Wave BP 6620 User manual

BP 6620
Read all instructions before assembly and use of
product. Keep instructions for future use.

Congratulations
Congratulations on purchasing your
new Love N Care Swing.
In just a few steps you should be able to
assemble this unique product and have it
ready to meet your beautiful child :)
1.

WARNING:
Prevent serious injury or death:
WARNING:
NEVER leave child unattended.
WARNING:
ALWAYS use restraint system.
WARNING:
NEVER use for a child able to sit up unassisted.
FALL HAZARD:
Child’s activity may move product.
SUFFOCATION HAZARD: Never use on a
soft surface (bed, sofa, cushion), as seat may tip over and
cause suffocation.
Use only on floor. Never use on an elevated surface.
- All plastic packaging and elements which are not a part of the bouncer set should be
removed before giving it to the child.
- The swing must be assembled by an adult only. The product should be checked by an
adult before every use.
The swing set includes small parts and should be kept away from babies before it is assembled.
- Never leave the child unattended. Never use for a baby who is able to leave the swing
on its own.
- Use in reclined position until your child is not able to hold up head unassisted.
- Do not use if your child is able to sit upright unaided or weighs more than 9 kgs.
- Never use on a soft surface (e.g. bed), as swing may tip over and cause suffocation.
- Never leave the swing on uneven or sloping surfaces.
- Never use this product on an elevated surface e.g. table - it is dangerous. Always use it
on the floor.
- This swing is not intended for prolonged period of sleeping. It does not replace a bed.
Should your child need to sleep, then it should be placed in a bed.
- Always use the restraint system while child is in the swing.
- Never lift or move the swing when the baby is inside.
- Never use the swing if there are any parts missing or broken. Never use any accessories or
replacement parts unless they are ones approved by the manufacturer. Regularly check the
condition of the swing.
- Keep swing away from open fire and other sources of heat.
- If the swing is not used for prelonged period of time - remove batteries. After dismantling
- keep parts away from babies.
IMPORTANT! Small parts are included in the box. Product must be assembled by an adult.
WARNINGS
NEVER place a child under 5 lbs. (2.26 kg) or over 20 lbs. (9 kg) in
the product.
- Please read this instruction manual carefully before using the swing and keep it together
with packaging for future reference.
- Swinging unit requires 4 x AAA batteries (not included).
- This swing is intended for children weighing up to 9 kgs.
- Actual product may differ from image shown.
2.

Parts List
A
B
C
D
A - Seat Frame
B - Base Frame
C - Remote Control
D - Power Adapter
3.
Please make sure all parts are included before
proceeding to assembly

This product has been certified to comply with EN71-1 EN71-2 EN71-3
and RoHS.
Product Feature
Product Specification
Product Name
Model Number
Input Voltage
Output Voltage
Weight Limit
Standard
Warning
BP 6620
100-240V/50/60HZ
5V 1000 mA
Do not use a non-matching adapter
EN71-1 EN71-2 EN71-3
9kg
Batteries Installation
The Location for the batteries is on the base.
The swing uses 4xAAA batteries.
4.

5.
Using the Harness
Adjusting the harness
CLICK
Adjust the straps in the buckles as
needed so that the restraint fits
snugly (but not too tightly). Be sure
the seat restraint is secure by
pulling it away from the baby’s
body. The buckles should remain
fastened.

6.
Assembly
A
B
Attach Part A (Seat Frame) to Part B (Base Frame)
Disassembly
Pull out the metal plate
and lift the seat(a) off
the Base Frame (b)

7.
Remote Control
Power on/off
Time Setting
Built in Music/USB
Volume Up
Volume Down
Play/Pause
Previous Song
Next Song
Sleep Mode
Stop
Five Speed Mode
Power On/Off
Swing Gear
Blue Tooth Mode
USB Mode
Time Setting (8/15/30)
Volume +/- Built in Music
Switch Music
Over Input Voltage
Warning
Remote Control
Receiver Manual
Adapter
Panel
Plug the Power Adapter (D) into
the DC jack located on the Base
Frame (B).
The USB port is also located on the
base frame (B)
Place the adapter (D) 100-240V
50/60HZ 0.3A in the AC Outlet.
Do Not use a different Voltage.

8.
1. Power Switch Button : Touch the one time and the indicator
light will turn on, which means the power is on. Press the button a
second time and the indicator light is turned off to turn off the power.
2. Five swing speeds: the indicator light stands for the speed gears.
The swing angles are 18°/21°/23°/25°/31°.
Notice: the Indicator light will show and the swing will stop
automatically when the motor is stuck.
3. Timer: Touch the button of for the first time to set 8 mins
swing, touch the second time to set 15 mins and the third time to
set 30 mins swing.
The indicator light will show respectively as
4. USB: This product can support a USB disk to play additional music.
Insert the USB disk and when the lights up this will indicate that
5. Music: 1. Touch to play built-in music.
2. Touch and hold for two second to play the next song.
3. When the USB disk is pulled out, touch to play
the built-in music.
6. Volume: Press to increase the volume, press to turn down
the volume.
7. Bluetooth: To connect the bluetooth, turn on the bluetooth from
the cell phone and connect with “BT-BABY”, when the button
lights up then you can play music from bluetooth.
8. If the swing shakes too much, check the safety lock and place
the swing on a flat surface.
/ /
Instructions for Use
you can play music from the USB.

9.
CARE AND MAINTENANCE
- Keep the product in dry places. In order to keep the product attractive - avoid
prelonged sun exposure.
- Check condition of the bouncer regularly. Before each use check if it is assembled
regularly.
- Use only parts recommended and provided by manufacturer.
- Clean the swing regularly.
- In order to clean plastic parts and tubes - use damp cloth.
- Padding can be hand washed with a bit of delicate soap. Do not bleach!
- Fabric of the seat pad can be cleaned with a damp cloth.

WARRANTY AGAINST DEFECTS
All Love N Care products are guaranteed for twelve months from the
date of purchase. Our goods come with guarantees that cannot be
excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for
compensation for any other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the goods
fail to be of acceptable quality and the failure does not amount to a
major failure.
This covers against faults which develop through faulty materials and
workmanship. Misuse, accidental damages, normal wear and tear or
neglect are not covered.
If a fault becomes apparent, please return the item to the store of
purchase with your receipt.
You must inform the store what the defect is. We will then arrange for
its repair or it will be assessed for replacement as expediently as possible.
The benefits of this warranty are in addition to other right and remedies
under the law in relation to the goods or services to which this warranty
relates.
If you are unable to return the item to the store of purchase, you can
contact Love N Care on free call 1300 732 599.
Where you send the product directly to the manufacturer then you may
be liable for the costs of transportation to and from Love N Care.
Love N Care will meet the reasonable expenses incurred by a consumer in
a making a warranty claim. You can claim expenses incurred in making a
claim by contacting our customer service team on 1300 732 599 or by
email at [email protected]
10.

Head Office:
Love N Care Pty Ltd.
297-299 Canterbury Rd, Revesby
NSW 2212 Australia
Contact No: 02 9774 4655
Fax: [phone]
Email: [email protected]
Website: www.lovencare.com.au
