LOXONE Room Comfort Sensor Tree User manual

Technical Specifications
Power Supply 9...28VDC PELVPower Consumption typ. 150mW, max. 160mWAmbient Temperature -20...55°C / -4...131°FHumidity Detection Range 0...100% r. H. (non condensing)Air Quality CO2CO2 Detection Range 400…10.000ppmSafety Rating IP20Dimension55x55x18mm / 2.16x2.16x0.71” without frame80x80x18mm / 3.15x3.15x0.71” with frameMaintenance & Cleaning This device is free of main-tenance and may only be cleaned with a dry cloth.Loxone Electronics GmbH
Smart Home 14154 KollerschlagAustrialoxone.com
Need Help?
loxone.com/supportPart No: 100276 (White)Part No: 100277 (Anthracite)Room Comfort Sensor Tree
V251119

About the product
The Room Comfort Sensor Tree ensures rooms are always comfortable, by measuring temperature, humidity, and air quality using a CO2 sensor. Together with the Miniserver, this information can be used to control, monitor and record statistics for the temperature and air quality in a room.Features
• Temperature sensor• Humidity sensor• CO2 sensorInstallation
Fix the mounting plate to your installation box. Now connect power and Tree communication to the Room Comfort Sensor Tree through the frame. Place the Room Comfort Sensor including the frame on top of the mounting plate and gently push to clip into place.For additional information, declaration of confirmity, visit www.loxone.com/help/room-comfort-sensor-treeWire Specifications
Wire Diameter 0.25...0.8mm² / 23...18AWGExposed Wire Length 5mm / 5/32”Push-In-Technology To make a connection, insert the wire; to remove the wire twist and pull at the same time.Mounting PlateFrameThis folder is a part of the product!
