LOYTEC LVIS-3E100 User manual

Instructions de montage
Montageanweisung
Montagevoorschrift
Instruzioni di montaggio
Instrucciones de montaje
Monteringsanvisning
max 50º C
min 5º C
1,380 kg
10 - 90 %
kg
RH
118mm57 mm
210 mm
88.5 mm
164 mm
LOYTEC
Installation instructions
L-VIS LVIS-3E100 Touch Panel 5.7’’
LVIS-100-RE Touch Panel 5.7’’
http://192.168.1.254
User: admin
Password: loytec4u

180 mm
120 mm20
Cable entry from rear
DEPTH = 57 mm
100 mm 25
30 mm 10 mm
150 mm
191 mm
5.5 mm
Ø 4.5 mm

0,2 - 2,5 mm2
Weidmüller BLZP 5.08/03/180
7
Ethernet
100Base-T
~~
+- 20-35 VDC
24 VAC +/-10%
TEMP
123456
7
89101112 13
SWITCH POWER
EARTH
JP1 JP2
L-TEMP
External
temperature
sensor
CEA-709
FT/LPT
Jumpers
JP1 Normal operation
Clear configuration
JP2 FT-10/LPT-10 channel active
CEA-852 (IP-10) channel active
Connectors
1 Temperatur sensor data
2 Temperatur sensor GND
3 Temperatur sensor +3V
4 CEA-709 input EARTH GND
5 CEA-709 input B
6 CEA-709 input A
7 Ethernet 10/100 Base-T (RJ45)
8 Digital input GND
9 Digital input 1
10 Digital input 0
11 Power supply input earth ground
12 Power supply input MINUS
13 Power supply input PLUS
Do not connect PLUS to GND

Document 88070703
11/2010
Printed in Austria
Data is subject to change
LOYTEC
http://www.loytec.com
[email protected]
Status LEDs
ACT709 GREEN flashing fast Traffic on CEA-709 port
GREEN flashing at 1 Hz CEA-709 port not commissioned
RED permanent CEA-709 port is damaged
RED flashing fast Traffic overload on CEA-709 port
CNIP GREEN IP port is fully functional
YELLOW IP port functional but config. is not up-to-date
RED IP port is non-functional
Flashing at 1Hz IP port not commissioned
OFF IP port not active
LINK GREEN Ethernet link
ACT GREEN flashing Ethernet traffic
ONLINE GREEN Node is in configured online state
PWR GREEN Power
STAT OFF Normal operation
Buttons
RESET Reset
STATUS Send service pin message
STAT
PWR
STATUS
RESET
ONLINE
CNIP
ACT709
ACT
LINK
LOYTEC electronics GmbH
MADE IN
AUSTRIA
W51/2005
LVIS-3E100
8000000350EF
8000000350F0
000AB0011D87
007902-8000000350EF
NID1
VID1
MAC1
SER#
Node ID of CEA-709 Port
Virtual (Node) ID of CEA-852 port (Ethernet)
MAC address of CEA-852 Ethernet port
Serial number of the device
Date Code
