Monitor Module
IM-10
Description
The addressable Monitor Module IM-10 provides 10
independent inputs and serves for the line-monitored
integration of contact detectors, such as manual call
points, sprinkler system contacts or supervising con-
tacts, into the bidirectional communication on the ADM
loop with System Sensor/200 protocol.
The Monitor Module IM-10 occupies 10 consecutive
addresses on the ADM loop. During commissioning, the
base address, i.e., the lowest one of the 10 addresses,
is set by means of decadic rotary switches.
The optional steel sheet Surface Mounting Box
M200SMB-MM accommodates one Monitor Module
IM-10 or Control Module CR-6.
• ADM loop technology with
System Sensor/200 protocol
• 10 independent inputs with
monitoring for wire breakage and
short circuit
• Status LED for each input
• Setting of module address via
decadic rotary switches
• Mounting in surface mounting box
Specifi cations
Operating voltage Supply through loop voltage
Current consumption approx. 3.5mA (quiescent)
Ambient temperature 0°C to +50°C
Dimensions L × W × H 172 × 147 × 25 (mm)
Weight 500g
Order number 249115
Order name Monitor Module 10xSurv.In/Anal./200/SS IM-10
Surface Mounting Box
Ambient temperature 0°C to +50°C
Dimensions L × W × H 285 × 225 × 62 (mm)
Colour cream
Weight 2kg
Order number 249117
Order name Surface Mounting Box for Multimodule/SS M200SMB-MM
