Flame Detector IR
3
16589
Description
• Triple infrared sensor
according to EN 54-10, Class 1
• Detection of open fl ames through
fl ickering infrared radiation
• Very high immunity to deceptive
alarms
• Selectable response delay
• Relay contacts for alarm and fault
• Integrated optical test function
The Flame Detector 16589 responds to the fl ickering
infrared radiation of open fl ames. Therefore, it is extre-
mely well suitable for the detection of fi res which are
diffi cult to detect with common smoke detectors – for
example, alcoholic fi res or gas fl ames.
The detector is ideal for the following applications:
• Pharmaceutical industry
• Paint shops
• Warehouses
• Nuclear facilities
• Tunnels
With three independent infrared sensors for different
wavelengths and with an intelligent evaluation logic, the
detector can safely distinguish between alarm situati-
ons and deceptive alarms. Therefore, it is particularly
insensitive to disturbance sources such as sunlight,
fl uorescent lamps or electric arcs.
The detector complies with EN 54-10, Class 1, which
means it is suitable to detect fl ames up to a distance
of 25m.
The response delay of the detector can be selected in
4 steps between 1 and 8s. An alarm and a fault conditi-
on is signalled via two dry relay contacts. Conventional
technology is used for alarm transmission to the fi re
detection control panel. The detector can be integra-
ted into an ADM loop by means of a conventional zone
module.
A simple test of the detector can be carried out by
means of the integrated optical self test function, which
does not require additional tools. During this self test,
a built-in infrared source simulates a fi re situation which
activates the detector.
The detector has been designed for indoor and outdoor
use. The optional Detector Mounting Bracket 7127 al-
lows stepless horizontal and vertical adjustment for the
easy adaptation of the detector to the required monito-
ring area.
For use in explosion-hazardous areas, an Ex version of
the fl ame detector is available on request.

© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL [phone] • FAX [phone]
[email protected] • WWW.LST.AT • ALL RIGHTS RESERVED
IR3-16589_DBL_LST_EN_0850.PDF • PAGE 2
ABuilding Safety. Building Security.
Specifi cations
Operating voltage 14 – 30VDC
Current consumption at 24VDC max. 8mA (quiescent), 14mA (alarm)
Monitored angle 90°
Range max. 25m
Spectral sensitivity 0.75 – 2.7µm
Contact rating of relay outputs max. 1A at 50VDC
Ambient temperature -10°C to +55°C
Dimensions W × H × D 108 × 142 × 82 (mm)
Colour sky blue, RAL 5015
Weight 2kg
Protection class IP65
Approvals LPCB 729a/01
0832-CPD-0595
Order number 243011
Order name Flame Detector/IR3 16589
Detector Mounting Bracket
Material stainless steel
Adjustment range vertical 0 to -45°
Adjustment range horizontal ±45°
Dimensions W × H × D 82 × 98 × 90 (mm)
Weight 650g
Order number 249141
Order name Detector Mounting Bracket/Flame Detector 7127
