Ltech LT-84A User manual

DMX/DALI -0-10V Dimming Module
LT-84A
1
protective housings with small size and light weight.
Dimming interface: DMX/RDM, DALI, Push Dim.
Optional output: 0-10V, 5V PWM, 10V PWM.
With the RDM protocol.
4 channel output.
Built-in relay for ON/OFF control of LED driver.
Soft-on and fade-in dimming function enhances your visual comfort.
Dimming range: 0~100%.
Full protective plastic housing.
DALI bus standard: IEC62386-101,102,207.
Compliant with Safety Extra Low Voltage standard.
Suitable for indoor environments.
Adopt SAMSUNG/COVESTRO V0 flame resistant polycarbonate
DMX/DALI
To 0-10V
LT-84A
SAFETY
&
EMC EN61000-4-2,3,4,5,6,8,11, EN61547
Storage temp/Humidity -40 ~ 80°C, 10~95%RH
175×44×30mm(L×W×H)
ta: -30°C ~ 55°C tc: 70°C
178×48×33mm(L×W×H)
DMX/RDM,DALI,Push Dim
Dimming interface
Output signal
Output signal logic
0-10V × 4CH (Default) ,5V PWM × 4CH,10V PWM × 4CH (Default 0-10V,Please specify if the other two output signals are needed)
High potential
0~100%
110g±10g
IEC/EN6 1347-1, IEC/EN6 1347-2-13
55015, EN61000-3-2 Class C, IEC61000-3-3
AC current 0.055A
100-240Vac/277Vac (277 Vac for North America only)
Power consumption
<0.5mA/240Vac
115V[email protected] MAX 230V[email protected] MAX
Cold start14A@230Vac
240Vac/8A
Relay switch
50/60Hz
Push Dimming
• On/off control: .Short press
• Stepless dimming: .Long press
• .With every other long press, the light level goes to the opposite direction
Reset switch
• Dimming memory: Brightness will be the same as previously adjusted when lights are turned off and on again.
MODEL
OTHERS
SPECIFICATIONS
I/P-O/P:500VdC/25°C/70%RH≥100MΩ
I/P-O/P:3750Vac
Withstand voltage
Insulation resistance
Safety standards
EMC emission
EMC immunity
Dimensions
Pacakge size
Weight
20 ~ 95%RH, non-condensing
Working temperature
Working humitdity
10-500HZ, 2G 12min/1cycle，72 min for X,Y and Z axes respectively.
Vibration
Leakage current
Input voltage
Inrush current
Frequency
Dimming range
www.ltech-led.com

2
DMX/DALI
To 0-10V
DALI connection
DALI bus
+
+
+
+
AC/L
AC/L
AC/N
AC/N
(DMX /DALI to 0-10V signal converter)
LT-84A
0-10V LEDLED0-10V
-
-
-
-
...
D-
GND
GND
CH1
CH2
CH3
Ch4
D+
PUSH DIM
DA/N DA/L
Dimensions
175
170
44
LT-84A
DA/L
DA/N
PUSH DIM
DA/N
DA/L
L1
CH3
CH4
DMX
GND
DMX
CH1
CH2
N
L
L
GND
+
Product Size
Unit：mm
www.ltech-led.com
0-10V driver
0-10V driver
Independent 4 channels
Lamp 1
Lamp 4
LED Light Fixture
DALI
controller
AC source

+
+
+
+
AC/L
AC/L
AC/N
AC/N
LT-84A
0-10V LEDLED0-10V
-
-
-
-
...
Push dim
D-
GND
GND
CH1
CH2
CH3
Ch4
D+
PUSH DIM
DA/N DA/L
D-
GND
GND
CH1
CH2
CH3
CH4
+
+
+
+
AC/L
AC/L
AC/N
AC/N
LT-84A
0-10V LEDLED0-10V
-
-
-
-
D+
...
PUSH DIM
DA/N DA/L
DMX/DALI
To 0-10V
3
www.ltech-led.com
(DMX /DALI to 0-10V signal converter)
AC source
Independent 4 channels
Lamp 1
Lamp 4
0-10V driver
0-10V driver
AC source
(DMX /DALI to 0-10V signal converter)
Independent 4 channels
DMX
controller
0-10V driver
0-10V driver
LED Light Fixture
LED Light Fixture
Lamp 4
Lamp 1
DMX/RDM connection
Push Dim connection
Please make sure the maximum voltage drop between DMX/RDM, DALI controller and LT-84A should not be higher than 2V.Maximum cable length for 1.5mm cables is 300m.
2
Each channel is individually addressable, light intensity of LED driver connected to the same channel with be the same; the maximum allowable voltage drop between the LT-84A
and LED driver should not be higher than 0.5V; Maximum cable length for 1.5mm cable is 300m.
2

4
DMX/DALI
To 0-10V
Push
Dim
+
+
+
+
AC/L
AC/L
AC/N
AC/N
LT-84A
0-10V LED
LED0-10V
-
-
-
-
...
Push dim
D-
GND
GND
CH1
CH2
CH3
CH4
D+
PUSH DIM
DA/N DA/L
DALI
DALI bus
+
+
+
+
AC/L
AC/L
AC/N
AC/N
LT-84A
0-10V LEDLED0-10V
-
-
-
-
...
D-
GND
GND
CH1
CH2
CH3
Ch4
D+
PUSH DIM
DA/N DA/L
Built-in Relay connection
DMX
RDM
D-
GND
GND
CH1
CH2
CH3
CH4
+
+
+
+
AC/L
AC/L
AC/N
AC/N
LT-84A
0-10V LEDLED0-1 0V
-
-
-
-
D+
...
PUSH DIM
DA/N DA/L
www.ltech-led.com
(DMX /DALI to 0-10V signal converter)(DMX /DALI to 0-10V signal converter)
AC source AC source
Independent 4 channels
Independent 4 channels
Lamp 1
Lamp 1
Lamp 4
Lamp 4
LED Light Fixture
LED Light Fixture
0-10V driver
DMX
controller
0-10V driver
0-10V driver 0-10V driver
(DMX /DALI to 0-10V signal converter)
AC source
Independent 4 channels
LED Light Fixture
Lamp 4
Lamp 1
0-10V driver
DALI
controller
0-10V driver
LT-84A is equipped with a relay that can be used to turn ON/OFF LED driver. The relay is in the closed position when the CH1 generates dimming signal, the relay is in the open position
when there is no output signal on the CH1.
The maximum load of built-in relay: 8A resistive current load or less than 50A inrush current load. The breakdowns caused by overloading is not covered by the warranty.

5
DMX/DALI
To 0-10V
External Relay connection
DMX
RDM
D-
GND
GND
CH1
CH2
CH3
CH4
+
+
+
+
LT-84A
LEDLED 0-10V0-10V
-
-
-
-
D+
...
AC/L
AC/L
AC/N
AC/N
PUSH DIM
DA/N DA/L
Note: Light intensity of LEDs in the same group may be decreased when one of the LED driver is AC OFF.
+
+
+
+
AC/N
AC/N
AC/L
AC/L
LT-84A
LEDLED 0-10V0-10V
-
-
-
-
Push dim
...
D-
GND
GND
CH1
CH2
CH3
CH4
D+
PUSH DIM
DA/N DA/L
Push
Dim
D-
GND
GND
CH1
CH2
CH3
CH4
+
+
+
+
LT-84A
LEDLED 0-10V0-10V
-
-
-
-
D+
...
AC/L
AC/L
AC/N
AC/N
PUSH DIM
DA/N DA/L
DALI bus
DALI
www.ltech-led.com
(DMX /DALI to 0-10V signal converter)(DMX /DALI to 0-10V signal converter)
(DMX /DALI to 0-10V signal converter)
DMX
controller
DALI
controller
0-10V driver
0-10V driver 0-10V driver
0-10V driver
0-10V driver
0-10V driver
LED Light Fixture
LED Light Fixture
LED Light Fixture
Independent 4 channels
Independent 4 channels
Independent 4 channels
AC source
AC source
AC source
Lamp 1
Lamp 4
Lamp 1
Lamp 4
Lamp 4
Lamp 1
An additional relay or magnetic switch is needed when the total input current of the LED driver is higher than 8A or inrush current is more than 50A. Connection diagram as below:

6
DMX/DALI
To 0-10V
6
Update Time: 25/08/2020_A0
www.ltech-led.com
