Ltech M Series User manual

Wireless Dimming Control
M1+M4-5A
Remote Distance: 131 feet - 164 feet
Working Temp.:
Weight(N.W.): 42g
175mm
44mm
170mm
-22ºF~131ºF
Model: M4-5A
Input Voltage: DC5V~DC24V
Max Current Load: 5A×4CH Max 20A
Max Output Power: 100W/240W/480W(5V/12V/24V)
Gray Scale Level : Max 4096×4096×4096×4096
Working Temp.:
Weight(N.W.): 125g
-4ºF~131ºF
Model: M1
Working Voltage: DC3V(battery CR2032)
Working Frequency: 433.92MHz
60mm 9mm
104mm
Power Input Socket
30mm
OUT
DC5V~24V
RF WIRELESS
1.Parameter:
CV Receiver(DIM):
Remote(DIM):
2. Product Size:
Receiver Remote Remote- h o l d e r
Attn: one receiver can be synced with 10 of the same or different kinds of remotes.
Learning ID:
Cancel ID: Long press of the ID learning button on the M4-5A receiver for 5 seconds.
3. The Learning ID Method of Remote Control:
4. Operating Instruction for Receiver：
5. Operating Instruction for Remote Control :
Sleep Mode:
On/Off
Delay Off
Touch
Color Circle
Scene-mode I Scene-mode
II
Dimming
(Press 2S to save) (Press 2S to save)
LED Lamps
Connection Socket
Running Light
ID Learning Button
warranty
5 years
The M series LED controller is compatible with 8 different kinds of remotes. The M4-5A receiver can
receive single color/CT dimming, RGB/RGBW control functions to meet a wide range of lighting
requirements. With the M series RF remotes, brightness, color as well as customizable color control
modes are easily achievable. Choose the remote that is right for your application.
The Remote control has been matched to the receiver before leaving the factory. If deleted
accidentally, you can re-learn the ID as follows.
With a short press of the ID learning button on the M4-5A receiver, the running light
will illuminate.Then press any key on the M1 remote control. The running light will
flash several times. The two should now be synced.
The remote goes into standby mode after
30 seconds of non-use to save power.
Press any key to resume operation.

M4-5A
DC12V
Maximum Output
60W
Connected to 12V LED Light Panels, loads 1~240W (12V)
CV Receiver
6. Wiring Diagram:
LED Light Panels
M1
7. Attention
8.
1. The product shall be installed and serviced by a qualified person.
2. This product is non-waterproof. Please avoid the sun and rain. When installed outdoors please ensure it is
mounted in a water proof enclosure.
3. Good heat dissipation will prolong the working life of the controller. Please ensure good ventilation.
4. Please check if the output voltage of any LED power supplies used comply with the working voltage of the
product.
5. Please ensure that adequate sized cable is used from the controller to the LED lights to carry the current.
Please also ensure that the cable is secured tightly in the connector to avoid the accidents due to overheat
and poor contact on the wire.
6. Ensure all wire connections and polarities are correct before applying power to avoid any damages to the LED
lights.
7. If a fault occurs please return the product to your supplier. Do not attempt to fix this product by yourself.
1. We provide lifelong technical assistance with this product:
• 5 year warranty is given from the date of purchase. The warranty is for free repair or replacement and
covers manufacturing faults only.
• For faults beyond the 5 year warranty we reserve the right to charge for time and parts.
2. Warranty exclusions below:
• Any man-made damages caused from improper operation, or connecting to excess voltage and overloading.
• The product appears to have excessive physical damage.
• Damage due to natural disasters and force majeure.
• Warranty label, fragile label and unique barcode label have been damaged.
• The product has been replaced by a brand new product.
3. Repair or replacement as provided under the warranty is the exclusive remedy to the customer. Evo-Lite as well
as its suppliers shall not be liable for any incidental or consequential damages for breach of any stipulation in
this warranty.
4. Any amendment or adjustment to this warranty must be approved in writing by Evo-Lite only.
This manual only applies to this model. Evo-Lite reserves the right to make changes without prior notice.
Warranty Agreement
★
100 - 240V AC
DC12V
Constant Voltage (CV)
Power Supply
