Ltech LT-995-OLED User manual

1
www.ltech-led.com
LT-995-OLED
Dimming Curve: 0.1~9.9
Shortcut / Over load protection
OLED display
8 bit / 16 bit
3 kinds of DMX interfaces
www.ltech-led.com
Product Introduction:
5. With the operations can be completed
via the RDM master console, such as parameters browsing & setting, DMX
address setting, equipment recognition, etc.
RDM remote management protocol,
4. Support 3 kinds of DMX ports with signal isolation function: 3-pin XLR,
RJ45, green terminal.
2. Easy operation with OLED screen and the touch buttons.
1. Designed with 5 channels output, and Max. 6A current per channel, up to
720W output power.
3. 5 kinds of mode optional: single color, CT, RGB, RGBW, RGBWY.
6.
function when fault.
With shortcut protection and over load protection, as well as warning
7. With fast self-testing function.
9. Multiple dimming curve (0.1~9.9) optional.
8. 16bit (65536 levels) / 8bit (256 levels) grey level optional.

23
www.ltech-led.com www.ltech-led.com
Technical Specs:
LT-995-OLED
DMX512/RDM
~
×
× 5CH Max. 720W
3-pin XLR, RJ45, green terminal
-30℃~65℃
L169×W80×H39mm
L182×W91×H41mm
550g
12 24Vdc
6A 5CH Max. 30A
(0~72W...144W)
Dimming/CT/RGB/RGBW/RGBWY
0.1~9.9
8bit (256 levels) / 16bit (65536 levels)
Shortcut / Over load
Model
Input Signal
Input Voltage
Current Load
:
:
:
Protection:
Working Temperature :
:
:
:
:
:
Output Power :
DMX Interface :
Control Mode :
Dimming Curve :
Grey Level
Dimensions
Package Size
Weight (G.W.)
Product Size:
Main Component Descripition:
Unit: mm
RJ45
3-pin XLR
DMX/RDM
input & output
DMX/RDM
input & output
Green terminal
DMX/RDM
input & output OLED screen
12-24Vdc
Power input
Green terminals
LED lamps connection

4 5
www.ltech-led.com www.ltech-led.com
OLED Screen Interface:
M
<
<
DMX: Hz: High
Mode: RGB 8bit
Curve: Standard
Dim: Smo TOOL&v
001
DMX: 001 Hz:
Mode: RGB 8bit
Curve: Standard
Dim: Smo TOOL&v
High
DMX: 001 Hz: High
Mode: 8bit
Curve: Standard
Dim: Smo TOOL&v
RGB
DMX: 001 Hz: High
Mode: RGB
Curve: Standard
Dim: Smo TOOL&v
8bit
DMX: 001 Hz: High
Mode: RGB 8bit
Curve: Standard
TOOL&v Dim: Smo
DMX: 001 Hz: High
Mode: RGB 8bit
Curve:
Dim: Smo TOOL&v
Standard
5. Dimming
Curve
4. Grey Level
3. Mode Press “∧" or “∨" key to choose.
Optional : Dim
CT
RGB
RGBW
RGBWY
Press “∧" or “∨" key to choose.
Optional :
Linear
0.1~9.9
Standard
It is recommended to use standard,
0.1-9.9 is for special requirements.
Main page
1. DMX Address
Setting
2. PWM
Frequency
Press “∧" or “∨" key to set DMX address.
Range: 001~512
No flicker in
video camera.
Press “∧" or “∨" key to choose.
Std (standard)
High
Mid (middle)
Low
Optional :
Smooth and delicate,
human eye is comfortable.
6. Enhance
Dimming
Press “∧" or “∨" key to choose.
Optional :
Smo (smooth)
Std (standard)
Smo: This option with smooth processing,
realize the dimming flicker-free and
dynamic effects more downy.
It is recommended to
use standard.
It is recommended to
use standard,
Press "M" key, switch entries.
Long press “M” key, back to main page.
Press "∧" or “∨" key, parameter adjustment.
Exit: back to previous page.
Press “∧" or “∨" key to choose.
Optional : 8bit
16bit (choose it if the master
controller support this
function)

6
www.ltech-led.com
CH1: 255 CH2: 255
CH3: 255 CH4: 255
CH5: 255 ALL: 255
EXIT &V
Screen: ON+Addr
Contrast: 40%
Beep: ON
Lock: OFF EXIT&v
TEST&v
001 Press M for 3s
DMX: 001 Hz: High
Mode: RGBW 8bit
Curve: Standard
Dim: Smo TOOL&v
DMX: 001 Hz: High
Mode: RGBW 8bit
Curve: Standard
Dim: Smo TOOL&v
7. Tool
Press “∧" or “∨"
key to enter submenu
Press “∧" or “∨"
key to enter
submenu of test.
Brightness setting
(range: 0~255)
Press"∨" to exit
Screen will be locked if
unmanned operation for 2 min,
press "M" key for 3s to unlock.
Lock: ON
Screensaver open and
display address.
Screen: ON+Addr
Screensaver open and
black.
Screen: ON+black
Screensaver is not open.
Screen: OFF
* Fast self-testing function: press “ or " keys
simultaneously for 2-3 seconds under any page,
decoder will enter self-testing function.
∧"∨"

87
www.ltech-led.comwww.ltech-led.com
2 Connecting LED lights:
Wiring Diagram:
1. DMX console onnectionc :
LT-995-OLED is equipped with 3 types DMX
terminals for users’ selection. The following
diagram takes 3-pin XLR as an example, same
connecting method for the rest two: RJ45 &
green terminal (with amplifier function).
If the recoil effect occurs because of longer signal line or bad line quality,
please try to connect 0.25W 90-120Ω terminal resistor at the end of each line.
*

910
*
www.ltech-led.com www.ltech-led.com
3. The connection diagram of 3 kinds of DMX/RDM terminals:
3-pin XLR
Connected
in Parallel
RJ45
Connected
in Parallel
Green Terminal
Connected
in Parallel
These 3 terminals can be connected in a mixed way.
4. The connection diagram of :AMP signal amplifier terminal
Connecting with green terminal or an extra amplifier will be needed when more than
32 decoders are connected or use overlong signal wire(as shown below).
Signal amplifier should not be more than 5 times continuously.

11 12
www.ltech-led.com www.ltech-led.com
Address setting table
Mode
Mode
Resolution
Resolution
Address Quantity
Address Quantity
Channel
Channel
DIM
DIM
CT
CT
RGB
RGB
RGBW
RGBW
RGBWY
RGBWY
1
2
2
4
3
6
4
8
5
10
8bit
16bit
8bit
16bit
8bit
16bit
8bit
16bit
8bit
16bit
1
1
2
2
3
3
4
4
5
5
001
001
002 001 002 001 002 001 002 001 002
001
002
003
004 003 004 003 004 003 004
005
006 005 006 005 006
007
008 007 008
009
010
007
008
005
006
005
006
003
004
003
004
001
002
001
002
001
002
001
002
001 001 001 001
001 002 002 002 002
001 001 003 003 003
001 002 003 004 004
001 002 003 004 005
Attention:
Warranty Agreement:
1. The product shall be installed and serviced by the qualified person.
2. This product is non-waterproof. Please avoid the sun and rain. When installed outdoors
please ensure it is mounted in a water proof enclosure.
3. Good heat dissipation will prolong the working life of the controller. Please ensure good
ventilation.
4. Please check if the output voltage of the LED power supply used comply with the
working voltage of the product.
5. Please ensure that adequate sized cable is used from the controller to the LED lights to
carry the current. Please also ensure that the cable is secured tightly in the connector.
6. Ensure all wire connections and polarities are correct before applying power to avoid
any damages to the LED lights.
7. If a fault occurs, please return the product to your supplier. Do not attempt to fix this
product by yourself.
1. We provide lifelong technical assistance with this product:
A 5-year warranty is given from the date of purchase. The warranty is for free
repair or replacement if cover manufacturing faults only.
For faults beyond the 5-year warranty, we reserve the right to charge for time and
parts.
2. Warranty exclusions below:
Any man-made damages caused from improper operation, or connecting to excess
voltage and overloading.
The product appears to have excessive physical damage.
Damage due to natural disasters and force majeure.
Warranty label, fragile label and unique barcode label have been damaged.
The product has been replaced by a brand new product.
3.
4. Any amendment or adjustment to this warranty must be approved in writing by our
company only.
★ This manual only applies to this model. reserve the right to make changes without
We prior notice.
Repair or replacement as provided under this warranty is the exclusive remedy to
the customer. We shall not be liable for any incidental or consequential damages
for breach of any stipulation in this warranty.
Update Time: 2017.04.20_A1
