Ltech Mini M2 User manual

LED controller
1 2
A. RF remote is fashionable, slim, light and easy to carry while receiver is small, exquisite and easy to install.
Attn: one receiver can be matched with max 10 same or different kinds remote.
1. Parameter:
2. Feature:
Remote:
-30 ~55℃ ℃
Model: M2/M5
Working Voltage: 3V (battery
Working Frequency: 433.92MHz
Remote Distance: 30m
Working Temp.:
Dimensions: L104×W58×H9(mm)
Weight(N.W.): 42g
CR2032)
M series LED controller reflected LTECH 12 years’ powerful independent R&D ability in LED field, Its volume
is only 1/3 of the conventional controller, but can implement features such as dimming, RGB and color temperature
control. Its high cost performance and creative design, allowing users to enjoy the benefits and convenience.
ini
3. Product Size:
Learning ID: Short press ID learning button on the receiver M3-3A, the running light is on, then press any key
on the remote control M2/M5, the running light flashes several times, activated.
Cancel ID: Long press ID learning button on the receiver .for 5 seconds
Remote control has been matched to the receiver before leave factory, if deleted accidentally, you can learn ID
as follow.
4. The Learning ID Method of Remote Control:
B. RF remote with low power consumption, long distance, strong obstructions penetrating ability, independent ID
interference-free and other properties.
C. 4096/road grey scale (most of them is 256 in the market), high grayscale performance is more outstanding, the
light is more gentle, dynamic changing modes become more rich and colorful.
D. One receiver compatible with six different functions of the remote, that is use one receiver can experience
dimming, color temperature and RGB control.
E. RF remote is simple and intuitive to use, a variety of actions at a glance, what you see is what you get.
F. Automatic sleep mode, when the touch remote unattended operation over 30s, it can automatically enter
standby mode to extend battery life.
RF WIRELESS
M2
5. Operating Instruction for Remote Control :
ON/OFF
Speed/Brightness+
Mode Key
Speed/Brightness-
Touch
Color Circle
2700K-5500K
NW( neutral white)
-WW(warm white)
smooth
Model: M3-3A
Power Input: 12 24V DC
Max Current Load: Max 3Ax3CH
Max Output Power: 108W(12V)/216W(24V)
Working Temp.:
Dimensions: L135×W30×H20(mm)
Weight(N.W.): 47g
~
Receiver:
-30 ~55℃ ℃
Total Weight(G.W.): 135g
M5
ON/OFF
Mode Key
Speed/Brightness+ Speed/Brightness-
Touch
Color Circle
2700K-7500K
NW-CW smooth,
Sleep Mode:
extend battery life.
when the remote unattended operation over 30s, it can automatically enter standby mode to
press any of these four keys to continue.
www.ltechonline.com

3 4
7. Wiring Diagram:
8. Attention:
9. Warranty Agreement:
1. The product shall be installed and serviced by a qualified person.
7. If a fault occurs please return the product to your supplier. Do not attempt to fix this product by yourself.
6. Ensure all wire connections and polarities are correct before applying power to avoid any damages to the
LED lights.
5. Please ensure that adequate sized cable is used from the controller to the LED lights to carry the current.
Please also ensure that the cable is secured tightly in the connector.
4. Please check if the output voltage of any LED power supplies used comply with the working voltage of the
product.
3. Good heat dissipation will prolong the working life of the controller. Please ensure good ventilation.
2. This product is non-waterproof. Please avoid the sun and rain. When installed outdoors please ensure it is
mounted in a water proof enclosure.
1. We provide lifelong technical assistance with this product:
★This manual only applies to this model. LTECH reserves the right to make changes without prior notice.
4. Any amendment or adjustment to this warranty must be approved in writing by LTECH only.
3. Repair or replacement as provided under this warranty is the exclusive remedy to the customer. LTECH shall
not be liable for any incidental or consequential damages for breach of any stipulation in this warranty.
2. Warranty exclusions below:
For faults beyond the 5-year warranty we reserve the right to charge for time and parts.
A 5-year warranty is given from the date of purchase. The warranty is for free repair or replacement and
covers manufacturing faults only.
Any man-made damages caused from improper operation, or connecting to excess voltage and overloading.
The product appears to have excessive physical damage.
Damage due to natural disasters and force majeure.
Warranty label, fragile label and unique barcode label have been damaged.
The product has been replaced by a brand new product.
6. Operating Instruction for Receiver：
Power input socket
Remote ID learning
button
Indicator light
LED lamp connection socket
W W W + Dimming, M1
C W / V+ Color temperature, remote M2 M5
R G B V+ RGB control, remote M3 M6 M7
V remote
Update Time: 2016.08.09
www.ltechonline.com
