Lucasey FSWA2220 User manual

ASSEMBLYINSTRUCTIONS mLUCASEY
>^HI^ MOUNTING SYSTEMS
FSWA2220ARTICULATINGPLASMAMOUNT
FSULFlatScreenAdaptorPlateRequired
3/8-16 NYLOKNUT
FSULADAPTORPLATE
[SOLDSEPARATELY)
kADAPTORPLATE
INTERFACE
#14X2-1/2"
TAPPINGSCREW
4REQUIRED
LEVELON
MONITORSUPPORTFRAME
1. Removeadaptorplateinterfacefrom
monitorsupportframe.
2. AttachadaptorplateinterfacetoFSUL
(plasmascreenadaptorplateappropriate
toyourmonitor)usingfour 3/8-16
NylockNutsasshown.
3. AttachFSULtoplasmamonitorwith
hardwareappropriateforyourmonitor.
4. Locateandmarkcentersofwoodstuds.
Raisesupportframe andplacea levelon
monitorsupportframe asshowninDiag.4
Adjustandlevelframe. Attachframe to
wallwithfour#14 x 2.5"tappingscrews,
formetalstudwallsuseLucasey
#WMATB4.
5. Raisemonitortosupportframe with
attachedadapterplateinterface.Angle
bottom of monitorawayfrom walland
hooksupportangleoverlipinframe with
studsaligningtoholes in frame.
MONITORSUPPORTFRAME
POSITIONMOUNT
WITH THESE
HOLESFACINGUP
WALLFRAME
l-TECH
COMPANY
Distributedby:
i-Tech CompanyLLC
TOLL FREE: (8881 483-2418EMAILinfo®iTechLCD.com* WEB: www.MechuCD.com

ASSEMBLYINSTRUCTIONS
H
l-IM-OD.
FLATWASHER
2REQUIRED
, ADAPTORPLATEINTERFACE
(SHOWNWrTHOUTFSUL
:SPRINGS FOR CLARITY)
1/4-20 NYLOCKNUT
4REQUIRED
mLUCASEY9-
^4t/trMOUNTING SYSTEMS
6.Securemonitor in placewith 1/4-20hex nuts and
fenderwashers.
7. Installdresscoversasshown in diagram 7.
DRF-SSCOVFR
WALLFRAME
ADJUSTINGSPRINGS & CLUTCHES
1. Adjustspringtensionequally onall4 springs so thatwhenmonitor is
placed ina 0°tiltposition (see diag#1) it stays in place.
2. Tightenclutchbolts 1/2 turn ata time(equally onall4) untilmonitor
stayswhenplaced in positivetiltdirection(seediag #2).
3. Whenproperlyadjustedmonitorshouldmoveeasily inall directions
andremain in placewhenpositioned
m
n
a
LJ
^CLUTCH
GfiTENSIONING
BOLT
SPRING
TENSIONING
KNOBS
l-TECH
COMPANY
Distributedby:
i-TechCompanyLLC
TOLL FREE: i838j433-2418♦ EMAILinfo^ITechLCD.com♦ WEB:www.iTechLCD.com
