luceco CASTRA LFSX-05 Manual

Installation & Operating Instructions
IP65
RATED 3
WARRANTY
year
standard
CRI
80
>
30,000
HOURS
1 2
Tech Help Line
UK - 0330 0249 279
Non UK - [phone]
Supplied by LUCECO
Stafford Park 1, Telford, Shropshire,
England, TF3 3BD
Visit our website at www.luceco.com
Kontakt
UK - 0330 0249 279
Non UK - [phone] - 29
Geliefert von Luceco GmbH
Holstenplatz 20b,
22765 Hamburg DEUTSCHLAND
Besuchen Sie uns auf www.luceco.de
Support Technique
UK - 0330 0249 279
Non UK - [phone]
Notice fournie par
Luceco SAS France & Belux 3
Rue de Courtalin, Magny Le Hongre 77700
FRANCE & BELUX
Visitez note site Web www.luceco.fr
Assistenza tecnica telefonica
UK - 0330 0249 279
Non UK - [phone]
Fornito da BG Electrical Ltd Nexus
Italia, Via Amman 10 33170
Pordenone, Italy
Visitate il nostro sito www.luceco.com
Servicio de asistencia telefónica
UK - 0330 0249 279
Non UK - [phone]
(EU) Luceco SE
C/Bobinadora 1-5 08302 Mataró
Barcelona, Spain
Visite nuestra web en www.luceco.com
CASTRA
LFSX-05
LFS-05.KR.05.2021
NOTE – To comply with regulations, installation must be carried
out by suitably qualified competent person and in accordance
with the current IEE Wiring Regulations (BS761) and Building
Regulations. A copy of the instructions must be left for the user/
maintenance engineer for the future reference.
For non-UK, please refer/consult local requirments
ENSURE ELECTRICAL SUPPLY IS DISCONNECTED/
ISOLATED BEFORE CIMMERCING INSTALLATION
5mm
40mm
Turn OFF power supply, ensure all required
equipment and tools are present
• Power Drill
• Applicable screws and fixings
the luminaire shall be destroyed.
This product range is designed for domestic outdoor use. Not suitable for interior use. If outdoor
connection is required, use a suitably IP rated junction box and terminals. Glands used must be suitable
for HO5RN-F cable as supplied with the luminaire. The Floodlight is pre-wired with 1.0M of H05RN-F 3*1.0mm²
cable,The external flexible cord or cable of this luminaire cannot be replaced; if the cord is damaged,
x: Stand for the colour of the product. It could be B/W.
TECHNICAL SPEC:
Non-Replacable Light Source
The light source contained in this luminaire is not replacable, at the end of life the luminaire shall be destroyed
Part N0 Wattage Useful
Lumens
Luminaire
Lumens
Suggested
Mounting Height Suggesed Halogen
equivalent
Weight Dims (mm) Max Projected
Area
LFS10x130 10W 970 1050 2.5-3.0M 100W 0.32kg 119x94x95 0.014m²
LFS10x150 10W 1050 1200 2.5-3.0M 100W 0.32kg 119x94x95
0.014m²
LFS20x130 20W 1930 2200 2.5-4.0M 200W 0.385kg 131x110x95 0.017m²
LFS20x150 20W 2100 2400 2.5-4.0M 200W 0.385kg 131x110x95 0.017m²
LFS30x130 30W 2650 3000 3.0-5.0M 300W 0.45kg 148x121x95 0.022m²
LFS30x150 30W 2750 3150 3.0-5.0M 300W 0.45kg 148x121x95 0.022m²
LFS50x130 50W 4500 5400 4.0-6.0M 500W 0.68kg 185x151x95 0.045m²
LFS50x150 50W 4600 5400 4.0-6.0M 500W 0.68kg 185x151x95 0.045m²

Installation & Operating Instructions
Tech Help Line
UK - 0330 0249 279
Non UK - [phone]
Supplied by LUCECO
Stafford Park 1, Telford, Shropshire,
England, TF3 3BD
Visit our website at www.luceco.com
Kontakt
UK - 0330 0249 279
Non UK - [phone] - 29
Geliefert von Luceco GmbH
Holstenplatz 20b,
22765 Hamburg DEUTSCHLAND
Besuchen Sie uns auf www.luceco.de
Support Technique
UK - 0330 0249 279
Non UK - [phone]
Notice fournie par
Luceco SAS France & Belux 3
Rue de Courtalin, Magny Le Hongre 77700
FRANCE & BELUX
Visitez note site Web www.luceco.fr
Assistenza tecnica telefonica
UK - 0330 0249 279
Non UK - [phone]
Fornito da BG Electrical Ltd Nexus
Italia, Via Amman 10 33170
Pordenone, Italy
Visitate il nostro sito www.luceco.com
Servicio de asistencia telefónica
UK - 0330 0249 279
Non UK - [phone]
(EU) Luceco SE
C/Bobinadora 1-5 08302 Mataró
Barcelona, Spain
Visite nuestra web en www.luceco.com
4
3
5 6
With a suitable mounting position identified,
loosen main fixing bolt on the rear of the housing
and tilt to allow access to fixing holes.
Fit floodlight to the wall using suitable fixings.
Tilt and rotate floodlight to desired angle and securing
fixing bolt. Ensure product is secure.
LIVE = BROWN
NEUTRAL = BLUE
EARTH = YELLOW/GREEN
Connect the pre-wired cable to the electrical
supply, observing the correct polarity.
Note - Cables must be grounded
When connections are safe. re-isntate power.
Undo
Environmental Protection W.E.E.E (Wheelie Bin Symbol for EU ONLY)
This symbol is known as the “crossed-out” wheelie Bin Symbol”. When this symbol is marked on a product or battery, It means that it should not be disposed of
with your general household waste. Some chemicals contained within electrical/electronic products or batteries can be harmful to health and the environment.
Only dispose of electrical/electronic/battery items in separate collection schemes, which cater for the recovery and recycling of materials contained within. Your
co-operation is vital to ensure the success of these schemes and for the protection of the environment.
United Kingdom Warranty
For other territories and for further information, please see www.luceco.uk for details
Products are protected by warranty for a period of 3 years from date of purchase against defects in material and workmanship (unless otherwise stated). Should a product
fail to perform as described within the warranty period it will be repaired or replaced with the same or equivalent product by Luceco, free of charge provided that you: (1)
return the product to us with shipping charge prepaid, (2) provide us with proof of the original date of purchase and (3) quote our return authorization number.
Repaired or replaced products will be returned to you with shipping charges prepaid. Replacement products may be refurbished or contain refurbished materials. If in our
sole discretion, we are unable to repair or replace a defective product, we will refund the purchase price of the product.
This warranty will not apply if in our judgment, the product fails due to damage in shipment, handling, storage, accident, abuse or misuse, or if it has been used in a
manner not conforming to our product instructions, has been modified in any way, or has any serial number removed or defaced. Repair or attempted repair will void this
warranty. Our maximum liability under the terms of this warranty is limited to the purchase price of the product covered by the warranty.
The warranty is given under English Law. If any part of this warranty is deemed unenforceable (including any provision in which we exclude our liability to you) the
enforceability of any other parts of the warranty will not be affected. These terms do not reduce your statutory rights.
For Non-UK please contact Local Luceco Office for details. THESE TERMS AND CONDITIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.
Eventually, you may want to replace this fitting;
