Lucent Technologies
Bell Labs Innovations
TransTalk™ 9000
Digital Wireless System
MDW 9031 Wireless Pocketphone
Installation and Use
503-801-166
Comcode 108170176
Issue 1
November 1997

Copyright ©199 7Lucent Technologies
All Rights Reserved
Printed in U.S.A.
Lucent Technologies 503-801-166
Comcode 108170176
Issue 1
November 1997
Notice
Every effort was made to ensure that the information in this book was complete and
accurate at the time of printing. However, information is subject to change. The pictures in
this book are for illustrative purposes only; your actual hardware may look slightly different.
Federal Communications Commission (FCC) and Industry Canada (IC) Information
For details, see Appendix B.
Security
Toll fraud, the unauthorized use of your telecommunications system by an unauthorized
party (for example, persons other than your company’s employees, agents, subcontrac-
tors, or persons working on your company’s behalf) can result in substantial additional
charges for your telecommunications services. You are responsible for the security of your
system. There may be a risk of toll fraud associated with your telecommunications system.
You are responsible for programming and configuring your equipment to prevent unautho-
rized use. Your system administrator should read all documents provided with this product
to fully understand the features that can introduce the risk of toll fraud and the steps that
can be taken to reduce that risk. Lucent Technologies does not warrant that this product is
immune from or will prevent unauthorized use of common-carrier telecommunication
services or facilities accessed through or connected to it. Lucent Technologies will not be
responsible for any charges that result from such unauthorized use.
Trademarks
TransTalk is a trademark of Lucent Technologies and DEFINITY, MERLIN, MERLIN LEG-
END, PARTNER, and SYSTIMAX are registered trademarks of Lucent Technologies. Supra
is a registered trademark of Plantronics, Inc.
Warranty
Lucent Technologies provides a limited warranty for this product; see Appendix A.
Ordering Information
The order number for this book is 503-801-166. The order number for the MDW 9031
Wireless Pocketphone Quick Reference is 503-801-165. To order additional copies of
these reference materials, call 1 800 457-1235 or 1 317 361-5353. To order parts and
accessories, see "Ordering Replacement & Optional Parts" in Chapter 4.
Customer Support
In the continental U.S., call 1 800 628-2888 if you need assistance when using your
wireless phone with a PARTNER, MERLIN, or MERLIN LEGEND system. Consultation
charges may apply. For all other systems, follow the procedure you normally use to get
support for your communications system.
Outside the continental U.S., contact your Lucent Technologies Representative or local
Authorized Dealer.

Contents
1Introduction1-1
About TransTalk™ 9000 Products 1-1
What Is a Wireless Phone? 1-1
TransTalk 9000 System 1-1
About the MDW 9031 Pocketphone
1-3
Privacy Information 1-3
Where Can You Use Your Pocketphone?
1-3
Parts List 1-4
Additional Parts 1-5
Spare Battery and Headset 1-6
2Installing the MDW 9031 Pocketphone
Important Safety Instructions
Guidelines for Safe and Efficient Operation
Exposure to Radio Frequency Energy
Cardiac Pacemakers
Hearing Aid Compatibility
Basic Safety Precautions for Installation and Use
Additional Safety Instructions
for Installation Personnel
AC Outlet Check
Installation Overview for
Radio Modules and Carriers
Radio Module/Switch Wiring
Key Components
Positioning a Radio Module or Carrier(s)
General Positioning Rules
Installing a Single Radio Module
Single Radio Module Installation Self Test
Understanding Carriers
Understanding Your Model 117A3 Carrier
Setting the 117A3 Carrier Power Level
Setting the 117A3 Carrier Control/Expansion
DIP Switch
2-1
2-1
2-2
2-2
2-2
2-2
2-3
2-4
2-5
2-6
2-6
2-7
2-9
2-9
2-11
2-12
2-13
2-13
2-15
2-16
i

Understanding Your Model 117A4 Carrier
Installing a Single Carrier
Installing a Single Carrier on a Shelf or Desk
Installing a Single Carrier on a Wall
Single Carrier Installation Self Test
Installing Multiple Carriers
Mounting and Cabling Multiple Carriers
Multiple Carrier Mounting and Cabling Self Test
Installing a Single Radio Module in Each Carrier
Installation Self Test with a Single Radio Module
in Each Carrier
Installing the Remaining Radio Modules
Installation Self Test for Remaining Radio Modules
2-18
2-21
2-22
2-25
2-28
2-29
2-29
2-32
2-33
Handset
Inserting and Removing the
Handset’s Battery Pack
Changing the Communications System Setting
Filling Out the Handset Label
2-35
2-37
2-39
2-41
2-41
2-42
2-43
Battery Charger
Positioning the Battery Charger
Installing the Battery Charger
Inserting a Battery Pack into
the Spare Battery Compartment
Removing a Battery Pack
from the Spare Battery Compartment
Inserting the Handset into the
Battery Charger’s Handset Cradle
Removing the Handset
from the Handset Cradle
2-44
2-44
2-44
2-46
2-47
2-48
2-48
Using the MDW 9031 Pocketphone
33-1
Important Safety Instructions 3-1
The Handset
Handset Controls
Column and Select Buttons
Handset Display (with Backlighting)
Display Messages
3-1
3-2
3-3
3-4
3-5
3-5
3-6
3-6
3-7
Line Status Indicators
Range Indicators
Low Battery Indicator
Volume Control
ii

Carrying Your Pocketphone
Antenna
Changing the Handset Settings
Changing the Communications System
Button Mapping Setting
Enabling or Disabling the Vibrator
Enabling or Disabling Line Preselection
Enabling or Disabling Backlighting
Enabling or Disabling the Alerter
Test Modes
Using Local Test Mode
Using Wireless Test Mode
"Waking Up" the Phone
Making a Call
Answering a Call
Manually Selecting a Line or Programmed Button
Preselecting a Line
Using a Headset
Using the Headset On/Off Button
Answering Calls with a Headset
Placing Calls with a Headset
The Battery Charger
Battery Charger Features
Extending Battery Life
3-7
3-8
3-8
3-8
3-9
3-9
3-10
3-11
3-12
3-12
3-13
3-17
3-17
3-17
3-18
3-18
3-19
3-19
3-19
3-20
3-21
3-21
3-23
4Maintaining the MDW 9031 Pocketphone 4-1
Important Safety Instructions
4-1
Removing a Radio Module
from the Carrier
4-1
Swapping Extensions
4-3
Replacing the Antenna
4-4
Ordering Replacement & Optional Parts 4-5
iii

5Troubleshooting 5-1
Procedures 5-1
Installation Problems 5-1
Handset Problems 5-5
Battery Problems 5-7
Voice Quality Problems 5-8
Range Problems 5-11
Battery Charger Problems 5-14
6MDW 9031 Pocketphone Compatibility6-1
Programming and
Call Handling Instructions 6-1
Programming Features for PARTNER,
MERLIN, and MERLIN LEGEND Systems
6-2
Communications System Compatibility 6-3
PARTNER Systems
6-3
iv
Button Mapping for PARTNER Systems
6-3
Setting the Line-Ringing Options 6-4
MERLIN Systems
6-5
Button Mapping for MERLIN Systems
except MERLIN 410 and MERLIN 820
6-6
Button Mapping for MERLIN 410 and
MERLIN 820 Systems
6-7
Setting the Line Ringing Options 6-8
System 25, System 75, System 85,
and DEFINITY Systems 6-9
Button Mapping for DEFINITY Systems,
System 25, System 75, and System 85
6-10
Setting the Line Ringing Options 6-12
AWarranty and Repair Information A-1
Lucent Technologies Limited Warranty
and Limitation of Liability
A-1
Limitation of Liability
A-2
Repair Information
In-Warranty Repairs
Post-Warranty Repairs
A-2
A-2
A-3

BRegulatory Information B-1
FCC Part 15 Rules
B-1
IC RSS-210 Compliance B-1
Hearing Aid Compatibility B-1
CSpecifications C-1
INIndex1
Battery Charger Wall-Mounting Template B-1
v

Introduction
1
About TransTalk™ 9000 Products
Congratulations on the purchase of your new TransTalk 9000 Digital Wireless System
MDW 9031 Pocketphone. MDW stands for "Multi-Line Digital Wireless." The MDW 9031
Pocketphone is the latest addition to the TransTalk 9000 family of wireless products,
which also includes the MDW 9000 Telephone, the MDW 9010 Telephone and the
MDW 9030P Pocketphone. All of these phones are designed to Lucent Technologies' high
standards for convenience, reliability, and innovation.
TransTalk 9000 products are designed to work with your communications system
(PARTNER®, PARTNER II, PARTNER Plus, PARTNER Advanced Communications System,
MERLIN®, MERLIN II, MERLIN Plus, MERLIN LEGEND®, System 25, System 75, System
85, or DEFINITY®) to provide wireless flexibility.
What Is a Wireless Phone?
A wireless phone has no handset cord and no telephone line cord, so it is portable. This
portability lets you move around freely, without giving up the features of a wired phone.
With a wireless phone, you can make and receive calls even when you are away from
your desk, thus remaining accessible and responsive to your customers and coworkers
as you move around your work area. Time-sensitive work issues will not need to wait until
you are back at your desk, and you can reduce the number of (sometimes costly) phone
calls you must return.
TransTalk 9000 System
Your wireless phone’s handset is linked with your communications system through a
matching radio module, not through the battery charger where the handset sits for charg-
ing. Each handset can be used only with the radio module packaged with the handset. The
handset and the radio module each have the same unique security code and serial number
(on the bottom of the radio module and inside the battery compartment of the handset) to
identify the matching pair. And there is built-in and secure automatic registration between
the handset and radio module, so that your system is ready to use after powering up.
Your TransTalk system may have from 1 to 24 wireless phones. In order to use multiple
wireless phones within the same zone (area of coverage), you also need a carrier (also
known as a backplane). A carrier holds up to six radio modules, and synchronizes radio
Introduction 1-1

To insert the battery pack, insert the tab on the battery
signals for proper operation of multiple phones, ensuring consistent voice quality and
range. If you have a key system (for example, PARTNER or MERLIN). you can link up to
three carriers supporting up to 18 wireless phones in a single zone; if you have a PBX
system (for example, DEFINITY), you can link up to four carriers, supporting up to 24
wireless phones in a single zone. Linked carriers are automatically synchronized with
each other.
The TransTalk 9000 system enables you to use several different phone and carrier models
in the same zone, but there are some compatibility issues to consider. You need to know
the following:
■
■
The name of the MDW phone (9000, 9010, 9030P, or 9031), located in the battery
compartment of the handset. (For an MDW 9000 phone, you also need to know the
Apparatus Code, also located in the battery compartment of the handset.)
The model number of your carrier, located on the left side of the carrier.
The following illustrations show which phone models and carriers can be used together:
Single Carrier Installation
If you have a Model 117A1 Carrier...
Use only...
MDW 9000 phones
(Code 7815H)
If you have a Model 117A1A Carrier,
Model 117A3 Carrier, or
Model 117A4 Carrier...
Note: 117A2
Carriers should
be replaced with
117A4 Carriers.
(No charge to
the customer).
You can use...
MDW 9000 phones
(Code 7815H)
MDW 9000 phones
(Code 7815H03A)
MDW 9010 phones
(Code 7815H04A)
MDW 9030P phones
(Code 7815H05A)
MDW 9031 phones
(Code 7815H06A)
Note: You can use Code 7815H phones
together with other phones only in a
Model 117A1A, Model 117A3, or
Model 117A4 single carrier installation.
1-2 Introduction

Multiple (4 Max) Carrier Installation
If you have multiple Model 117A3 or Model 117A4 System Expansion Carriers (or both)...
Note:
For 117A2
Carriers, see
Note under
Single Carrier
Installation.
Use only...
MDW 9010 phones
(Code 7815H04A)
MDW 9030P phones
(Code 7815H05A)
MDW 9031 phones
(Code 7815H06A)
Note: Multiple carrier installations must use MDW 9010 phones, MDW 9030P phones, and/or MDW
9031 phones. MDW 9000 phones cannot be used in multiple carrier installations.
About the MDW 9031 Pocketphone
The MDW 9031 Pocketphone is not only wireless, but it is also lightweight and pocket-
sized. A removable carrying clip and a lanyard are provided with the handset. You can
use either the clip or the lanyard for hands-free portability. The MDW 9031 also has a
headset connector to accommodate an optional headset.
You can be notified of an incoming call by either an alerter (which rings) or a vibrator, or
both. There is a five-line, user-activated backlighted display that shows information you
would see on a wired system phone’s display (with the exception of the time ), icons
representing various handset functions (such as the alerter and the vibrator), and the
status of up to 12 telephone lines. The MDW 9031 provides Redial, Hold, Mute, Transfer,
and Conference buttons, and provides the capability to program additional features on
unused line buttons.
Privacy Information
The MDW 9031 Pocketphone is designed to protect the privacy and security of your voice
conversation. The phone uses continuously changing radio frequencies and digital
encoding techniques to make it impossible for eavesdropping to occur through the use of
commercially available analog radio scanners.
Where Can You Use Your Pocketphone?
The MDW 9031 Pocketphone can be used in most typical office buildings, in warehouses,
malls, and even in outdoor areas such as loading docks. The location of the radio
module greatly affects the performance of the MDW 9031. Read the "Positioning a
Radio Module or Carrier(s)" section in Chapter 2 to determine the best place to
install the radio module. Repeat the tests several times with the radio module positioned
in a different location each time. To perform the tests, all you need is an electrical outlet
for the radio module and a charged battery pack in the handset.
Introduction 1-3

Parts List
Along with this book and the MDW 9031 Pocketphone Quick Reference, the box should
contain the items shown below. If it does not, call for customer support as described on the
inside front cover of this book.
Handset Battery Pack
Battery Charger
8-foot (2.4 m)
Telephone Line Cord
Carrying Clip
11-foot (3.4 m)
Power Cord/AC Adapter for
Battery Charger
Radio Module
Wall Spacers (2) Philips Head
Wood Screws (2)
8* (0.5 m) Lanyard
1-4 Introduction

Additional Parts
The following parts may be necessary, depending upon your installation.
This Kit of Parts is required only when a single (stand-alone) MDW 9031 Pocketphone
is installed:
Rubber Feet (4)
Radio Module 11-foot (3.4 m) Philips Head Wall Mounting
Power Cord/AC Adapter Wood Screws (2) Plate
These additional parts are required when two or more MDW 9031 Pocketphones are
installed in the same zone:
Philips Head
Wood Screws (4)
Expansion Cable 6-foot (1.8 m) Carrier Assembly 25-foot (7.6 m)
for multiple-carrier installation Power Cord and Standard AC Adapter
or
117A3 Carrier 117A4 Carrier
For information about ordering parts, see "Ordering Replacement & Optional Parts" in
Chapter 4.
Introduction 1-5

Spare Battery and Headset
One nickel metal hydride battery pack, which provides up to 3 hours of talk time, comes
with your MDW 9031 Pocketphone. For extended phone usage, you should purchase an
additional battery pack. If you require full business-day use, you can purchase an
extended battery pack. Although thicker and heavier than the standard battery pack, the
extended battery pack provides 8–9 hours of talk time when fully charged. You can store
the extra battery pack in the Spare battery compartment of the battery charger. Then
when the battery pack in the handset is low, you can switch battery packs.
To help you answer calls, an optional Supra® 9031 headset or a Radium (over the ear)
headset can be attached to a quick-disconnect adapter cord, which you can insert into
the connector on the bottom of the handset to allow hands-free conversation. For instruc-
tions for connecting the headset, see "Using a Headset" in Chapter 3.
Supra 9031 Headset Radium Headset
Standard Battery Extended Battery
Pack Clip Pack Clip
Standard
Extended
Battery Pack Battery Pack
Adapter
For ordering information, see "Ordering Replacement & Optional Parts" in Chapter 4.
1-6 Introduction

Installing the MDW 9031 Pocketphone
2
Important Safety Instructions
This book contains instructions related to safety labels on the product:
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the product.
WARNING indicates the presence of a hazard that can cause severe or fatal
personal injury if the hazard is not avoided.
CAUTION indicates the presence of a hazard that will or can cause minor
personal injury or property damage if not avoided.
This phone is designed to provide trouble-free performance without any special mainte-
nance procedures. To reduce the risk of accidental damage:
■
■
■
■
Keep the phone in an area free of dust, smoke, and moisture; do not block the air
vents by placing objects on top of the radio module.
Do not place the phone or battery charger near a heating duct, radiator, or other heat
source, and do not drop or expose it to excessive shock or vibration.
Unplug the battery charger, radio module, or carrier if its power cord is damaged, if
liquid is spilled into it, or if its housing becomes cracked or otherwise damaged.
To clean your phone, wipe the outside housing with a soft, dust-free cloth. If absolutely
necessary, you may use a cloth slightly dampened with a mild soap and water solu-
tion. Dry quickly with a soft cloth.
CAUTION:
Your phone contains sensitive electronic parts. Never submerge it in any kind of
liquid, and never use liquid or aerosol cleaners, detergents, alcohols, solvents,
abrasive cleaners, or an excessive amount of water when cleaning the housing and
faceplate. To do so could result in irreparable damage.
Installing the MDW 9031 Pocketphone 2-1

Guidelines for Safe and Efficient Operation
Your wireless telephone is a radio transmitter and receiver. When the phone is turned on,
it receives and sends out radio frequency (RF) energy. The phone operates in the fre-
quency range of 902–928 MHz. Your hand-held wireless telephone uses the digital TDD
mode. The power is transmitted in bursts at a 200 Hz pulsed repetition rate. The peak
envelope transmit power is 325 mW or less.
Exposure to Radio Frequency Energy
The design of your wireless telephone complies with the latest Institute of Electrical and
Electronic Engineers (IEEE) and the American National Standards Institute (ANSI) safety
levels with respect to human exposure to RF energy. Of course, if you would like to limit
RF exposure even further, you may choose to control the duration of your calls.
Cardiac Pacemakers
CAUTION:
The MDW 9031 handset is a radio device and, like all radio devices, should not
be placed next to a pacemaker.
Preliminary studies performed at the US Food and Drug Administration (FDA) and else-
where have shown that when digital cellular telephones are placed very close to im-
planted cardiac pacemakers, interference with the operation of the implanted pacemaker
can occur. These preliminary studies show that interference does not occur when there is
a reasonable distance between the telephone and the implanted pacemaker and stops
when the phone is turned off or moved so that it is more than 6 inches (15 cm) from the
pacemaker. Digital cellular telephones operate at .6 W. TransTalk wireless telephones
operate at a lower peak power of 325 mW or less (100 mW, on an average).
Until more is known, the FDA suggests that people with pacemakers may want to take
some simple precautions when using or carrying digital wireless telephones to ensure that
there is ample distance between the digital wireless telephone and the pacemaker—by
not placing the phone next to the pacemaker implant (for example, in a shirt or a coat
pocket directly over the pacemaker implant) when the phone is on and ready to receive a
call and holding it to the ear opposite the side of the body where the pacemaker is
implanted when using the phone. Consult your physician or medical device manufacturer
to determine if additional precautions are necessary.
Hearing Aid Compatibility
Most electronic equipment, such as equipment in hospitals is shielded from RF energy.
However RF energy from wireless telephones may affect some electronic equipment.
Although the TransTalk wireless telephone is compatible with inductively-coupled hearing
aids, you should consult your physician or hearing aid manufacturer to determine if your
hearing aid is adequately shielded from external RF energy. The operation of inad-
equately shielded medical devices may be adversely affected when a portable wireless
telephone is operating in close proximity.
2-2 Installing the MDW 9031 Pocketphone

Basic Safety Precautions for Installation and Use
Always follow these basic safety precautions when installing or using this product to
reduce risk of injury from fire or electric shock.
WARNING:
Installation of this equipment for In-Range Out of Building (IROB) conditions
requires the use of protectors. See the documentation that came with your
communications system for more information.
CAUTION:
This equipment is for installation on Lucent Technologies PARTNER, PARTNER Plus,
PARTNER II, PARTNER Advanced Communications System, MERLIN, MERLIN
Plus, MERLIN II, MERLIN LEGEND, System 25, System 75, System 85, and DEFINITY
■
■
■
■
■
■
■
■
■
communications systems only.
Read and understand all instructions in this book before using this product.
Observe all warnings and instructions marked on the product.
Do not use the product near water or when you are wet. If the product comes in contact
with any liquids, unplug the power cord and telephone line cords immediately. Do not
plug the product back in until it has dried thoroughly.
Never push objects of any kind into this product through housing slots, since the objects
may touch hazardous voltage points or short out parts that could result in a risk of electric
shock. Never spill liquid of any kind on the phone.
If you suspect a gas leak, report it immediately, but use a phone away from the area in
question. The phone’s electrical contacts could generate a tiny spark. While unlikely, it is
possible that this spark could ignite a heavy concentration of gas. This product is not
approved for use in areas labeled by the Occupational Safety and Health Administration
(OSHA) as "explosive environments." Only "Explosive Atmosphere Telephones" may be
used in such hazardous environments.
Unplug this product from wall outlets and telephone jacks before cleaning. Clean
exposed parts with a soft, damp cloth. Do not use liquid or aerosol cleaners.
Unplug this product from the wall outlet, remove the telephone line cord from the
modular wall jack or communications system switch/control unit, and refer servicing to
qualified service personnel under the following conditions:
–When the power cord or plug is damaged or frayed.
–If the product does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions because
improper adjustment of other controls may result in damage and will often require
extensive work by a qualified technician to restore the product to normal operation.
–If the product has been dropped and the housing has been damaged.
This product should be serviced by (or taken to) a qualified service center when service
or repair work is required. Do not open the product, there are no user-serviceable
components inside.
Always unplug the power cord/AC adapter for the carrier or carriers from the wall
outlet when:
–Removing a radio module
–Moving a radio module to a new slot in the carrier
Installing the MDW 9031 Pocketphone 2-3

–
–
–
■
Installing a new radio module
Connecting or disconnecting telephone line cords
Adding a carrier
Use only the type of battery pack shipped with this product or sold as an optional part.
(See "Ordering Replacement & Optional Parts" in Chapter 4.)
WARNING:
The rechargeable battery pack may contain elements that are harmful to the
environment (for example, nickel). Do not burn or puncture the battery pack. Like
other batteries of this type, if it is burned or punctured, it could release toxic
material which could cause injury. Do not dispose of it in household garbage. For
information about recycling or proper disposal, consult your local solid waste
(garbage) collection or disposal organization.
Additional Safety Instructions
for Installation Personnel
■
■
■
■
■
■
■
■
■
■
■
■
Install the product to meet all environmental and electrical requirements listed in
Appendix C.
All wiring that connects to this equipment and becomes part of the building wiring
must be a minimum of CLASS 2 or UL (Underwriters Laboratories) Listed Communica-
tions cable.
Do not install telephone wiring during a lightning storm.
Do not install telephone jacks in a wet location unless the jack is specifically designed
for wet locations. Never touch uninsulated telephone wires or terminals unless the
telephone line has been disconnected at the network interface.
Use caution when installing or modifying telephone lines.
Install this product securely on a stable surface. Damage may result if the product
falls.
Never place this product near or over a radiator or heat register.
Slots and openings in the housing and the back or bottom are provided for ventilation.
To protect the housing from overheating, these openings must not be blocked or
covered. Therefore, do not place the product on a bed, sofa, rug, or other similar
surface. Also, do not place this product in an enclosed area unless proper ventilation
is provided.
Install this product in a protected location where no one can step on or trip over power
cords and telephone line cords. Do not place objects on the cords that may cause
damage or abrasion.
Do not allow anything to rest on the power cord. Do not locate this product where the
cord will be abused by persons walking on it. Do not overload wall outlets as this can
result in the risk of fire or electric shock. Do not staple or otherwise attach the power
cord to building surfaces.
Use only the power supply (Comcode 847713583) shipped with this product for the
battery charger.
Use only the power supply (Comcode 847523404) shipped with this product for the
radio module.
2-4 Installing the MDW 9031 Pocketphone

■
■
■
Use only the power supply (Comcode 847224227) shipped with the carrier.
Use only the correct power source. If you are not sure of the power supply to your
location, consult your local power company.
This product uses a 3-prong plug. Such plugs are designed for your safety. Do not
attempt to defeat this purpose. If your wall outlet will not accept the plug, the outlet
should be replaced by an electrician.
WARNING: Risk of Electric Shock
Failure to properly ground this product will result in a risk of electrical shock,
which can cause serious personal injury. This product requires a 3-prong AC
outlet for safe operation. You should have your outlet checked by a qualified
electrician (see "AC Outlet Check" below) before connecting this equipment.
AC Outlet Check
Have a qualified electrician check all of the outlets into which the MDW 9031 radio
modules or carriers as well as the communications system switch/control unit will be
plugged. The electrician should check that the hot, neutral, and ground wires are properly
connected to the outlet by using a circuit tester.
The outlet can also be tested using a voltmeter by taking the measurements as shown:
If the outlet does not meet the electrical specifications for grounded outlets, your MDW
9031 Pocketphone may not operate properly.
IMPORTANT:
If there is no current to the outlet or the voltages are not correct, the problem should
be corrected by a qualified electrician.
Go to "Installation Overview for Radio Modules and Carriers."
Installing the MDW 9031 Pocketphone 2-5

Installation Overview for
Radio Modules and Carriers
This section explains how to install radio modules and carriers. You should proceed
through this section in the following order:
1. "Radio Module/Switch Wiring"
2. "Key Components"
3. "Positioning a Single Radio Module or Carrier(s)"
4. "Wireless Test Mode" (in Chapter 3)
5. Choose one of the following paths, depending upon which components you are
installing:
■If you are installing single radio module, go to "Installing a Single Radio
Module."
■If you are installing one or more carriers (from two to 24 radio modules), go to
"Understanding Carriers."
NOTE:
The illustrations in this chapter depict PARTNER system hardware; your hardware may
differ from these illustrations.
Radio Module/Switch Wiring
If your installation requires some customized wiring, the technician should match the Pin
numbers with the switch interfaces as shown in the following table:
Switch Interface
Pin #
ATL (MERLIN, DEFINITY) 1, 2
ETR (PARTNER)
3, 6
T/R (Tip/Ring)
5, 4
2-6 Installing the MDW 9031 Pocketphone

Key Components
Each radio module communicates with a corresponding handset. The matching sets are
identified by a serial number located on the bottom of the radio module and in the battery
compartment of the handset.
Antenna
Hook
Mounting
LEDs
Power Cord
Connector
Card Edge
(Cover not
shown)
Snap Lock
Serial Number
Telephone
Line Cord
Connector
Installing the MDW 9031 Pocketphone 2-7
