CIB 2866
Auxiliary Power Unit
CIB 2866
Comcode 103-974-606
Issue 3

CIB 2866
Auxiliary Power Unit
When the number of voice terminals and voice terminal accessories
(including hands-free units and headset adapters) is greater than your
MERLIN® Communications System’s capacity, connect an Auxiliary
Power Unit (Figure 1) to supply your MERLIN system with additional
power.
The Auxiliary Power Unit is for use with the MERLIN® Communications
System Models 1030 and 3070 and the MERLIN II system.
FIGURE 1 The Auxiliary Power Unit
The following components come with the Auxiliary Power Unit:
●
●
●
NOTE: For MERLIN II system installations, use a 7-foot D4CH (Order
Number 61407) modular line cord or a D4BU (Order Number 2725-02G)
modular line cord. Do not use the auxiliary power cord supplied.
AC line cord
Auxiliary power cord
Hardware kit (for wall-mounting).
iss 3, cib2866-1

Installing the Auxiliary Power Unit
Refer to the table below to select an appropriate installation method for
your Auxiliary Power Unit, depending on the model of your MERLIN sys-
tem. Separate installation instructions follow the table for each method.
If your system
Use one of these installation methods:
is a:
MERLIN Model
1030 or 3070
●Shelf or desk-top mounted to the left (or in
front) of the control unit.
●Mounted on the back of the control unit or
expansion unit.
●Wall-mounted to the left of the control
unit.
MERLIN II ●Wall-mounted to the left of or below the
unit’s basic carrier (depending on avail-
able space).
SHELF OR DESK-TOP MOUNTING
Place the Auxiliary Power Unit on a shelf or desk as close as possible to
the auxiliary power jack on the power module to which it will be con-
nected.
1030 OR 3070 CONTROL UNIT MOUNTING
The Auxiliary Power Unit may be mounted on the back of a control unit
or expansion unit whether or not they are wall-mounted. (It is not neces-
sary to remove wall-mounted units from the wall.)
1Hold the Auxiliary Power Unit so the AUX POWER, AC OUTPUT,
and AC INPUT connectors are facing downward.
2Place the keyhole slots on the bottom of the Auxiliary Power Unit
over the control unit or expansion unit mounting hooks.
WALL-MOUNTING
Follow the steps below, using the mounting location specified for your
MERLIN system in the table on Page 2.
1Holding the template (provided at the end of these instructions) level,
place it against the mounting location on the wall.
2
Using a pencil or sharp object, mark the two mounting screw loca-
tions on the wall.
iss 3, cib2866-2

3Unpack the hardware kit and follow the instructions below for the type
of mounting surface you have selected.
For plywood walls or walls with a sturdy support structure (wood
studs or crossmembers):
AUse a 1/16” drill bit to drill pilot holes at both of the marked
mounting screw locations.
B
Place the mounting plate against the wall and align its screw
holes with those in the wall.
CInsert and partially thread one wood screw (provided) into each of
the mounting plate’s screw holes. Tighten both screws.
For paneled, plaster, and plasterboard (hollow) walls:
A
B
C
D
E
Use a 5/16” drill bit to drill holes at both of the marked mounting
screw locations.
Select the proper sized toggle bolts for the wall thickness:
●For walls 3/8” to 1/2” thick, use the smaller of the two sizes of
toggle bolts.
●For walls 5/8” to 3/4” thick, use the larger of the two sizes.
Fold the screw anchor (Figure 2A) and insert one anchor into
each of the drilled holes. Tap each anchor with a hammer until it
is flush with the wall (Figure 2B).
Insert the red key (provided in the hardware kit) into the anchor,
and push with your fingertip (do not force or hammer the red key)
to pop open the anchor (Figure 2C). Remove the red key.
Place the mounting plate against the wall and align its screw
holes with the anchor’s screw holes (Figure 2D). Insert and par-
tially thread the 1-3/4” screws into each of the mounting plate’s
screw holes. Tighten both screws.
iss 3, cib2866-3

A
B
CD
Red
key Mounting
Plate
E Wall mount
Mounting
Studs
Keyholes
FIGURE 2 Installing the Auxiliary Power Unit On a Hollow Wall
For concrete, brick, and cinder block surfaces:
A Install #6 masonry bolts (not provided) according to the
manufacturer’s instructions at each of the previously marked
mounting screw locations.
B Place the mounting plate against the wall and align its screw
holes with the bolt’s screw holes. Insert and partially thread a
screw (provided with the masonry bolts) into each of the mounting
plate’s screw holes. Tighten both screws.
4Align the keyholes on the back of the Auxiliary Power Unit with the
mounting plate’s studs (Figure 2E). Slide the auxiliary power unit
downward until it rests securely on the mounting plate.
Connecting the Auxiliary Power Unit
MODEL 1030 AND 3070
1
2
3
4
Remove the door(s) and lift the silver lid off the top of the unit.
Turn off the power switch(es) on the Power Module(s). If your sys-
tem has an expansion carrier, first turn the power off at the basic
carrier's power module. Then turn the power off at the expansion
carrier’s power module.
Unplug the power cord from its ac outlet and plug it into the outlet
labeled AC OUTPUT on the Auxiliary Power Unit.
Insert the modular jack on the auxiliary power cord into the jack
labeled AUX POWER on the Auxiliary Power Unit (Figure 3).
iss 3, cib2866-4

Connect to the Power Module’s
auxiliary power jack
Auxiliary power cord
Auxiliary Power Unit
AC outlet
AC line cord
Control unit Power cord from
the Power Module
FIGURE 3 Connecting the Auxiliary Power Unit to a Model 1030
5
6
7
8
9
10
If you mounted the Auxiliary Power Unit on back of the control unit or
expansion unit, thread the auxiliary power cord through the top rail of
the unit (Figure 3).
Insert the other end of the auxiliary power cord into one of the jacks
labeled AUXILIARY POWER on the Power Module.
Plug one end of the ac line cord into the AC INPUT on the Auxiliary
Power Unit (Figure 3).
Plug the other end of the line cord into an ac outlet that is not switch-
controlled (Figure 3).
Turn On the power switch(es). If your system has an expansion car-
rier, first turn the power on at the expansion unit’s Power Module.
Then turn the power on at the basic carrier’s Power Module.
Replace the silver lid and the door(s).
iss 3, cib2866-5

MERLIN II
1 Remove the front cover.
2Turn off the power switch(es) on the Power Module(s). If your sys-
tem has an expansion carrier, first turn the power off at the basic
carrier’s power module. Then turn the power off at the expansion
carrier’s power module.
3Unplug the power cord from its ac outlet and plug it into the outlet
labeled AC OUTPUT on the Auxiliary Power Unit (Figure 4).
AC
outlet
Auxiliary
power unit
Auxiliary
power input
jack
D4BU or D4CH
modular line cord
Power module
Basic carrier
Basic carrier’s
power cord
Wire manager
FIGURE 4 Connecting the Auxiliary Unit to MERLIN II
4 Plug one end of a D4BU or a D4CH modular line cord into the jack
labeled AUX POWER INPUT on the Power Module (Figure 4).
Thread the cord through the module’s wire manager.
5
Plug the other end of this cord into the jack labeled AUX POWER on
the Auxiliary Power Unit (Figure 4).
6Plug the other end of the ac line cord into the AC INPUT on the Auxi-
liary Power Unit (Figure 4).
iss 3, cib2866-6

7Plug the other end of the line cord into an ac outlet that is not switch-
controlled (Figure 4).
8Turn On the power switch. If your system has an expansion car-
rier, first turn the power on at the expansion unit’s Power Module. Then
turn the power on at the basic carrier’s Power Module.
9Replace the front cover.
Template
1
2
To remove this template:
Cut along dotted
line.
Tear lower portion of page out of booklet.
Mounting plate outline
Mounting
holes
iss 3, cib2866-7
