Lucent Technologies ED83134-30 User manual

Product Manual
ED83134-30
026-369-100
Comcode 107300584
Issue 2
June 1996
Lucent Technologies
600-2000 Ampere
Switch and Fuse
Notice:
Every effort was made to ensure that the information in this
document was complete and accurate at the time of printing.
However, information is subject to change.
©1996 Lucent Technologies
All Rights Reserved
Printed in U.S.A.

Lucent Technologies 600-2000 Ampere Switch and Fuse (ED83134-30)
Issue 2 June 1996 Table of Contents - 1
Table of Contents
1 Introduction
General 1 - 1
Documentation References 1 - 1
Technical Support 1 - 2
USA, Canada, Puerto Rico, and the US Virgin Islands 1 - 2
Central and South America 1 - 2
Europe, Middle East, and Africa 1 - 2
Asia Pacific Region 1 - 2
Product Repair and Return 1 - 2
USA, Canada, Puerto Rico, and the US Virgin Islands 1 - 2
Central and South America 1 - 3
Europe, Middle East, and Africa 1 - 3
Asia Pacific Region 1 - 3
Customer Service 1 - 3
2 Product Description
General Description 2 - 1
Features 2 - 1
3 Installation and Operation
4 Product Warranty

Lucent Technologies 600-2000 Ampere Switch and Fuse (ED83134-30)
Issue 2 June 1996 List of Figures - 1
List of Figures
Figure 1-1: ED83134-30 Switch and Fuse Panel
Installed in H569-418 Bay 1 - 4
Figure 1-2: Rear View of ED83134-30
Switch and Fuse Panel 1 - 5

Lucent Technologies 600-2000 Ampere Switch and Fuse (ED83134-30)
Issue 2 June 1996 Introduction 1 - 1
1 Introduction
General This Product Manual describes the 600-2000 Ampere Switch
and Fuse panel (ED83134-30). The ED83134-30, shown
installed in the H569-418 equipment frame in Figure 1-1, serves
as a multi-purpose switch and fuse. It can be used in three ways:
• as a high capacity distribution with “ON” and “OFF”
positions.
• as a battery disconnect switch which allows for the safe
removal of blown fuses.
• for off line equalize charging capability, switching from
floating operation to equalize charging.
The ED83134-30 panel may be ordered with a switch rated at
either 1200 or 2000 amperes. As many as six panels may be
installed in a single H569-418 equipment frame.
This manual includes a general product description, basic
features, and installation information.
Documentation
References This Lucent Technologies document (Select Code
026-369-100) is part of a set of documentation developed to
assistengineering and installationpersonnel.Additionalproduct
information includes the following:
• ED83134-30 Switch and Fuse Assembly Drawings
• H569-418 Bay Drawings
• T-8320730 Wiring Drawings
• SD-8320701 Schematic Drawings

Lucent Technologies 600-2000 Ampere Switch and Fuse (ED83134-30)
1 - 2 Introduction Issue 2 June 1996
Technical
Support Technical support for Lucent Technologies equipment is
available to customers around the world.
USA, Canada,
Puerto Rico, and
the US Virgin
Islands
Onapost-salebasis,duringtheProductWarrantyperiod,our
Technical Support telephone number 1-800-CAL RTAC (1-800-
225-7822) provides coverage during normal business hours.
Product Specialists are available to answer your technical
questions and assist in troubleshooting problems. For out-of-
hours EMERGENCIES, the 800 number will put you in touch
with a Regional Technical Assistance Center Engineer via our
24 hour a day, 7 day per week Help Desk.
When Technical Support is required in the Post-Warranty
Period, the service may be billable unless you hold an extended
warranty or contractual agreement.
Central and
South America If you need product technical support, contact your local Field
Support/Regional Technical Assistance Center or contact your
sales representative who will be happy to discuss your specific
needs.
Europe, Middle
East, and Africa If you need product technical support, contact your local Field
Support/Regional Technical Assistance Center or contact your
sales representative who will be happy to discuss your specific
needs.
Asia Pacific
Region If you need product technical support, contact your local Field
Support/Regional Technical Assistance Center or contact your
sales representative who will be happy to discuss your specific
needs.
Product Repair
and Return Repair and return service for Lucent Technologies equipment is
available to customers around the world.
USA, Canada,
Puerto Rico, and
the US Virgin
Islands
For information on returning of products for repair, customers
may call 1-800-255-1402 for assistance.

Lucent Technologies 600-2000 Ampere Switch and Fuse (ED83134-30)
Issue 2 June 1996 Introduction 1 - 3
Central and
South America If you need to return a product for repair, your sales representative will be happy to discuss your individual situation.
Europe, Middle
East, and Africa If you need to return a product for repair, your sales representative will be happy to discuss your individual situation.
Asia Pacific
Region If you need to return a product for repair, your sales representative will be happy to discuss your individual situation.
Customer
Service For customer service, any other product or service information,
or for additional copies of this manual or other Lucent
Technologies documents, call 1-800-THE-1PWR
(1-800-843-1797). Specify the select code number for manuals,
or drawing number for drawings. Contact your regional
customer service organization or sales representative for
information regarding spare parts.

Lucent Technologies 600-2000 Ampere Switch and Fuse (ED83134-30)
1 - 4 Introduction Issue 2 June 1996
Figure 1-1: ED83134-30 Switch and Fuse Panel Installed in H569-418 Bay

Lucent Technologies 600-2000 Ampere Switch and Fuse (ED83134-30)
Issue 2 June 1996 Introduction 1 - 5
Figure 1-2: Rear View of ED83134-30 Switch and Fuse Panel

Lucent Technologies 600-2000 Ampere Switch and Fuse (ED83134-30)
1 - 6 Introduction Issue 2 June 1996

Lucent Technologies 600-2000 Ampere Switch and Fuse (ED83134-30)
Issue 2 June 1996 Product Description 2 - 1
2 Product Description
General
Description The H569-418 Battery Switch Bay can come equipped with up
to six ED83134-30 panels(600-2000 Ampere SwitchandFuse).
These switch and fuse panels have the capacity to carry and
switch up to 2000 amperes at up to 65 volts dc.
Each switch and fuse unit comes mounted in a 12-inch panel. A
protective clear cover protects users from electrical contact.
Rear access busbars allow cable connections.
You may order the ED83134-30 switch and fuse panel as either
Group 1 or Group 2. Group 1 panels use fuses ranging from 600
to 1200 amperes, while Group 2 panels uses fuses ranging from
1000 to 2000 amperes. Group 1 comes equipped with a 1200
ampere shunt and Group 2 comes equipped with a 2000 ampere
shunt for current monitoring.
Features The following features are provided with this product:
• Distributes or switches ± 24VDC and ± 48VDC
• Single pole, double throw switch
• Compact size allows six units to be mounted in one H569-
418 bay
• Accommodates fuses ranging from 600 to 2000 amps
• Fuse operation generates visual alarm within the unit
• Remote access for monitoring alarm conditions through
controller
• 1200 or 2000 ampere monitoring shunts
• Rear access for cabling
• Cable entry from top or bottom of cabinet
• Allows connection of cable sizes from 4/0 to 750MCM
• Protective front and rear clear covers
• Front access for fuse replacement

Lucent Technologies 600-2000 Ampere Switch and Fuse (ED83134-30)
2 - 2 Product Description Issue 2 June 1996

Lucent Technologies 600-2000 Ampere Switch and Fuse (ED83134-30)
Issue 2 June 1996 Installation and Operation 3 - 1
3 Installation and Operation
Installation of the ED83134-30 panel is very simple. A set of
#12-24x0.625 self tapping screws is provided for installation in
an H569-418 Switch Bay. Figure 1-1 shows the ED83134-30
unit along with the H569-418 bay. Mount the panel onto the
H569-418 bay as shown in the figure. Recommended torque
setting for the self tapping screws is 35 in-lb. Use a power drill
with an 8mm socket to thread the screw through the frame.
The switch may be used either for power distribution,
disconnect, or off-line equalize. Raise the switch handle fully to
select the “ON” position. Lower the switch handle fully to select
the “OFF” or “Equalize” position, depending on the application
selected.
Always move the switch handle firmly and seat the switch fully
in the chosen position. Never leave the switch partially seated.
Partial contact can cause excess heating between conducting
parts.
The switch may operate stiffly; this is normal.
When the switch is used for the equalize function, there is no
“OFF” position. Do not leave the switch handle in the center to
simulate an “OFF” position.
Leave the lexan cover in place during normal operation because
some sparking may occur when the switch is thrown. Remove
the lexan cover to change the fuse. The handle may be left in the
centerpositiontointerruptthecurrentpathwhenchangingfuses,
but take care not to move the handle accidentally to either
contact position while you are working. If possible, block the
path of the switch with non-conductive material to prevent
accidental contact.

Lucent Technologies 600-2000 Ampere Switch and Fuse (ED83134-30)
3 - 2 Installation and Operation Issue 2 June 1996

Lucent Technologies 600-2000 Ampere Switch and Fuse (ED83134-30)
Issue 2 June 1996 Product Warranty 4 - 1
4 Product Warranty
A. Seller warrants to Customer only, that:
1. As of the date title to Products passes, Seller will have
the right to sell, transfer, and assign such Products and
the title conveyed by Seller shall be good;
2. Upon shipment, Seller's Manufactured Products will be
free from defects in material and workmanship, and will
conform to Seller's specifications or any other
agreed-upon specification referenced in the order for
such Product;
3. With respect to Vendor items, Seller, to the extent
permitted, does hereby assign to Customer the
warranties given to Seller by its vendor of such Vendor
Items, such assignment to be effective upon Customer's
acceptance of such Vendor Items. With respect to
Vendor items recommended by Seller in its
specifications for which the vendor's warranty cannot be
assigned to Customer, or if assigned, less than Sixty
(60) days remain of the vendor's warranty or warranty
period when the Vendor's items are shipped to Customer
or when Seller submits its notice of completion of
installation if installed by Seller, Seller warrants that
such Vendor's Items will be free from defects in
material and workmanship on the date of shipment to
Customer. In such an event, the applicable Warranty
Period will be sixty (60) days.
B. The Warranty Period listed below is applicable to Seller's
Manufactured Products furnished pursuant to this
Agreement, unless otherwise stated:

Lucent Technologies 600-2000 Ampere Switch and Fuse (ED83134-30)
4 - 2 Product Warranty Issue 2 June 1996
WARRANTY PERIOD
*The Warranty Period for a repaired Product or part thereof is
as listed or, in the case of Products under Warranty, is the
period listed or the unexpired term of the new Product
Warranty Period, whichever is longer.
**The Warranty Period for Products ordered for Use in
Systems or equipment Manufactured by and furnished by
Seller is that of the initial Systems or equipment.
C. If, under normal and proper use during the applicable
Warranty Period, a defect or nonconformity is identified in a
Product and Customer notifies Seller in writing of such
defect or nonconformity promptly after Customer discovers
such defect or nonconformity, and follows Seller's
instructions regarding return of defective or nonconforming
Products, Seller shall, at its option attempt first to repair or
replace such Product without charge at its facility or, if not
feasible, provide a refund or credit based on the original
purchase price and installation charges if installed by Seller.
Where Seller has elected to repair a Seller's Manufactured
Product (other than Cable and Wire Products) which has
been installed by Seller and Seller ascertains that the
Product is not readily returnable for repair, Seller will repair
the Product at Customer's site.
With respect to Cable and Wire Products manufactured by
Seller which Seller elects to repair but which are not readily
returnable for repair, whether or not installed by Seller,
Seller at its option, may repair the cable and Wire Products
at Customer's site.
D. If Seller has elected to repair or replace a defective Product,
Customer shall have the option of removing and reinstalling
or having Seller remove and reinstall the defective or
nonconforming Product. The cost of the removal and the
reinstallation shall be borne by Customer. With respect to
Cable and Wire Products, Customer has the further
Product Type New Product Repaired Product or Part
Central Office
Power
Equipment 24 Months 6 Months

Lucent Technologies 600-2000 Ampere Switch and Fuse (ED83134-30)
Issue 2 June 1996 Product Warranty 4 - 3
responsibility, at its expense, to make the Cable and Wire
Products accessible for repair or replacement and to restore
the site. Products returned for repair or replacement will be
accepted by Seller only in accordance with its instructions
and procedures for such returns. The transportation expense
associated with returning such Product to Seller shall be
borneby Customer.Seller shallpay thecost of transportation
of the repair or replacing Product to the destination
designated by Customer within the Territory.
E. The defective or nonconforming Products or parts which are
replaced shall become Seller's property.
F. If Seller determines that a Product for which warranty
service is claimed is not defective or nonconforming,
Customer shall pay Seller all costs of handling, inspecting,
testing, and transportation and, if applicable, traveling and
related expenses.
G. Seller makes no warranty with respect to defective
conditions or nonconformities resulting from actions of
anyone other than Seller or its subcontractors, caused by any
ofthe following: modifications, misuse, neglect, accident, or
abuse; improper wiring, repairing, splicing, alteration,
installation, storage, or maintenance; use in a manner not in
accordance with Seller's or vendor's specifications or
operating instructions, or failure of Customer to apply
previously applicable Seller modifications and corrections.
In addition, Seller makes no warranty with respect to
Products which have had their serial numbers or month and
year of manufacture removed, altered, or with respect to
expendable items, including, without limitation, fuses, light
bulbs, motor brushes, and the like.
THE FOREGOING WARRANTIES ARE EXCLUSIVE AND
ARE IN LIEU OF ALL OTHER EXPRESS AND IMPLIED
WARRANTIES, INCLUDING BUT NOT LIMITED TO
WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE. CUSTOMER'S SOLE
AND EXCLUSIVE REMEDY SHALL BE SELLER'S
OBLIGATION TO REPAIR, REPLACE, CREDIT, OR
REFUND AS SET FORTH ABOVE IN THIS WARRANTY.
© 1996 Lucent Technologies
All Rights Reserved
Printed in U.S.A.
